60123-3: DescriptionTerminal, 0.5 mm2, BRASS, TIN FINISH, RING TERMINAL, ROHS COMPLIANT; CategoryThe connector terminals; File Size119KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

60123-3 Overview

Terminal, 0.5 mm2, BRASS, TIN FINISH, RING TERMINAL, ROHS COMPLIANT

60123-3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Manufacturer's serial number	60123
Terminal and terminal strip types	RING TERMINAL
Conductor cross section	0.5 mm2
Wire gauge	20 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Product Feature Selector

> Product Details

60123-3 Product Details

Live Product Chat

Product View

Ring and Spade Tongue Terminals

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

60123-3

T E I nternal N umber: 6 0 1 2 3 - 3

Product Highlights:

Terminal Shape = Ring Tongue

Receptacle Style = Straight

Barrel Type = Open Barrel

Wire/C able Type = Regular Wire

Wire Range = 0.12-0.50² [26-20] mm [AWG]

View all Features

Obsolete

C ontact Product Information C enter

View 3D PDF

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

RING

(PDF, English)

Catalog Pages/Data Sheets:

MAC HINE APPLIED TERMINATIONS, OPEN BARREL

(PDF, English)

Product Specifications:

Terminal, AMPLIVAR, Ring, C rimping

(PDF, English)

Terminal, Ring, Extruded, C rimping

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version K)

3D Model

(IGES, Version K)

3D Model

(STEP, Version K)

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Terminal Shape

= Ring Tongue

Receptacle Style

= Straight

Barrel Type

= Open Barrel

Wire/C able Type

= Regular Wire

Insulation

= No

Insulation Support

= Insulation Support

Insulation Diameter (mm [in])

= 1.22-1.98 [.048-.078]

Stud Size = None

Stud Diameter (mm [in])

= 3.60 [0.142]

Shape

= RING-003

Heavy Duty

= No

Material

= Brass

Finish

= Tin

Body Related Features:

Wire Range (mm [AWG])

= 0.12-0.50² [26-20]

Stock Thickness (mm [in]) = 0.51 [0.020]

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was RoHS compliant

Packaging Related Features:

Packaging Method

= Strip

Packaging Quantity = 8000/Reel

Other:

Brand = AMP

Additional Information:

Product Line Information
