CHIP INDUCTOR
SPEER ELECTRONICS, INC.
KL32F
1210 SHIELDED
SHIELDED CHIP INDUCTORS
- Available March 1999
- Low Leakage Flux Inductor
- Suitable for High-Density Mounting
- Suitable for Low Voltage Applications
Due to Low DC Resistance
- Body Color: Brown
DIMENSIONS
DIMENSIONS
MM
INCH
L
3.2
±0.2
W
2.5
±0.2
Wt
1.7
±0.1
H
2.2
±0.2
Ht
1.9
±0.1
P
.05
nominal
.126
.098
.067
.087
.075
.02
±.008 ±.008 ±.004 ±.008 ±.004
nominal
STANDARD APPLICATIONS
TYPE
NOMINAL
INDUCTANCE
(mH)
100
150
220
330
470
680
1000
K ( +10%)
M ( +20%)
INDUCTANCE
TOLERANCE
QUALITY
FACTOR
MIN.
30
30
30
30
20
20
20
SELF RESONANT
FREQ.
MIN (MHz)
10
8
7
5
4
3
2.4
DC RESISTANCE
(W) + 30%
ALLOWABLE
MEASURING
DC CURRENT
FREQ.
MAX (mA)
(MHz)
IND.CHANGE TEMP. RISE
30
200
25
170
19
16
13.5
11
8
130
110
79
70
63
0.796
KL32FTE101
KL32FTE151
KL32FTE221
KL32FTE331
KL32FTE471
KL32FTE681
KL32FTE102
2.4
3.1
5.3
6.9
15.5
19
22
0.252
ORDERING & SPECIFYING INFORMATION*
KL
Type
32
Size Code
3.2x2.5x2.2
1210 Size
F
Application
Shielded
TE
Packaging
TE: Embossed Plastic
2000 pcs/reel
TDD: 10” Punched Paper
TED: 10” Embossed Plastic
101
Nominal Inductance
Value designation
same as marking on
Inductor Chip
K
Tolerance
K:
±10%
M:
±20%
*Please Note: KSE’s Part Numbers Do Not Contain any Spaces or Hyphens.
TELEPHONE:
814-362-5536
37
FAX:
814-362-8883
CHIP
INDUCTORS
