TCD WIDEBAND DELAY LINE MODULES

Preview

Download Datasheet

View All

TCD WIDEBAND DELAY LINE

MODULES

General Characteristics

The TCD Wideband Delay Modules are fixed delay lines i.e. they provide a fixed amount of delay for a given

impedance. The SCD modules contain a number of sections of delay which, using a suitable switching arrangement,

can be cascaded together or selected individually.

In general (for a given size delay module) the higher the input/output impedance the lower the delay - but bandwidth is

increased and delay variation over the band is less; for lower input/output impedance the opposite is true but more delay

is packed into a smaller area.

PART NUMBER

Drawing no.

No. of S.I.L.

Pins

(0.1” pitch)

Impedance

IN/OUT

Total Delay for

module

3dB

Bandwidth

TCD075M07

TCD037B07

SCD150E16

SCD100B24

SCD075A32

SCD100A32

SCD075A8X4

SCD050C48

SCD075A48

SCD037D64

SCD050D70

DR00165

TBD

DR00340

TBD

DR00347

TBD

DR00346

75 ohms

37.5 ohms

150 ohms

100 ohms

75 ohms

100 ohms

75 ohms

50 ohms

75 ohms

37.5 ohms

50 ohms

7ns

14ns

16ns

24ns

32ns

in 8x4ns

sections

48ns

64ns

70ns

300 MHz

150 MHz

200 MHz

150MHz

100 MHz

100MHz

100 MHz

75 MHz

50 MHz

3dB bandwidth codes

M = 300MHz

E = 200MHz

B= 150MHz

A = 100MHz

C=75MHz

D=50MHz

Fara351d

Page 1 of 2

Oct-05(A)
