79LV0832
8 Megabit (256K x 32-Bit)
Low Voltage EEPROM MCM
Memory
F
EATURES
:
• 256k x 32-bit EEPROM MCM
• R
AD
-P
AK
® radiation-hardened against natural
space radiation
• Total dose hardness:
- >100 krad (Si)
- Dependent upon orbit
• Excellent Single event effects
- SEL
TH
> 84.7 MeV/mg/cm
2
- SEU > 26.6 MeV/mg/cm
2
read mode
- SEU = 11.4 MeV/mg/cm
2
write mode
• High endurance
- 10,000 cycles/dword, 10 year data retention
• Page Write Mode: 2 X 128 dword page
• High Speed:
- 200 and 250 ns maximum access times
• Automatic programming
- 15 ms automatic Page/dword write
D
ESCRIPTION
:
Maxwell Technologies’ 79LV0832 multi-chip module (MCM)
memory features a greater than 100 krad (Si) total dose toler-
ance, dependent upon orbit. Using Maxwell Technologies’ pat-
ented radiation-hardened R
AD
-P
AK
® MCM packaging
technology, the 79LV0832 is the first radiation-hardened 8
megabit MCM EEPROM for space application. The 79LV0832
uses eight 1 Megabit high speed CMOS die to yield an 8
megabit product. The 79LV0832 is capable of in-system elec-
trical dword and page programmability. It has a 128 x 32 byte
page programming function to make its erase and write opera-
tions faster. It also features Data Polling and a Ready/Busy
signal to indicate the completion of erase and programming
operations. In the 79LV0832, hardware data protection is pro-
vided with the RES pin. Software data protection is imple-
mented using the JEDEC standard algorithm.
Maxwell Technologies' patented R
AD
-P
AK
® packaging technol-
ogy incorporates radiation shielding in the microcircuit pack-
age. It eliminates the need for box shielding while providing
the required radiation shielding for a lifetime in orbit or space
mission. In a GEO orbit, R
AD
-P
AK
®‘ provides greater than 100
krad (Si) radiation dose tolerance. This product is available
with screening up to MAxwell Technologies self-defined Class
K.
01.10.05 Rev 8
All data sheets are subject to change without notice
1
(858) 503-3300 - Fax: (858) 503-3301 - www.maxwell.com
©2005 Maxwell Technologies
All rights reserved.
Low Voltage 8 Megabit (256K x 32-Bit) EEPROM MCM
79LV0832
TYP
M
AX
7.0
7.0
45
38
3
°
C/W
T
ABLE
2. 79LV0832 A
BSOLUTE
M
AXIMUM
R
ATINGS
P
ARAMETER
Supply Voltage
Input Voltage
Package Weight
Thermal Impedance (RP and RT Packages; XP TBD)
Operating Temperature Range
Storage Temperature Range
1. V
IN
min = -3.0V for pulse width <50ns.
S
YMBOL
V
CC
V
IN
RP
RT
F
JC
T
OPR
T
STG
-55
-65
M
IN
-0.6
-0.5
1
U
NIT
V
V
Grams
125
150
°
C
°
C
T
ABLE
3. 79LV0832 R
ECOMMENDED
DC O
PERATING
C
ONDITIONS
P
ARAMETER
Supply Voltage
Input Voltage
RES_PIN
Operating Temperature Range
1. V
IL
min = -1.0V for pulse width < 50 ns
S
YMBOL
V
CC
V
IL
V
IH
V
H
T
OPR
M
IN
3.0
-0.3
1
2.2
V
CC
-0.5
-55
M
AX
3.6
0.8
V
CC
+0.3
V
CC
+1
125
U
NIT
V
V
V
V
°
C
Memory
T
ABLE
4. D
ELTA
L
IMITS1
P
ARAMETER
I
CC1A
I
CC2A
I
CC2C
I
LI
- ADDR, CE, OE, WE
V
ARIATION2
+/- 10 %
+/- 10 %
+/- 10 %
+/- 10 %
I
Lo
- D0 - D31
+/- 10 %
1. Delta limits are calculated from test data taken at preburn-in and post burn-in as
defined in MIL-STD-883
2. Specified value in Table 6
01.10.05 Rev 8
All data sheets are subject to change without notice
3
©2005 Maxwell Technologies
All rights reserved
Low Voltage 8 Megabit (256K x 32-Bit) EEPROM MCM
T
ABLE
6. 79LV0832 DC E
LECTRICAL
C
HARACTERISTICS
(V
CC
= 3.3V ±10%, T
A
= -55
TO
+125°C)
P
ARAMETER
Output Voltage
T
EST
C
ONDITION
S
YMBOL
S
UBGROUPS
M
IN
--
79LV0832
M
AX
0.4
0.4
--
--
U
NITS
V
V
V
V
V
V
OL
Data Lines: V
CC
Min, I
OL
= 2.1mA
1, 2, 3
RDY/BSY_Line: V
CC
Min, I
OL
= 12mA
V
OL
Data Lines: V
CC
Min, I
OH
= -400µ A
V
OH
RDY/BSY_Line: V
CC
Min, I
OH
= -12mA
V
OH
All Outputs: V
CC
Min, I
OH
=-100uA
1. All Inputs are tied to Vcc with a 5.5KW
resistor, except for RES which is 30KW.
2. For RES I
LI
=800uA max.
3. Only one CE active (low) at a time
2.4
2.4
V
CC
-0.3V
T
ABLE
7. 79LV0832 AC E
LECTRICAL
C
HARACTERISTICS FOR
R
EAD
O
PERATION 1
(V
CC
= 3.3V ±10%, T
A
= -55
TO
+125°C)
P
ARAMETER
Address Access Time CE = OE = V
IL
, WE = V
IH
-200
-250
Chip Enable Access Time OE = V
IL
, WE = V
IH
-200
-250
Output Enable Access TIme CE = V
IL
, WE = V
IH
-200
-250
Output Hold to Address Change CE = OE =V
IL
, WE = V
IH
-200
-250
Output Disable to High-Z
2
CE = V
IL
, WE = V
IH
-200
-250
CE = OE = V
IL
, WE = V
IH
-200
-250
RES to Output Delay CE = OE = V
IL
, WE = V
IH3
-200
-250
S
YMBOL
t
ACC
S
UBGROUPS
9, 10, 11
--
--
t
CE
9, 10, 11
--
--
t
OE
9, 10, 11
0
0
t
OH
9, 10, 11
0
0
9, 10, 11
t
DF
0
0
t
DFR
0
0
T
RR
9, 10, 11
0
0
525
550
300
350
ns
50
50
ns
ns
--
--
110
120
ns
200
250
ns
200
250
ns
M
IN
M
AX
U
NIT
ns
Memory
1. Test conditions: input pulse levels = 0.4V to 2.2V; input rise and fall times < 20 ns; output load = 1 TTL gate + 100 pF (including
scope and jig); reference levels for measuring timing = 0.8 V/1.8 V.
2. t
DF
and t
DFR
are defined as the time at which the output becomes an open circuit and data is no longer driven.
3. Guaranteed by design.
01.10.05 Rev 8
All data sheets are subject to change without notice
5
©2005 Maxwell Technologies
All rights reserved
