770674-1: DescriptionTerminal, 0.6 mm2, BERYLLIUM COPPER, TIN FINISH, PCB TERMINAL, ROHS COMPLIANT; CategoryThe connector terminals; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

770674-1 Overview

Terminal, 0.6 mm2, BERYLLIUM COPPER, TIN FINISH, PCB TERMINAL, ROHS COMPLIANT

770674-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Manufacturer's serial number	770674
terminal gender	FEMALE
Terminal and terminal strip types	PCB TERMINAL
Conductor cross section	0.6 mm2
Wire gauge	20 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors - Wire to Board - Power

Product Feature Selector

> Product Details

770674-1 Product Details

Live Product Chat

Printed Circuit Board Disconnects

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

770674-1

T E I nternal N umber: 7 7 0 6 7 4 - 1

Product Highlights:

Receptacle

C Body Shape

Disconnect Diameter = 1.02 mm

Wire Range = 0.20-0.60² [24-20] mm [AWG]

With Insulation Support

View all Features

Obsolete

C ontact Product Information

C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

REC EPTAC LE, .040 DIAMETER,

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

Disconnect System, P.C .B., .058 Dia

(PDF, English)

Disconnect System, P.C .B., .093 Dia

(PDF, English)

Application Specifications:

.058 and .093 Diameter Printed C ircuit Board Pins an...

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Receptacle

Body Shape

= C

Insulation Support

= Yes

Material = Beryllium C opper

Insulation Diameter (mm [in])

= 1.02-2.54 [.040-.100]

C omment = Machine applied applicator required.; Receptacle has an

overlap insulation crimp.

Body Related Features:

Disconnect Diameter (mm [in])

= 1.02 [0.040]

Wire Range (mm [AWG])

= 0.20-0.60² [24-20]

Plating = Tin

Stock Thickness (mm [in]) = 0.25 [0.010]

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was RoHS compliant

Packaging Related Features:

Packaging Method

= Strip

Other:

Brand = AMP

Additional Information:

Product Line Information
