BZX384-C30 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BZX384-C30

BZX384-C30: DescriptionZener Diode, 30V V(Z), 5%, 0.2W,; CategoryDiscrete semiconductor diode; File Size386KB，8 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

BZX384-C30 Overview

Zener Diode, 30V V(Z), 5%, 0.2W,

BZX384-C30 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Vishay
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode type	ZENER DIODE
Maximum dynamic impedance	80 Ω
JESD-609 code	e3
Number of components	1
Maximum operating temperature	175 °C
Maximum power dissipation	0.2 W
Nominal reference voltage	30 V
surface mount	YES
Terminal surface	Matte Tin (Sn)
Maximum voltage tolerance	5%
Working test current	2 mA

Preview

Download Datasheet

View All

NEW PRODUCT

BZX384-C2V4 THRU BZX384-C75

ZENER DIODES

SOD-323

.012 (0.3)

FEATURES

♦

Silicon Planar Power Zener Diodes

♦

The Zener voltages are graded according to the

international E 24 standard. Standard Zener voltage

tolerance is ±5%. Replace “C” with “B” for ±2% tolerance. Other

voltage tolerances and other Zener voltages are available upon

request.

max. .006 (0.15)

min. .010 (0.25)

.112 (2.85)

.100 (2.55)

.076 (1.95)

.065 (1.65)

Cathode Mark

Top View

max. .049 (1.25)

.059 (1.5)

.043 (1.1)

max. .004 (0.1)

MECHANICAL DATA

Case:

SOD-323 Plastic Package

Weight:

approx. 0.004 g

Dimensions are in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25°C ambient temperature unless otherwise specified.

SYMBOL

VALUE

UNIT

Zener Current

Power Dissipation at T

amb

= 25°C

Junction Temperature

Storage Temperature Range

NOTES:

(1) Device on fiberglass substrate, see layout.

tot

250

200

175

– 65 to +175

°C

SYMBOL

MIN.

TYP.

MAX.

UNIT

Thermal Resistance

Junction to Ambient Air

Forward Voltage

at I

= 10 mA

thJA

–

650

K/W

–

0.9

Volts

NOTES:

(1) Valid provided that electrodes are kept at ambient temperature

9/2/98
