assuredcommunications
™
RF-5850-PS001
RF-5850-PS002
POWER SUPPLY /
BATTERY ELIMINATOR
RF-5850-PS001
The RF-5850-PS Power Supply/Battery Eliminator family
may be used to power any of the FALCON
®
II manpack
transceivers:
The RF-5850-PS001 model mates with the wider body
radios: the RF-5800H-MP, RF-5800M-MP, RF-5800U-MP,
AN/PRC-150(C) and AN/PRC-117F(C).
The RF-5850-PS002 model mates with the narrow body
radios: RF-5800V-MP and RF-5800R-RC Remote Control
Unit.
The RF-5850-PS mounts to the radio in place of the
battery box and operates on 85 to 270 VAC, or 9 to 36
VDC. An internal battery (PS001 only) permits radio
operation for short periods of time (less then one hour)
without external power. The internal battery is charged
when external power is reapplied.
The RF-5850-PS has three indicator lights to provide
operating status. An auxiliary power connector is
provided to power an external DC device such as an
amplified speaker. The unit is supplied with an AC power
cable with a US NEMA 5-15P plug and a DC power cable
with pigtail leads.
RF-5850-PS002
Specifications for the RF-5850
General
RF-5850-PS001 is used with
the RF-5800H-MP,
RF-5800M-MP,
RF-5800U-MP, AN/PRC-117F,
and AN/PRC-150(C) radios
RF-5850-PS002 is used with
the RF-5800V-MP radio or
the RF-5800R-RC Remote
Control Unit
Mechanical /
Environmental
Temperature
Size
Weight
Environmental
Protection
Operating: -40 to +70 º C
Storage: -40 to 85 º C
PS001: 6.00H x 9.53W x 2.98D
PS002: 5.35H x 6.36W x 2.96D
PS001: 3.75 lbs w/o battery
PS002: 3.12 lbs
Splash proof
Sand/dust proof (with connector
covers)
Input Voltage
Input Protection
85-270 VAC, 47-440 Hz single
phase; 9-36 VDC
MIL-STD-1275
(optional cable required for
overvoltage and reverse
polarity protection)
26.5 VDC
PS001 5.25 a continuous,
6.0 a peak
PS002 3.0 a continuous,
3.5 a peak
50 mVPP typical
Continuous short circuit, over-
voltage and over-temperature
protection
90-94% for DC input, 85% typical
for AC input at full load
Automatic Switchover due to loss
of power: AC to DC Input
DC to internal rechargeable
24V / 1.9 AH battery (PS001 only)
26 VDC, 1 amp nominal for
powering external accessories
Optional
Accessories
RF-5870-VM001
RF-5871-VM001
10513-0510-01
10513-0511-01
Shock Mount for mounting
RF-5850-PS001 with attached
radio
Shock Mount for mounting
RF-5850-PS002 with attached
radio
10ft DC input cable for
RF-5850-PS001 and PS002 with
slave HMMWV connector
6ft DC input cable for
RF-5850-PS001 and PS002 with
alligator clips. Contains 100 V
overvoltage and reverse polarity
protection
Output Voltage
Output
Noise and Ripple
Output Protection
Efficiency
Backup Power
Auxiliary Output
Specifications are subject to change without notice.
®
RF Communications Division | 1680 University Avenue | Rochester, NY USA 14610
www.harris.com
1-585-244-5830
assuredcommunications
™
© Copyright 2006 Harris Corporation 10/06 DS-298B
