PNP SILICON PLANAR MEDIUM POWER
HIGH GAIN TRANSISTOR
ISSUE 1 - JANUARY 1997
FEATURES
* V
CEO
= -40V
* 3 Amp Continuous Current
* 5 Amp Pulse Current
* Low Saturation voltage
* High Gain
ZTX1151A
C
B
E
E-Line
TO92 Compatible
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Peak Pulse Current
Continuous Collector Current
Base Current
Power Dissipation at T
amb
=25°C
Operating and Storage Temperature
Range
SYMBOL
V
CBO
V
CEO
V
EBO
I
CM
I
C
I
B
P
tot
T
j
:T
stg
VALUE
-45
-40
-5
-5
-3
-500
1
-55 to +200
UNIT
V
V
V
A
A
mA
W
°C
ZTX1151A
Transiant Thermal Resistance ( C/W)
180
160
140
120
100
80
D=0.2
D=0.5
tp
D=t1
tp
t1
1.0
Max Power Dissipation - (Watts)
D=1(D.C)
0.75
Am
tt
en
bi
em
0.50
ra
pe
tu
60
40
20
0
D=0.1
D=0.05
Single Pulse
re
0.25
0.1ms
1ms
10ms
100ms
1s
10s
100s
-40
0
40
80
120
160
200
Pulse Width
T -Temperature
(°C)
Transient Thermal Resistance
Derating curve
*ZETEX ZTX1151 Spice model Last revision 12/12/96
*
.MODEL
ZTX1151 PNP IS =1.7e-12 NF =1.004 ISE=1.02e-13 NE =1.55 BF =562
+
VAF=26.01 IKF=3.5 NR =.97 ISC= 1.5e-13 NC =1.3
+
BR =38 VAR=2.41 IKR=0.3 RE =25.37e-3 RB =250e-3
+
RC =25e-3 CJE=440e-12 CJC=160e-12 VJC=1.058
+
MJC= 0.5678 TF =0.8e-9 TR =55.5e-9
*
*
©1995 ZETEX PLC
The copyright in this model and the design embodied belong to Zetex PLC (“Zetex”). It is
supplied free of charge by Zetex for the purpose of research and design and may be used or
copied intact (including this notice) for that purpose only. All other rights are reserved. The
model is believed accurate but no condition or warranty as to its merchantability or fitness for
purpose is given and no liability in respect of any use is accepted by Zetex PLC, its
distributors or agents.
