PS5023-100: DescriptionSMD Power Inductors Unshielded; File Size1MB，8 Pages; ManufacturerPREMO; Websitehttp://www.grupopremo.com

Download Datasheet View All

PS5023-100 Overview

SMD Power Inductors Unshielded

Preview

Download Datasheet

View All

PS5009 , PS5014 , PS5017 ,               

PS5023 

 PS6011

                                     SMD Power Inductors Unshielded

C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain)

Phone

+34 951 231 320 Fax +34 951 231 321

E-mail:

mar.villarrubia@grupopremo.com

Web http://www.grupopremo.com

1. Configuration & Dimensions

PS5009, PS5014 & PS6011

PS5017 & PS5023

Series

PS5009

PS5014

PS5017

PS5023

PS6011

Dimensions [mm]

5.60±0.3

6.80±0.3

6.00±0.3

5.60±0.3

7.50±0.3

0.95±0.1

1.45±0.1

1.90±0.2

2.50±0.2

1.05±0.1

D(typ.)

1.00

1.20

E(typ.)

5.20

6.70

F(typ.)

3.20

4.00

G(ref.)

0.80

1.10

H(ref.)

1.30

1.40

I(ref.)

2.00

2.60

J(ref.)

6.40

7.90

K(ref.)

4.60

5.40

L(ref.)

1.30

1.50

M(ref.)

3.80

4.90

2. Schematic Diagram

SMD Power Inductors                                                  
