Shielded Power Inductors – MSS7341T
• Designed for high ambient temperatures – up to 125°C
• AEC-Q200 Grade 1 qualified
• Low DCR and excellent current handling
Core material
Ferrite
Environment
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over phos
bronze. Other terminations available at additional cost.
Weight:
0.61 – 0.67 g
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C
to +165°C with derated current
Storage temperature
Component: –40°C to +165°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
300/7″ reel; 1200/13″ reel; Plastic tape: 16 mm wide,
0.35 mm thick, 12 mm pocket spacing, 4.5 mm pocket depth
PCB washing
Only pure water or alcohol recommended
ERATURE
HIGH TEMP
Document 725-1
Part number
1
MSS7341T-332NL_
MSS7341T-502NL_
MSS7341T-622NL_
MSS7341T-742NL_
MSS7341T-872NL_
MSS7341T-103ML_
MSS7341T-123ML_
MSS7341T-153ML_
MSS7341T-183ML_
MSS7341T-223ML_
MSS7341T-273ML_
MSS7341T-333ML_
MSS7341T-393ML_
MSS7341T-473ML_
MSS7341T-563ML_
MSS7341T-683ML_
MSS7341T-823ML_
MSS7341T-104ML_
MSS7341T-224ML_
MSS7341T-474KL_
Inductance
2
(µH)
3.3 ±30%
5.0 ±30%
6.2 ±30%
7.4 ±30%
8.7 ±30%
10 ±20%
12 ±20%
15 ±20%
18 ±20%
22 ±20%
27 ±20%
33 ±20%
39 ±20%
47 ±20%
56 ±20%
68 ±20%
82 ±20%
100 ±20%
220 ±20%
470 ±10%
DCR (Ohms)
typ
max
0.016
0.020
0.017
0.024
0.024
0.027
0.027
0.031
0.029
0.034
0.032
0.038
0.043
0.053
0.047
0.057
0.062
0.078
0.074
0.082
0.091
0.109
0.104
0.124
0.114
0.138
0.127
0.155
0.174
0.202
0.220
0.276
0.239
0.324
0.281
0.358
0.654
0.780
1.21
1.45
SRF typ
3
(MHz)
85
49
42
35
33
32
27
26
25
22
19
17
15
14
11
9.6
8.5
7.2
5.0
3.0
10% drop
2.8
2.4
2.1
2.0
1.8
1.7
1.6
1.4
1.3
1.2
1.0
0.94
0.86
0.80
0.72
0.64
0.57
0.54
0.39
0.27
Isat
(A)
4
20% drop
3.4
2.8
2.5
2.3
2.1
2.0
1.8
1.7
1.5
1.4
1.2
1.1
1.0
0.95
0.86
0.76
0.68
0.64
0.47
0.32
Irms
(A)
5
30% drop 20°C rise 40°C rise
3.7
3.95
5.00
3.1
3.40
4.70
2.7
3.05
4.30
2.6
2.80
4.10
2.3
2.80
3.90
2.2
2.80
3.80
2.0
2.45
3.30
1.8
2.05
3.00
1.6
1.85
2.65
1.5
1.70
2.35
1.3
1.50
2.10
1.2
1.50
1.95
1.1
1.50
1.90
1.0
1.50
1.85
0.94
1.25
1.60
0.83
1.00
1.35
0.74
1.00
1.25
0.70
0.90
1.15
0.51
0.57
0.78
0.35
0.43
0.57
1. When ordering, please specify
termination
and
packaging
codes:
MSS7341T-104MLD
Termination: L
= RoHS compliant matte tin over nickel over phos bronze.
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5)
over gold over nickel over phos bronze or
S
= non-RoHS tin-lead (63/37) over gold over nickel
over phos bronze.
Packaging: D
= 13″ machine-ready reel.
EIA-481 embossed plastic
tape (1200 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge),
use code letter D instead.
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc using a Coilcraft
SMD A fixture in an Agilent/HP 4263B LCR meter.
-
3. SRF measured using an Agilent/HP 8753D network analyzer and a
Coilcraft SMD-D test fixture.
4. DC current at which the inductance drops the specified amount from its
value without current.
5. Current that causes the specified temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 725-1
Revised 04/04/11
© Coilcraft, Inc. 2011
