DESCRIPTION
RELEASED FOR PRODUCTION
ECN 3165: UPDATE DWG FORMAT
2
REVISIONS
4/4/02
1
DATE
CHANGED BY
DFP
D.GRIFFIN
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
1/21/08
D
D
.36 9.04
.95 24.08
.59 14.86
.50 12.70
C
CENTER PIN
M8 X 0.75
INTERNAL THREAD
.04 ID [1.00]
.22 ID [5.64]
FERRULE
C
RECOMMENDED CRIMP
FOR FERRULE
.213 5.41
B
B
NOTES:
A
MATERIAL:
BODY: BRASS
CENTER PIN: BRASS
INSULATOR: ACETAL
FINISH:
BODY: NICKEL PLATE
CENTER PIN: GOLD OVER NICKEL PLATE
APPROVALS
UNLESS OTHERWISE SPECIFIED,
DRAWN BY
DIMENSIONS ARE IN INCHES [mm]
D PARHAM
TOLERANCES TO BE:
.X .1 [2.5]
ANGLES 2 CHECKED BY
.XX .01 [.25]
T CLARK
.XXX .005 [.13]
OVERALL CABLE LENGTH TOL:
≤
60 [1524] +3 [76.2] / - 0
> 60 [1524] +5% / -0%
PROJ
APPROVED BY
C McCORMICK
DATE
CATEGORY
3/22/2002
3/25/2002
3/25/2002
SIZE
PRODUCT DESCRIPTION
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
COAXIAL
CONN FME M RG58 CRIMP
A
CONFIGURATION DETAILS OF
UNDIMENSIONED FEATURES
MAY VARY
SCALE: NONE CAD FILE:
A
43321
FSCM NO.
DWG. NO.
BAC8015
1
REV.
SHEET 1 OF 1
BAC8015.SLDDRW
B
8
7
6
5
4
3
2
