LB-603-VF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> LB-603-VF

LB-603-VF: Description7 SEG NUMERIC DISPLAY, RED, 14.3 mm; CategoryLED optoelectronic/LED photoelectric; File Size933KB，4 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

LB-603-VF Overview

7 SEG NUMERIC DISPLAY, RED, 14.3 mm

LB-603-VF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Reach Compliance Code	compliant
color	RED
Configuration	COMMON ANODE, 3 DIGITS WITH DECIMAL POINT
Display height	14.3 mm
Maximum forward current	0.015 A
JESD-609 code	e1
Number of functions	3
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Optoelectronic device types	SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Terminal surface	TIN SILVER COPPER

Preview

Download Datasheet

View All

High efficiency, three-digit Numeric Display

LB-603 FP Series

The LB-603 FP series were designed to meet the need for

multi-digit numeric displays. These LED numeric displays

use GaAsP on GaP for the emitting material (with the

exception of green) and are housed in an epoxy resin

package. They are three-digit displays with a character

height of 14.3mm.

Dimensions

(Unit : mm)

37.5

12.5

1.3

14.3

18.0

12.5

1.3

8.0

Features

1) Height of character : 14.3mm.

2) The package surface is painted black and the segments

are colored the display color.

3) High efficiency reflectors are used to achieve a bright,

clear display.

0.5

(2.54)

(33.02)

Tolerance are

±0.2

unless otherwise noted :

Selection

guide

Emitting color

Common

Anode

Cathode

Red

LB-603VF

LB-603VP

Green

LB-603MF

LB-603MP

Pin

assignments

28 27 26 25 24 23 22 21 20 19 18 17 16 15

Digit 3 D.P3

2.5Min.

8.0

Pin No.

Function

Segment "e1"

Segment "d1"

Digit 1 Common

Segment "c1"

D.P1

Segment "e2"

Segment "d2"

Segment "c2"

D.P2

Segment "e3"

Segment "d3"

Segment "g3"

Segment "c3"

D.P3

Pin No.

Function

Segment "b3"

Segment "a3"

Segment "f 3"

Digit 3 Common

Digit 2 Common

Segment "b2"

Segment "a2"

Segment "g2"

Segment "f 2"

Segment "b1"

Segment "a1"

Digit 1 Common

Segment "f 1"

Segment "g1"

Digit 1 D.P1

Digit 2 D.P2

Pin No. 1 2 3 4

7 8

9 10 11 12 13 14

Equivalent

circuit (anode common)

Dig.1

3,26

COM

Dig.2

COM

Dig.3

COM

a1 b1 c1 d1 e1 f1 g1 D.P1

25 24 4 2 1 27 28 5

a2 b2 c2 d2 e2 f2 g2 D.P2

21 20 8 7 6 23 22 9

a3 b3 c3 d3 e3 f3 g3 D.P3

16 15 13 11 10 17 12 14

www.rohm.com

○

1/3

2011.03 - Rev.B

0.25

1.5

(15.24)

LB-603-VF Related Products

	LB-603-VF	LB-603-MF	LB-603-MP	LB-603-VP
Description	7 SEG NUMERIC DISPLAY, RED, 14.3 mm	7 SEG NUMERIC DISPLAY, GREEN, 14.3 mm	7 SEG NUMERIC DISPLAY, GREEN, 14.3 mm	7 SEG NUMERIC DISPLAY, RED, 14.3 mm
Is it lead-free?	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	compliant	compliant	compli
color	RED	GREEN	GREEN	RED
Configuration	COMMON ANODE, 3 DIGITS WITH DECIMAL POINT	COMMON ANODE, 3 DIGITS WITH DECIMAL POINT	COMMON ANODE, 3 DIGITS WITH DECIMAL POINT	COMMON ANODE, 3 DIGITS WITH DECIMAL POINT
Display height	14.3 mm	14.3 mm	14.3 mm	14.3 mm
Maximum forward current	0.015 A	0.02 A	0.02 A	0.015 A
JESD-609 code	e1	e1	e1	e1
Number of functions	3	3	3	3
Maximum operating temperature	75 °C	75 °C	75 °C	75 °C
Minimum operating temperature	-25 °C	-25 °C	-25 °C	-25 °C
Optoelectronic device types	SMART/NORMAL 7 SEG NUMERIC LED DISPLAY	SMART/NORMAL 7 SEG NUMERIC LED DISPLAY	SMART/NORMAL 7 SEG NUMERIC LED DISPLAY	SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Terminal surface	TIN SILVER COPPER	TIN SILVER COPPER	TIN SILVER COPPER	TIN SILVER COPPER
Maker	ROHM Semiconductor	ROHM Semiconductor	-	ROHM Semiconductor
