Series 800 PCB Receptacle
G
H
J
K
L
M
N
P
Series 800
Series 800 “Mighty Mouse”
Original UNF Threaded Coupling
A
Series 800 Vertical PCB Receptacles
Series 800 PCB Receptacles
feature
.020" (0.5mm) diameter gold-plated
tails for solder termination to rigid or
flexible circuits. Contacts are non-
removable.
Two Shell Styles:
jam nut with o-ring
for rear panel mounting, or square
flange.
Epoxy Sealed
to prevent water
ingress in "open face" condition.
Integral Standoffs
allow clearance
for washing.
HOW TO ORDER SERIES 800 VERTICAL PCB RECEPTACLES
Sample Part Number
800-012
Series
800-012
PCB Receptacle,
Vertical Mount
– 07
Shell Style
M
Shell Material / Finish
C
Aluminum / Black Anodize
7-10
Shell Size- Insert
Arrangement
5-3
6-1
6-4
6-7
7-1
7-10
8-13
9-4
9-19
10-26
12-2
12-37
3 #23
1 #16
4 #23
7 #23
1 #12
10 #23
13 #23
4 #16
19 #23
26 #23
2 #12
37 #23
P
Contact
Type
P
Pin
Z
Shell Key
Position
N
Normal
M
Aluminum / Electroless Nickel
S
Socket
X
Pos. X
02
Square Flange
NF
Aluminum / Cadmium with Olive
Drab Chromate
Y
Pos. Y
ZN
Aluminum / Zinc-Nickel with
Olive Drab Chromate
Z
Pos. Z
ZNU
07
Jam Nut
Aluminum / Zinc-Nickel with
Black Chromate
Z1
Stainless Steel / Passivated
© 2006 Glenair, Inc.
CAGE Code 06324/0CA77
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
C-10
E-Mail: sales@glenair.com
Series 800 “Mighty Mouse”
Original UNF Threaded Coupling
Series 800 PCB Jam Nut Receptacles
.725 (18.4) mAX
.460 (11.7)
ØA
.125 (3.2) SHELL SIZE 5 & 6
.168 (4.27) SHELL SIZE 7 THRU 12
ø .022/.018 (.56/.46)
C FLAT
A
B
C
D
E
F
B FLATS
D THREAD
.125 (3.2) MAX
PANEL THICKNESS
SHELL SIZE 5 & 6
.100 (2.5) MAX
PANEL THICKNESS
SHELL SIZE 7 & UP
4X .025 (.64) STANDOFF
.050 (1.3) SHELL SIZE 5 & 6
.093 (2.4) SHELL SIZE 7 THRU 12
DIMENSIONS
Shell
Size
5
6
7
8
9
10
12
ØA
In.
.541
.610
.670
.775
.875
.980
1.062
ØB
mm.
13.74
15.49
17.02
19.69
22.23
24.89
26.97
C
mm.
12.70
14.27
16.13
18.67
20.47
23.88
25.04
In.
.500
.562
.635
.735
.806
.940
.986
In.
.285
.352
.411
.473
.530
.604
.712
mm.
7.24
8.94
10.44
12.01
13.46
15.34
18.08
D Threads
Mating
.3125-28 UN-2A
.3750-28 UN-2A
.4375-28 UNEF-2A
.5000-32 UN-2A
.5625-32 UN-2A
.6250-32 UN-2A
.7500-28 UN-2A
G
H
J
K
L
SERIES 800 KEY POSITIONS
60°
60°
SERIES 800 PANEL CUTOUTS
øB
Z°
Y°
NORMAL
X°
Z°
Y°
X°
NORMAL
A
FLAT
Plug Key Position
Receptacle Key Position
Key Position
Normal (N)
X
Y
Z
Key Rotation
150°
140°
130°
120°
Shell
Size
5
6
7
8
9
10
12
A Flat
In.
.297 / .292
.365 / .360
.429 / .424
.483
.540
.614
.722
mm.
7.54 / 7.42
9.27 / 9.14
10.90 / 10.77
12.27
13.72
15.60
18.38
In.
.318
.386
.449
.510
.574
.635
.760
øB
mm.
8.08
9.80
11.40
12.95
14.58
16.12
19.30
M
N
P
Shell size 5 and 6: master key is located at top dead center for
normal (N) position. Shell size 7 thru 12: master key is rotated 90°
from TDC for normal position.
© 2006 Glenair, Inc.
CAGE Code 06324/0CA77
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
C-11
E-Mail: sales@glenair.com
Series 800
B
C
D
E
F
G
H
J
K
Key Position
M
N
P
Series 800
Series 800 “Mighty Mouse”
Original UNF Threaded Coupling
A
ØC
Series 800 PCB Square Flange Receptacles
