SM3E
ULTRA MINIATURE
STRATUM 3E MODULE
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630- 851- 4722
Fax: 630- 851- 5040
www.conwin.com
Application
The SM3E Timing Module is a
complete system clock module for
Stratum 3E timing applications and
conforms to GR-1244-CORE
(Issue 2), GR-253-CORE (Issue
3) and ITU-T G.812 (Option 3).
Applications include shared port
adapters, data digital cross
connects, ADM's, DSLAM's,
multiservice platforms, switches
and routers in TDM, SDH and
SONET environments.
The SM3E Timing Module
guarantees full Stratum 3E
compliance with a minimum of
effort and cost in the smallest
complete package available.
Features
Small Package Size,
2.05 x 1.25 x 0.75 inches
Eight Auto Select Input
References,
8 kHz - 77.76 MHz
Phase Buildout
Hitless Reference Switching
Better than 1ppb initial
Hold Over offset
Frequency Qualification and
Loss of Reference detection
for each input
Master/Slave Operation with
Phase Adjustment
Manual/Autonomous
Operation
Bi-Directional SPI Port
Control and Status
Reporting
Three CMOS Frequency
Outputs - Output1 from
1.544 - 77.76MHz, M/
S_Out@8KHz, BITS
@2.048 MHz or 1.544 MHz
3.3V operation
Bulletin
Page
Revision
Date
Issued By
TM054
1 of 36
02
07 Nov 08
ENG
General Description
The SM3E timing module provides a clock output that meets or exceeds Stratum 3E specifications given in GR-1244-CORE
(Issue 2), GR-253-CORE (Issue 3) and ITU-T G.812 (option 3). The SM3E features eight reference inputs. Each input will auto-
detect the following reference frequencies: 8 kHz, 1.544 MHz, 2.048 MHz, 12.96 MHz, 19.44 MHz, 25.92 MHz, 38.88 MHz, 51.84
MHz and 77.76 MHz.
The SM3E timing module can be configured during production to produce an output up to 77.76MHz. This output is derived
from an onboard VCXO and must be specified when ordering. The second output is a BITS output selectable for either 1.544 or
2.048 MHz. The master/slave output is 8KHz. The user communicates with the SM3E module through a SPI port. The user con-
trols the SM3E operation by writing to the appropriate registers. The user can also enable or disable SPI operation through a
SPI_Enable pin.
The SM3E offers a wide range of options for the system designer. The bandwidth is SPI Port-selectable from 0.00084 Hz to 1.6
Hz. 0.0016 Hz is the recommended operational bandwidth for Stratum 3E applications. The 8 kHz output has an adjustable pulse
width. The pull-in range is also adjustable to establish the desired reference frequency rejection limits. A Free Run frequency
calibration value can be written to the module to provide a high degree of accuracy in the free run mode. The reference frequency
for any given reference input is automatically detected. A wealth of status information is available through the SPI Port registers.
The user also has a choice between autonomous or full manual control operation.
In manual mode, the user controls the module operating modes Free Run, Hold Over or locked to a specific reference. If the
chosen reference is unavailable or disqualified the module automatically enters Hold Over.
In autonomous control mode, operational mode selection occurs automatically based on reference priority and qualification sta-
tus. When the active reference becomes disqualified, the module will switch to another qualified reference. If none is available, it will
switch to Hold Over. In the revertive mode the module will seek to acquire the highest priority qualified reference. In the non-
revertive mode the module will not return to the previous reference even after it is re-qualified unless there are no other qualified
references.
Switching between references is hitless. Likewise, the output frequency slew rate is minimized during any change of operating
mode, including entry into and return from Free Run or Hold Over to protect traffic from transient-induced bit errors.
Reference Status information and the operating mode information is accessed through status registers. The module will set the
Interrupt pin (SPI_INT) low to indicate a status change.
Free Run operation guarantees an output within 4.6ppm of nominal frequency and Hold Over operation guarantees the output
frequency will not change by more than 0.012ppm during the first 24 hours. Frequency accuracy is based on a precision oven to
provide the stabilty required for Stratum 3E compliance.
The SM3E can be programmed to startup in any mode or bandwidth. The module may even be programmed to operate in a
fully autonomous mode with no further configuration required.
The module operates on 3.3V ± 5% with a typical power drain of less than 3W at turn on, dropping to approximately 1W @ room
temperature after warming up. The module operates over the 0° to 70° C commercial temperature range.
Phase buildout can be enabled or disabled by means of the SPI port.
Functional Block Diagram
Figure 1
TRST
TCK
TDO
TDI
TMS
M/S Input
Ref 1 - 8
Reset
M/S
T1/E1
SPI_ENBL
SPI_Clk
SPI_In
SPI_Out
SPI_INT
Bus Interface
Reference Priority,
Revertivity and Mask
Table
8
Control
Mode
Reference
Selection
Reference Input Monitor
OCXO
EEPROM
DAC
VCXO
Output 1
M/S Output
BITS_Clk
DPLL
APLL
LOS
LOL
Hold_Good
Data Sheet #:
TM054
Page 2
of
36
Rev:
02
Date:
11/07/08
© Copyright 2008 The Connor-Winfield Corp. All Rights Reserved
Specifications subject to change without notice
Specifications for Ultra Miniature Stratum 3E
Table 1
Parameter
Voltage
Power
Reference Frequency 1 - 8
CMOS Output Frequency #1
M/S_Out
BITS_Clk
Master/Slave I/O
Input Reference Pulse Width
Free Run Accuracy
Hold Over Accuracy
Hold Over Stability
Dimensions
Specification
3.3V ± 5%
3W Maximum during start up, 1.5W Typical @ room temperature
8 kHz - 77.76 MHz (Determined by customer's application)
8 kHz - 77.76 MHz
8 kHz
1.544/2.048 MHz (Selectable)
8 kHz
10 ns Min @ 8 kHz, 5 ns Min @ >8 kHz
4.6 ppm
0.001 ppm
0.012 ppm for the first 24 hours
2.05 x 1.25 x 0.75 inches (52.07 x 31.75 x 19.05 mm)
Pin Description
Table 2
Pin #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
I
O
I/O
O
O
I
I
I
I
I
Pin Name
LOS
LOL
M/S REF
REF1
REF2
REF3
REF4
TDI
TMS
TRST
BITS_CLK
M/S_OUT
OUTPUT1
VPP
REF5
REF6
REF8
REF7
VPN
T1/E1
HOLD_GOOD
TDO
TCK
GND
SPI_CLK
SPI_IN
VCC
SPI_ENBL
RESET
SPI_OUT
SPI_INT
MASTER SELECT
Pin Description
Alarm output - Loss of Active Reference Signal
Alarm Output - Loss of Lock
Master/Slave 8 kHz reference input
Reference Input 1 – 8 kHz to 77.76 MHz auto detected
Reference Input 2 – 8 kHz to 77.76 MHz auto detected
Reference Input 3 – 8 kHz to 77.76 MHz auto detected
Reference Input 4 – 8 kHz to 77.76 MHz auto detected
JTAG TDI pin
JTAG TMS pin
JTAG TRST pin
1.544 or 2.048 MHz output selected by pin 14
Master/Slave 8 kHz output
Synchronous Primary Output
Positive Programming Supply Pin. During normal operation, It is
recommended to float this pin.
Reference Input 5 – 8 kHz to 77.76 MHz auto detected
Reference Input 6 – 8 kHz to 77.76 MHz auto detected
Reference Input 8 – 8 kHz to 77.76 MHz auto detected
Reference Input 7 – 8 kHz to 77.76 MHz auto detected
Negative Programming Supply Pin. During normal operation, It is
recommended to float this pin.
BITS_CLK select input – 1=1.544 MHz, 0=2.048 MHz
Holdover Good Output Flag – 1=Holdover Available
JTAG TDO pin
JTAG TCK pin
Module Ground
SPI Port Clock input
SPI Port Data input
3.3 Vdc VCC Supply Input
SPI Port Enable input – Active Low
Module Reset – Active Low
SPI Port Data Output
SPI Port Interrupt Output
Master/Slave select input – 1=Master, 0=Slave
O
O
O
I
I
I
I
O
O
I
Data Sheet #:
TM054
Page 3
of
36
Rev:
02
Date:
11/07/08
© Copyright 2008 The Connor-Winfield Corp. All Rights Reserved
Specifications subject to change without notice
Pin Diagram
Figure 2
SM3E
LOS
LOL
M/S REF
REF1
REF2
REF3
REF4
TDI
TMS
TRST
BITS_CLK
M/S_OUT
OUTPUT1
VPP
REF5
REF6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
MASTER SELECT
SPI_INT
SPI_OUT
RESET
SPI_ENBL
Vcc
SPI_IN
SPI_CLK
GND
TCK
TDO
HOLD_GOOD
T1/E1
VPN
REF7
REF8
(TOP VIEW)
25
24
23
22
21
20
19
18
17
Register Map
Table 3
Address
0x00
0x01
0x02
0x03
0x04
0x05
0x06
0x07
0x08
0x09
0x0a
0x0b
Reg Name
Chip_ID_Low
Chip_ID_High
Chip_Revision
Bandwidth_PBO
Ctl_Mode
Op_Mode
Max_Pullin_Range
M/S Input_Activity
Ref_Activity
Ref_Pullin_Sts
Ref_Qualified
Ref_Mask
Description
Low byte of chip ID
High byte of chip ID
Chip revision number
Bandwidth & Phase Build-Out option
Manual or automatic selection of Op_Mode,BITS clock output frequency
indication, and frame/multi-frame sync pulse width mode control
Master Free Run, Locked, or Hold Over mode, or Slave mode
Maximum pull-in range in 0.1 ppm units
Cross Reference activity
Activities of 8 reference inputs
In or out of pull-in range of 8 reference inputs
Qualification of 8 reference inputs
Availability mask for 8 reference inputs
Type
R
R
R
R/W
R/W
R/W
R/W
R
R
R
R
R/W
Data Sheet #:
TM054
Page 4
of
36
Rev:
02
Date:
11/07/08
© Copyright 2008 The Connor-Winfield Corp. All Rights Reserved
Specifications subject to change without notice
Register Map Continued
Table 3
0x0c
0x0d
0x0e
0x0f
0x10
0x11
0x12
0x13
0x14
0x15
0x16
0x17
0x18
0x19
0x1a
0x1b
0x1c
0x1d
0x1e
0x1f
0x20
0x21
0x22
0x23
0x24
0x25
0x26
0x27
0x30
0x31
0x32
0x33
0x35
0x37
0x38
0x39
Ref_Available
Ref_Rev_Delay
Phase_Offset
Calibration
Fr_Pulse_Width
DPLL_Status
Intr_Event
Intr_Enable
Ref1_Frq_Offset
Ref2_Frq_Offset
Ref3_Frq_Offset
Ref4_Frq_Offset
Ref5_Frq_Offset
Ref6_Frq_Offset
Ref7_Frq_Offset
Ref8_Frq_Offset
Ref1_Frq_Priority
Ref2_Frq_Priority
Ref3_Frq_Priority
Ref4_Frq_Priority
Ref5_Frq_Priority
Ref6_Frq_Priority
Ref7_Frq_Priority
Ref8_Frq_Priority
FreeRun Priority
History_Policy
History_CMD
HoldOver_Time
Cfgdata
Cfgctr_Lo
Cfgctr_Hi
Chksum
EE_Wrt_Mode
EE_Cmd
EE_Page_Num
EE_FIFO_Port
Availability of 8 reference inputs
Reference reversion delay time, 0 - 255 minutes
Phase offset between M/S REF & M/S Output (for the Slave in
M/S operation) in 250ps resolution
Local oscillator digital calibration in 0.05 ppm resolution
Frame sync pulse width
Digital Phase Locked Loop status
Interrupt events
Enable individual interrupt events
Ref1 frequency offset in 0.2 ppm resolution
Ref2 frequency offset in 0.2 ppm resolution
Ref3 frequency offset in 0.2 ppm resolution
Ref4 frequency offset in 0.2 ppm resolution
Ref5 frequency offset in 0.2 ppm resolution
Ref6 frequency offset in 0.2 ppm resolution
Ref7 frequency offset in 0.2 ppm resolution
Ref8 frequency offset in 0.2 ppm resolution
Ref1 frequency and priority
Ref2 frequency and priority
Ref3 frequency and priority
Ref4 frequency and priority
Ref5 frequency and priority
Ref6 frequency and priority
Ref7 frequency and priority
Ref8 frequency and priority
Control and Priority for designation of Free Run as a reference
Sets policy for Hold Over history accumulation
Save, restore and flush comands for Hold Over history
Indicates the time since entering Hold Over state
Configuration data write register
Configuration data write counter, low byte
Configuration data write counter, high byte
Configuration data checksum pass/fail indicator
Disables/Enables writing to the external EEPROM
Read/Write command & ready indication register for ext. EEPROM access
Page number for external EEPROM access
Read/Write data for external EEPROM access
R
R/W
R/W
R/W
R/W
R
R
R/W
R
R
R
R
R
R
R
R
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R/W
R
R
R
R/W
R/W
R/W
R/W
Data Sheet #:
TM054
Page 5
of
36
Rev:
02
Date:
11/07/08
© Copyright 2008 The Connor-Winfield Corp. All Rights Reserved
Specifications subject to change without notice
京公网安备 11010802033920号
EEWORLD
