IllumInatIon
luXEon 5050
High efficacy and superior robustness
in a multi-die, high power package,
enabling cost-effective system design
LUXEON 5050 is a multi-die, high power package that provides high
luminance from a super robust package to enable cost effective, single
optic and directional fixture designs. LUXEON 5050 uses an industry
standard 5050 surface mount package with a small Light Emitting Surface
(LES). LUXEON 5050 comes in 70CRI, 80CRI and 90CRI with a wide range
of CCTs, and offers hot-color targeting to ensure that the LEDs are within
color target at application conditions of 85°C.
FEaturEs and BEnEFIts
Superior lm/W enables outstanding efficacy in end application
Extremely reliable package design affirms long lifetime in harsh environments
[1]
Two voltage configurations are compatible with low cost high efficacy drivers
Low R
th
enables effective thermal dissipation design for higher efficiency
Hot-color targeting ensures color is within ANSI bin at 85°C
3-step and 5-step MacAdam ellipse binning structure ensures excellent
color uniformity
1.
Refer to reliability datasheet for more details.
PrImary aPPlIcatIons
High Bay
Low Bay
Floodlights
Wall Pack
More…
DS174 LUXEON 5050 Product Datasheet ©2019 Lumileds Holding B.V. All rights reserved.
No. E352519
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electrical and Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Spectral Power Distribution Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Forward Current Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Radiation Pattern Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Product Bin and Labeling Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Decoding Product Bin Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Luminous Flux Bins
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Color Bin Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Reflow Soldering Guidelines
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
JEDEC Moisture Sensitivity
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Pocket Tape Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Reel Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
DS174 LUXEON 5050 Product Datasheet 20190825 ©2019 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON 5050 LEDs are tested with a 20ms monopulse specified below at a junction temperature, T
j
, of 25°C. Forward voltage
and luminous flux are binned at a T
j
of 25°C, while color is hot-targeted at a T
j
of 85°C.
160mA
640mA
800mA
–
–
–
LUXEON 5050 (Round LES) – 24V and LUXEON 5050 (Square LES) – 30V
LUXEON 5050 (Round LES) – 6V
LUXEON 5050 (Square LES) – 6V
Part Number Nomenclature
Part numbers for LUXEON 5050 follow the convention below:
L 1 5 0 –
A A B B
5 0
C C
0 0 0
D
0
Where:
A A
–
designates nominal ANSI CCT (22=2200K, 27=2700K, 30=3000K, 35=3500K 40=4000K, 50=5000K,
57=5700K, 65=6500K)
B B
–
C C
–
D
–
designates minimum CRI (70=70CRI, 80=80CRI, 90=90CRI)
designates voltage (06=6V, 24=24V, 30=30V)
designates product type (0=Round LES, S=Square LES)
Therefore, the following part number is used for a LUXEON 5050 Square LES, 3000K 80CRI, 30V:
L 1 5 0 –
3 0 8 0
5 0
3 0
0 0 0
S
0
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the long-
term performance of this product.
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON 5050 is
compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely the
RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the following restricted
materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated
diphenyl ethers (PBDE).
DS174 LUXEON 5050 Product Datasheet 20190825 ©2019 Lumileds Holding B.V. All rights reserved.
2
Performance Characteristics
Product Selection Guide
Table 1. Product performance of LUXEON 5050 at specified test current, T
j
=25°C .
Product
nomInal
cct
[1]
2200K
2700K
3000K
3500K
4000K
5000K
5700K
6500K
2200K
LUXEON 5050
(Round LES)
24V
2700K
3000K
3500K
4000K
5000K
5700K
6500K
2700K
3000K
3500K
4000K
5000K
5700K
2200K
2700K
3000K
3500K
4000K
5000K
5700K
6500K
2200K
LUXEON 5050
(Round LES)
6V
2700K
3000K
3500K
4000K
5000K
5700K
6500K
2700K
3000K
3500K
4000K
5000K
5700K
mInImum
crI
[2, 3]
70
70
70
70
70
70
70
70
80
80
80
80
80
80
80
80
90
90
90
90
90
90
70
70
70
70
70
70
70
70
80
80
80
80
80
80
80
80
90
90
90
90
90
90
lumInous FluX
[2, 3]
(lm)
mInImum
515
535
553
600
580
580
570
570
440
500
516
527
539
539
539
539
414
428
445
456
456
456
515
535
553
600
580
580
570
570
440
500
516
527
539
539
539
539
414
428
445
456
456
456
tyPIcal
550
605
625
635
655
655
650
650
475
550
590
595
615
615
615
615
475
490
510
530
530
530
550
605
625
635
655
655
650
650
475
550
590
595
615
615
615
615
475
490
510
530
530
530
tyPIcal lumInous
EFFIcacy (lm/W)
140
154
159
162
167
167
166
166
121
140
151
152
157
157
157
157
121
125
130
135
135
135
140
154
159
162
167
167
166
166
121
140
151
152
157
157
157
157
121
125
130
135
135
135
tEst
currEnt
(ma)
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
160
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
640
Part numBEr
L150-2270502400000
L150-2770502400000
L150-3070502400000
L150-3570502400000
L150-4070502400000
L150-5070502400000
L150-5770502400000
L150-6570502400000
L150-2280502400000
L150-2780502400000
L150-3080502400000
L150-3580502400000
L150-4080502400000
L150-5080502400000
L150-5780502400000
L150-6580502400000
L150-2790502400000
L150-3090502400000
L150-3590502400000
L150-4090502400000
L150-5090502400000
L150-5790502400000
L150-2270500600000
L150-2770500600000
L150-3070500600000
L150-3570500600000
L150-4070500600000
L150-5070500600000
L150-5770500600000
L150-6570500600000
L150-2280500600000
L150-2780500600000
L150-3080500600000
L150-3580500600000
L150-4080500600000
L150-5080500600000
L150-5780500600000
L150-6580500600000
L150-2790500600000
L150-3090500600000
L150-3590500600000
L150-4090500600000
L150-5090500600000
L150-5790500600000
Table 1 continued on next page:
1. Correlated color temperature is hot targeted at T
j
=85°C.
2.
Luminous flux and CRI are based upon mounted package on highly reflective surface at T
j
=25°C. Typical CRI is approximately 2 points higher than the minimum CRI specified, but this
is not guaranteed.
3.
Lumileds maintains a tolerance of ±2 on CRI and ±7% on luminous flux measurements.
DS174 LUXEON 5050 Product Datasheet 20190825 ©2019 Lumileds Holding B.V. All rights reserved.
3
Table 1. Product performance of LUXEON 5050 at specified test current, T
j
=25°C, Continued.
Product
nomInal
cct
[1]
2200K
2700K
LUXEON 5050
(Square LES)
30V
3000K
3500K
4000K
5000K
5700K
6500K
2200K
2700K
LUXEON 5050
(Square LES)
6V
3000K
3500K
4000K
5000K
5700K
6500K
mInImum
crI
[2, 3]
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
lumInous FluX
[2, 3]
(lm)
mInImum
621
693
720
729
743
743
738
720
621
693
720
729
743
743
738
720
tyPIcal
690
770
800
810
825
825
820
800
690
770
800
810
825
825
820
800
tyPIcal lumInous
EFFIcacy (lm/W)
141
158
164
166
169
169
168
164
141
158
164
166
169
169
168
164
tEst
currEnt
(ma)
160
160
160
160
160
160
160
160
800
800
800
800
800
800
800
800
Part numBEr
L150-22705030000S0
L150-27705030000S0
L150-30705030000S0
L150-35705030000S0
L150-40705030000S0
L150-50705030000S0
L150-57705030000S0
L150-65705030000S0
L150-22705006000S0
L150-27705006000S0
L150-30705006000S0
L150-35705006000S0
L150-40705006000S0
L150-50705006000S0
L150-57705006000S0
L150-65705006000S0
Notes for Table 1:
1. Correlated color temperature is hot targeted at T
j
=85°C.
2.
Luminous flux and CRI are based upon mounted package on highly reflective surface at T
j
=25°C. Typical CRI is approximately 2 points higher than the minimum CRI specified, but this
is not guaranteed.
3.
Lumileds maintains a tolerance of ±2 on CRI and ±7% on luminous flux measurements.
Optical Characteristics
Table 2. Optical characteristics for LUXEON 5050 at test current, T
j
=25°C .
Part numBEr
L150-xxxx50xx000x0
tyPIcal total IncludEd anglE
[1]
138°
tyPIcal VIEWIng anglE
[2]
116°
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured.
2.
Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
Electrical and Thermal Characteristics
Table 3. Electrical and thermal characteristics for LUXEON 5050 at test current, T
j
=25°C .
Part numBEr
L150-xxxx502400000
L150-xxxx500600000
L150-xxxx5030000S0
L150-xxxx5006000S0
ForWard VoltagE
[1]
(V
f
)
mInImum
23.5
5.8
29.0
5.8
tyPIcal
24.5
6.1
30.5
6.1
maXImum
26.5
6.6
32.0
6.6
tyPIcal tEmPEraturE
coEFFIcIEnt oF ForWard
VoltagE
[2]
(mV/°c)
-12
-3
-15
-3
tyPIcal thErmal
rEsIstancE—JunctIon
to soldEr Pad (°c/W)
2.4
2.4
1.4
1.4
Notes for Table 3:
1. Lumileds maintains a tolerance of ±1% on forward voltage measurements.
2. Measured between 25°C and 85°C.
DS174 LUXEON 5050 Product Datasheet 20190825 ©2019 Lumileds Holding B.V. All rights reserved.
4
京公网安备 11010802033920号
EEWORLD
