BQ2201PNN datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> BQ2201PNN

BQ2201PNN: DescriptionPower Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDIP8, PLASTIC, DIP-8; CategoryPower/power management The power supply circuit; File Size333KB，11 Pages; ManufacturerBenchmarq Microelectronics Inc

Download Datasheet Parametric Compare View All

BQ2201PNN Overview

Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDIP8, PLASTIC, DIP-8

BQ2201PNN Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Benchmarq Microelectronics Inc
package instruction	DIP, DIP8,.3
Reach Compliance Code	unknown
Other features	THRESHOLD VOLTAGE ARE 4.62 AND 4.37 VOLT
Adjustable threshold	YES
Analog Integrated Circuits - Other Types	POWER SUPPLY SUPPORT CIRCUIT
JESD-30 code	R-PDIP-T8
JESD-609 code	e0
Number of channels	1
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP8,.3
Package shape	RECTANGULAR
Package form	IN-LINE
power supply	5 V
Certification status	Not Qualified
Maximum supply current (Isup)	5 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL

Preview

Download Datasheet

View All

BQ2201PNN Related Products

	BQ2201PNN	BQ2201SNN	BQ2201SN	BQ2201PN	BQ2201S
Description	Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDIP8, PLASTIC, DIP-8	Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDSO8, SOIC-8	Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDSO8, SOIC-8	Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDIP8, PLASTIC, DIP-8	Power Management Circuit, CMOS, PDSO16,
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
JESD-30 code	R-PDIP-T8	R-PDSO-G8	R-PDSO-G8	R-PDIP-T8	R-PDSO-G16
JESD-609 code	e0	e0	e0	e0	e0
Number of terminals	8	8	8	8	16
Maximum operating temperature	85 °C	85 °C	70 °C	70 °C	70 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	SOP	SOP	DIP	SOP
Encapsulate equivalent code	DIP8,.3	SOP8,.25	SOP16,.4	DIP8,.3	SOP16,.4
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE	SMALL OUTLINE
power supply	5 V	5 V	5 V	5 V	5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum supply current (Isup)	5 mA	5 mA	5 mA	5 mA	5 mA
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V	5 V
surface mount	NO	YES	YES	NO	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE	GULL WING	GULL WING	THROUGH-HOLE	GULL WING
Terminal pitch	2.54 mm	1.27 mm	1.27 mm	2.54 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL
package instruction	DIP, DIP8,.3	SOIC-8	SOP, SOP16,.4	DIP, DIP8,.3	-
Other features	THRESHOLD VOLTAGE ARE 4.62 AND 4.37 VOLT	THRESHOLD VOLTAGE ARE 4.62 AND 4.37 VOLT	THRESHOLD VOLTAGE ARE 4.62 AND 4.37 VOLT	THRESHOLD VOLTAGE ARE 4.62 AND 4.37 VOLT	-
Adjustable threshold	YES	YES	YES	YES	-
Analog Integrated Circuits - Other Types	POWER SUPPLY SUPPORT CIRCUIT	POWER SUPPLY SUPPORT CIRCUIT	POWER SUPPLY SUPPORT CIRCUIT	POWER SUPPLY SUPPORT CIRCUIT	-
Number of channels	1	1	1	1	-
Number of functions	1	1	1	1	-
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5.5 V	5.5 V	-
Minimum supply voltage (Vsup)	4.5 V	4.5 V	4.5 V	4.5 V	-
Base Number Matches	-	1	1	1	1
