ZRT025C2: Description1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4; Categoryaccessories; File Size161KB，4 Pages; ManufacturerZetex Semiconductors; Websitehttp://www.zetex.com/

Download Datasheet Compare View All

ZRT025C2 Overview

1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4

Preview

Download Datasheet

View All

2.5V LOW POWER

PRECISION REFERENCE SOURCE

ISSUE 1 - OCTOBER 1995

DEVICE DESCRIPTION

The ZRT025 is a monolithic integrated circuit

providing a precise stable reference voltage

of 2.5V at 500µA.

The circuit features a knee current of 150µA

and operation over a wide range of

temperatures and currents.

The ZRT025 is available in a 3-pin metal can

package for through hole applications as

well as SOT223 and SO8 packages for

surface mount applications. Each package

option offers a trim facility whereby the

output voltage can be adjusted as shown in

F i g . 1. Thi s f a ci l i t y i s u sed w he n

compensating for system errors or setting

the reference output to a particular value.

When the trim facility is not used, the pin

should be left open circuit.

ZRT025

FEATURES

•

Trimmable output

Excellent temperature stability

Low output noise figure

Available in two temperature ranges

1 and 2% initial voltage tolerance

versions available

No external stabilising capacitor

required in most cases

Low slope resistance

No derating required at low

temperatures

TO18 package

SOT223 and SO8 small outline

packages

SCHEMATIC DIAGRAM

R=V

-V

=100k

(Optional trim facility)

This circuit will allow the reference to be

trimmed over a wide range. The device is

specified over a 5% trim range.

4-279

ZRT025C2 Related Products

	ZRT025C2	ZRT025N8C2	ZRT025N8C1	ZRT025N8A1	ZRT025GC1	ZRT025GA1	ZRT025A1	ZRT025C1
Description	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4	1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.5 V, PDSO4
Is it Rohs certified?	-	incompatible	incompatible	incompatible	conform to	conform to	-	-
Maker	-	Zetex Semiconductors	Zetex Semiconductors	Zetex Semiconductors	Zetex Semiconductors	Zetex Semiconductors	-	-
package instruction	-	SOP,	SOP,	SOP,	SOT-223, SMT-4	SOT-223, SMT-4	-	-
Reach Compliance Code	-	unknow	unknow	unknown	_compli	not_compliant	-	-
ECCN code	-	EAR99	EAR99	EAR99	EAR99	EAR99	-	-
Other features	-	OUTPUT VOLTAGE CAN BE ADJUSTED OVER A +/-5% TRIM RANGE	OUTPUT VOLTAGE CAN BE ADJUSTED OVER A +/-5% TRIM RANGE	OUTPUT VOLTAGE CAN BE ADJUSTED OVER A +/-5% TRIM RANGE	OUTPUT VOLTAGE CAN BE ADJUSTED OVER A +/-5% TRIM RANGE	OUTPUT VOLTAGE CAN BE ADJUSTED OVER A +/-5% TRIM RANGE	-	-
Analog Integrated Circuits - Other Types	-	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	TWO TERMINAL VOLTAGE REFERENCE	-	-
JESD-30 code	-	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDSO-G4	R-PDSO-G4	-	-
JESD-609 code	-	e0	e0	e0	e3	e3	-	-
length	-	4.89 mm	4.89 mm	4.89 mm	6.5 mm	6.5 mm	-	-
Humidity sensitivity level	-	1	1	1	1	1	-	-
Number of functions	-	1	1	1	1	1	-	-
Output times	-	1	1	1	1	1	-	-
Number of terminals	-	8	8	8	4	4	-	-
Maximum operating temperature	-	70 °C	70 °C	125 °C	70 °C	125 °C	-	-
Maximum output voltage	-	2.55 V	2.525 V	2.525 V	2.525 V	2.525 V	-	-
Minimum output voltage	-	2.45 V	2.475 V	2.475 V	2.475 V	2.475 V	-	-
Nominal output voltage	-	2.5 V	2.5 V	2.5 V	2.5 V	2.5 V	-	-
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	-	-
encapsulated code	-	SOP	SOP	SOP	LSOP	LSOP	-	-
Package shape	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	-
Package form	-	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, LOW PROFILE	-	-
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	260	260	-	-
Certification status	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-	-
Maximum seat height	-	1.75 mm	1.75 mm	1.75 mm	1.7 mm	1.7 mm	-	-
Maximum supply current (Isup)	-	75 mA	75 mA	75 mA	75 mA	75 mA	-	-
surface mount	-	YES	YES	YES	YES	YES	-	-
Maximum voltage temperature coefficient	-	50 ppm/°C	50 ppm/°C	50 ppm/°C	50 ppm/°C	50 ppm/°C	-	-
Temperature level	-	COMMERCIAL	COMMERCIAL	MILITARY	COMMERCIAL	MILITARY	-	-
Terminal surface	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Matte Tin (Sn)	Matte Tin (Sn)	-	-
Terminal form	-	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	-	-
Terminal pitch	-	1.27 mm	1.27 mm	1.27 mm	2.3 mm	2.3 mm	-	-
Terminal location	-	DUAL	DUAL	DUAL	DUAL	DUAL	-	-
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	40	40	-	-
Fine-tuning/adjustable output	-	YES	YES	YES	YES	YES	-	-
width	-	3.9 mm	3.9 mm	3.9 mm	3.5 mm	3.5 mm	-	-
