JS29F04G08BANB3: DescriptionFlash, 512MX8, 18ns, PDSO48, LEAD FREE, PLASTIC, TSOP1-48; Categorystorage storage; File Size2MB，54 Pages; ManufacturerNumonyx ( Micron ); Websitehttps://www.micron.com

Download Datasheet Parametric Compare View All

JS29F04G08BANB3 Overview

Flash, 512MX8, 18ns, PDSO48, LEAD FREE, PLASTIC, TSOP1-48

JS29F04G08BANB3 Parametric

Parameter Name	Attribute value
Maker	Numonyx ( Micron )
Parts packaging code	TSOP1
package instruction	TSOP1,
Contacts	48
Reach Compliance Code	unknown
ECCN code	3A991.B.1.A
Maximum access time	18 ns
JESD-30 code	R-PDSO-G48
JESD-609 code	e3
length	18.4 mm
memory density	4294967296 bit
Memory IC Type	FLASH
memory width	8
Number of functions	1
Number of terminals	48
word count	536870912 words
character code	512000000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	512MX8
Package body material	PLASTIC/EPOXY
encapsulated code	TSOP1
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Programming voltage	2.7 V
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	2.7 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	12 mm
