ACTIVE (DIGITAL) DELAY LINES
A01 SERIES
(SINGLE DELAY)
A03 SERIES
(TRIPLE DELAY)
RESISTORS
#
CAPS & COILS
#
DELAY LINES
A03
FEATURES
!
Economical cost, prompt delivery!
!
Wide range of values, 10nS to 500nS.
!
TTL compatible
!
Operating temperature: 0°C to 70°C
!
Single output SIP delay line now available--
consult factory for data sheet on SA01 Series
Low cost solution for single or triple delays!
RCD’s digital delay lines have been designed to provide precise fixed delays
with all the necessary drive and pick-off circuitry. All inputs and outputs are
schottky-type and require no additional components to achieve specified de-
lays. Encapsulated construction utilizes a molded DIP case designed to meet
or exceed all applicable environmental requirements of MIL-D-23859. Type
A01 features a single fixed delay time, whereas type A03 features three iso-
lated delays.
OPTIONS
!
Non-standard delay times
!
ECL and high speed CMOS available
!
Increased operating temperature range
!
Tighter tolerances, faster rise times
!
Trailing edge measurement
!
Low power design
!
Military screening per MIL-D-83532
TYPE A01 - STANDARD
(Also available in SIP package)
.015[.38]
Min.
.120[3.05]
Min.
"
←
.800[20.3] Max.
→
↓
.295[7.5]
Max.
14
VCC
1
IN
.400[10.2]
Max.
R
8 Output
TYPE A01 Single Delay Line
Delay Time (nSec)
10±1.5
20±1.5
30±2
40±2
50±2.5
60±3
70±3.5
80±4
90±4.5
100±5
125±6.2
150±7.5
175±8.7
200±10
250±12.5
300±15
350±17.5
400 ±20
450±22.5
500±25
Rise Time (Max.)
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
5nS
5nS
↑
↓
←
.600±.010
→
[12.7±.254]
↑
↑
↓
.300±.010
[7.62±.254]
7
G
↑
TYPE A01S - MINIATURE
(Also available in a molded
auto-insertable design)
.015[.38]
Min.
.120[3.05]
Min.
"
←
.500[12.7]
Max.
→
↑
.295[7.5] Max.
↓
VCC
8
5 Output
↑
↓
.300±.010
[7.62±.254]
.300±.010
←
→
[7.62±.254]
1
IN
.400[10.2]
Max.
↑
↓
4
G
R
↑
TYPE A03 - TRIPLE DELAY -
(Also available in double
.015[.38]
Min.
.120 [3.05]
Min.
"
TYPE A03 Triple Delay Line
Delay Time (nSec)*
10±1.5
20±1.5
30±2
40±2
50±2.5
60±3
70±3.5
80±4
90±4.5
100±5
* Available up to 250nS on special order.
←
.800[20.3] Max.
→
↑
.295 [7.5] Max.
↓
and quadruple delays)
Rise Time (Max.)
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
4nS
A01
-
100nS - B
(IN)
1
(OUT)
12
(IN)
3
(OUT)
10
(IN)
5
(OUT)
8
↑
↓
.300±.010
[7.62±.254]
←
→
.600±.010
[15.2±.254]
→
←
.200[5.1] Typ.
↑
↓
(VCC)
14
7
(GND)
.400 [10.2]
Max.
↑
TEST CONDITIONS @25°C
1.) Input test pulse voltage: 3.2V
2.) Input pulse width: 3x the total delay
3.) Input rise time: 2.0nSec
4.) Delay measured at 1.5V on leading edge only with no loads on output.
5.) Rise time measured from 0.75V to 2.4V.
6.) Pulse period: 3x pulse width minimum
P/N DESIGNATION:
RCD Type
(A01, A01S, A03)
Delay Time
Packaging:
B=Bulk
RCD Components Inc.,
520 E. Industrial Park Dr., Manchester, NH, USA 03109
Tel: (603) 669-0054 Fax:(603) 669-5455 E-mail: sales@rcdcomponents.com
www.rcdcomponents.com
FA specifications subject to change without notice
