Type SF
Motor-Run and Power Supply Capacitors
Oil Filled/Impregnated, AC Rated, Metallized Polypropylene Capacitors
Type SF, AC rated metallized polypropylene capacitors
provide starting torque and power factor correction for
split phase motors typically used in refrigeration and air
conditioning motor-run applications. Type SF also may
be used to provide noise suppression, voltage regulation
and line current reduction in power supply applications.
Highlights
Complies with the EU Directive
2002/95/EC requirement
restricting the use of Lead (Pb),
Mercury (Hg), Cadmium (Cd),
Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB)
and PolyBrominated Diphenyl
Ethers (PBDE).
•
•
•
•
Self healing
Fault current protection up to 10,000 amps AFC
Low energy consumption
4 - tine, 1/4” quick connect lug terminals are standard
•
•
•
Meets EIA Standard EIA-456-A
UL recognized File Number E71645
CSA File Number 223507
Specifications
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Temperature Range:
Dissipation Factor:
5.0 µF to 120.0 µF
240 Vac to 660 Vac
±10% standard, ± 6% and ±3% available
–40 ºC to 70 ºC standard, 90 ºC available
<0.1%
Service Life Objective
The service life objective for this series is 60,000 hours
of operating life with a 94% survival rate when operated
at full voltage, 60 Hz, and rated ambient temperature.
AC capacitors are frequently used at voltages and
ambient temperatures other than rated conditions.
Service life may be estimated under specific conditions
of temperature and voltage by using the curves as shown
below and to the right.
Capacitance vs. Temperature
The Capacitance vs. Temperature curve may be used
to determine the capacitance change as a function of
temperature. capacitance varies by no more than ±3%
over the operating temperature range.
Capacitance vs. Temperature
Capacitance Change %
4
2
0
–2
–4
–6
–40
–20
0
20
40
60
80 100
Life vs. Temperature
100000
10000
1000
100
10
0
25
50
75
100
125
% of Rated Life
Temperature °C
Life vs. Voltage
% of Rated Life
% of Rated Temperature
% of Rated Voltage
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.
cde.com
Type SF
Motor-Run and Power Supply Capacitors
Outline Drawing - Oval Case Style
Ratings
Cap.
(µF)
2.0
2.0
3.0
3.0
4.0
4.0
5.0
5.0
6.0
6.0
7.5
10.0
12.5
15.0
17.5
20.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
2.0
2.0
3.0
3.0
4.0
4.0
5.0
6.0
7.5
10.0
12.5
12.5
15.0
15.0
17.5
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
- Oval - RoHS Compliant
Dimensions (Inches)
Case Code
A
B
C
D
A
1.31
1.56
1.91
1.97
B
2.16
2.69
2.91
3.66
H
See Ratings Table
See Ratings Table
See Ratings Table
See Ratings Table
Ratings
Cap.
(µF)
4.0
5.0
6.0
7.5
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
60.0
70.0
- Oval
Stock
Items
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Catalog
Part Number
SFA24S4K219B-F
SFA24S5K219B-F
SFA24S6K219B-F
SFA24S7.5K219B-F
SFA24S10K219B-F
SFA24S15K263B-F
SFA24S20K300B-F
SFC24S25K263B-F
SFC24S30K263B-F
SFC24S35K263B-F
SFC24S40K303B-F
SFC24S45K303B-F
SFC24S50K303B-F
SFC24S60K391B-F
SFC24S70K391B-F
Case
H
Code (inches)
A
A
A
A
A
A
A
C
C
C
C
C
C
C
C
2.19
2.19
2.19
2.19
2.19
2.63
3.00
2.63
2.63
2.63
3.03
3.03
3.03
3.91
3.91
240 Vac Oval 70°C Case Temperature
Stock
Catalog
Case
H
Items
Part Number
Code (Inches)
370 Vac Oval 70 °C Case Temperature
S
SFA37S2K219B-F
A
2.19
*
SFA37S2K156B-F
A
1.56
S
SFA37S3K219B-F
A
2.19
*
SFA37S3K156B-F
A
1.56
S
SFA37S4K219B-F
A
2.19
*
SFA37S4K156B-F
A
1.56
S
SFA37S5K219B-F
A
2.19
*
SFA37S5K156B-F
A
1.56
S
SFA37S6K219B-F
A
2.19
*
SFA37S6K156B-F
A
1.56
S
SFA37S7.5K219B-F
A
2.19
S
SFA37S10K288B-F
A
2.88
S
SFA37S12.5K288B-F
A
2.88
S
SFA37S15K288B-F
A
2.88
S
SFC37S17.5K291B-F
C
2.91
S
SFC37S20K291B-F
C
2.91
*
SFA37S20K375B-F
A
3.75
S
SFC37S25K291B-F
C
2.91
S
SFC37S30K291B-F
C
2.91
S
SFC37S35K291B-F
C
2.91
S
SFC37S40K391B-F
C
3.91
S
SFC37S45K391B-F
C
3.91
S
SFC37S50K391B-F
C
3.91
440 Vac Oval 70 °C Case Temperature
S
SFA44S2K203B-F
A
2.03
*
SFA44S2K156B-F
A
1.56
S
SFA44S3K209B-F
A
2.09
*
SFA44S3K156B-F
A
1.56
S
SFA44S4K209B-F
A
2.09
*
SFA44S4K156B-F
A
1.56
S
SFA44S5K219B-F
A
2.19
S
SFA44S6K288B-F
A
2.88
S
SFA44S7.5K288B-F
A
2.88
S
SFA44S10K375B-F
A
3.75
*
SFA44S12.5K375B-F
A
3.75
*
SFC44S12.5K291B-F
C
2.91
S
SFA44S15K375B-F
A
3.75
*
SFC44S15K291B-F
C
2.91
*
SFC44S17.5K291B-F
C
2.91
S
SFC44S20K391B-F
C
3.91
S
SFC44S25K391B-F
C
3.91
S
SFC44S30K391B-F
C
3.91
S
SFD44S35K391B-F
D
3.91
S
SFD44S40K391B-F
D
3.91
S
SFD44S45K391B-F
D
3.91
S
SFD44S50K391B-F
D
3.91
S
SFD44S55K391B-F
D
3.91
S
SFD44S60K391B-F
D
3.91
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.
cde.com
Type SF
Motor-Run and Power Supply Capacitors
Ratings
Cap.
(µF)
1.0
1.0
2.0
2.0
3.0
4.0
5.0
6.0
8.0
8.0
10.0
10.0
12.0
15.0
18.0
20.0
25.0
30.0
35.0
40.0
Stock
Items
S
*
S
*
S
S
S
S
S
*
S
S
S
S
S
S
S
S
S
S
- Oval
Catalog
Part Number
SFA66S1K156B-F
SFA66S1K219B-F
SFA66S2K156B-F
SFA66S2K219B-F
SFA66S3K288B-F
SFA66S4K288B-F
SFA66S5K375B-F
SFA66S6K375B-F
SFA66S8K475B-F
SFC66S8K291B-F
SFA66S10K475B-F
SFC66S10K291B-F
SFC66S12K391B-F
SFC66S15K391B-F
SFC66S18K391B-F
SFD66S20K391B-F
SFD66S25K391B-F
SFD66S30K391B-F
SFD66S35K491B-F
SFD66S40K491B-F
Case
H
Code (Inches)
A
A
A
A
A
A
A
A
A
C
A
C
C
C
C
D
D
D
D
D
1.56
2.19
1.56
2.19
2.88
2.88
3.75
3.75
4.75
2.91
4.75
2.91
3.91
3.91
3.91
3.91
3.91
3.91
4.91
4.91
Options
♦
660 Vac Oval 70 °C Case Temperature
Tinplated steel cans are standard. Aluminum
cases are available upon request.
Tighter capacitance tolerances such as ±3%
or ±6% are available.
+90 °C ratings are available for HID lighting
and power supply applications.
Discharge resistors are available.
Special terminal lugs such as 2 tines plus 1
fork lugs are available.
Dual capacitance values are available for 370
Vac and 440 Vac applications.
♦
♦
♦
♦
♦
Hardware and Brackets:
See Capacitor Hardware, page 5.000
Part Numbering System
SF
Series
SF
C
Case
B
= 1 1/2 Oval
D
= 2.0" Oval
37
AC Volt
37
= 370 Vac
66
= 660 Vac
S
Case Material
S
= Steel
T
= Aluminum
w/steel cover
A
= All Aluminum
35
Cap
7
= 7.0 µF
K
Tol. ±%
L
= ±3%
K
= ±10%
291
Can Height
238
= 2.38"
291
= 2.91"
388
= 3.88"
475
= 4.75"
488
= 4.88"
B
VAR
A
= 2 way 70ºC
B
= 4 way 70 ºC
C
= 2 way 90 ºC
D
= 4 way 90 ºC
E
= Dual 2,3,4 70 ºC
F
= Forks 70 ºC
G
= Forks 90 ºC
H
= Forks 100 ºC
J
= Forks, 70 ºC Res.
K
= Forks, 90 ºC Res.
L
= Forks 100 ºC Res.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.
cde.com
-F
RoHS
Compliant
-F
= Compliant
Blank
= Not
Compliant
A
= 1 1/4" Oval
24
= 240 Vac
C
= 1 3/4" Oval
44
= 440 Vac
35
= 35.0 µF
H
= ±6%
Type SF
Motor-Run and Power Supply Capacitors
Ratings - Round -
Cap
(µF)
2.0
3.0
5.0
7.5
10.0
12.5
15.0
17.5
20.0
25.0
30.0
35.0
40.0
Stock
Items
*
*
*
*
*
*
*
*
*
*
*
*
*
Catalog
Part Number
SFP66S2K238B-F
SFP66S3K238B-F
SFP66S5K238B-F
SFP66S7.5K288B-F
SFP66S10K288B-F
SFS66S12.5K288B-F
SFS66S15K375B-F
SFT66S17.5K391B-F
SFT66S20K391B-F
SFT66S25K491B-F
SFT66S30K491B-F
SFT66S35K491B-F
SFT66S40K491B-F
Case
Code
P
P
P
P
P
S
S
T
T
T
T
T
T
H
(Inches)
2.38
2.38
2.38
2.88
2.88
2.88
3.75
3.91
3.91
4.91
4.91
4.91
4.91
♦
♦
♦
♦
♦
Options
♦
Tinplated steel cans are standard. Aluminum
cases are available upon request.
Tighter capacitance tolerances such as ±3% or
±6% are available.
+90 °C ratings are available for HID lighting
and power supply applications.
Discharge resistors are available.
Special terminal lugs such as 2 tines plus 1
fork lug are available.
Dual capacitance values are available for 370
Vac and 440 Vac applications.
660 Vac Round 70°C Case Temperature
Hardware and Brackets:
See Capacitor Hardware, page 5.000
Part Numbering System
SF
Series
SF
C
Case
37
AC Volt
S
Case Material
35
Cap
7
= 7.0 µF
K
Tol. ±%
L
= ±3%
K
= ±10%
291
Can Height
B
VAR
-F
RoHS
Compliant
-F
= Compliant
Blank
= Not
Compliant
P
= 1 3/4" Round
24
= 240 Vac
S
= Steel
S
= 2.0" Round
37
= 370 Vac
T
= Aluminum
T
= 2 1/2" Round
44
= 440 Vac
X
= Other
w/steel cover
66
= 660 Vac
A
= All Aluminum
238
= 2.38"
A
= 2 way 70ºC
291
= 2.91"
B
= 4 way 70 ºC
388
= 3.88"
C
= 2 way 90 ºC
488
= 4.88"
E
= Dual 2,3,4 70 ºC
F
= Forks 70 ºC
G
= Forks 90 ºC
H
= Forks 100 ºC
J
= Forks, 70 ºC Res.
K
= Forks, 90 ºC Res.
35
= 35.0 µF
H
= ±6%
Z
= Special
475
= 4.75"
D
= 4 way 90 ºC
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.
cde.com
