IP 67 Com bina tion D -SU B C onne c t or s
IP67
Combination
D-SUB
Solid Body
Solder pin – Straight – Precision machined contacts
Description
High power contacts 20A
Mounting style:
4-40 UNC threaded rear spacer with PCB clip
Quality class 3 (also available in quality class 1)
One-piece zinc die-cast nickel plated shell
IP67 for harsh environments, pressure-proof up to 1.45 PSI
Stainless steel hex bolts are supplied loose
RoHS compliant – UL listed, File No.: E202784
Socket connector
Shellsize
1
2
3
4
Plug connector
A
39.40
47.70
61.40
78.00
+ 0.3
- 0
+ 0.3
- 0
+ 0.3
- 0
+ 0.3
- 0
B2
-0.25
16.46
24.79
38.50
54.96
C
25.00
33.32
47.04
63.50
+ 0.12
- 0.13
+ 0.13
- 0.12
± 0.13
± 0.13
Shellsize
1
2
3
4
A
39.40
-
47.70
61.40
+ 0.3
0
+ 0.3
- 0
+ 0.3
- 0
+ 0.3
0
B1
16.81
-
25.14
38.86
+ 0.23
0.02
+ 0.23
- 0.02
+ 0.23
- 0.02
+ 0.23
0.02
C
25.00
-
33.32
+ 0.12
0.13
+ 0.13
- 0.12
D
6.00
6.00
+ 0.12
- 0.18
+ 0.12
- 0.18
- 0.3
- 0.3
47.04
± 0.13
5.99
63.50
± 0.13
5.99
78.00
-
55.32
-
Shellsize 1-4
Shellsize 1-4
Order data
Socket connector
Design
2W2C
3W3C
3W3
5W5
8W8
Plug connector
Power contact Part number
High power 20A
High power 20A
High power 20A
High power 20A
High power 20A
15-001783
15-001793
15-001803
15-001813
15-002023
Mounting style 4-40 UNC
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Design
3W3C
3W3
5W5
8W8
Mounting style 4-40 UNC
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Threaded rear spacer PCB clip
Power contact Part number
High power 20A
High power 20A
High power 20A
High power 20A
15-005883
15-001843
15-001853
15-001833
Other high power or coaxial contacts on request.
