MMBZ5V6ALT1 Series
Preferred Device
24 and 40 Watt Peak Power
Zener Transient Voltage
Suppressors
SOT−23 Dual Common Anode Zeners
for ESD Protection
These dual monolithic silicon Zener diodes are designed for
applications requiring transient overvoltage protection capability. They
are intended for use in voltage and ESD sensitive equipment such as
computers, printers, business machines, communication systems,
medical equipment and other applications. Their dual junction common
anode design protects two separate lines using only one package. These
devices are ideal for situations where board space is at a premium.
Features
3
1
2
xxx
M
= Device Code
= Date Code
http://onsemi.com
1
3
2
MARKING
DIAGRAM
SOT−23
CASE 318
STYLE 12
•
Pb−Free Packages are Available
•
SOT−23 Package Allows Either Two Separate Unidirectional
•
•
•
•
•
•
•
Configurations or a Single Bidirectional Configuration
Working Peak Reverse Voltage Range − 3 V to 26 V
Standard Zener Breakdown Voltage Range − 5.6 V to 33 V
Peak Power − 24 or 40 Watts @ 1.0 ms (Unidirectional),
per Figure 5 Waveform
ESD Rating of Class N (exceeding 16 kV) per the Human
Body Model
Maximum Clamping Voltage @ Peak Pulse Current
Low Leakage < 5.0
mA
Flammability Rating UL 94 V−O
xxx
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 2 of this data sheet.
DEVICE MARKING INFORMATION
See specific marking information in the device marking
column of the table on page 3 of this data sheet.
Preferred
devices are recommended choices for future use
and best overall value.
Mechanical Characteristics
CASE:
Void-free, transfer-molded, thermosetting plastic case
FINISH:
Corrosion resistant finish, easily solderable
MAXIMUM CASE TEMPERATURE FOR SOLDERING PURPOSES:
260°C for 10 Seconds
Package designed for optimal automated board assembly
Small package size for high density applications
Available in 8 mm Tape and Reel
Use the Device Number to order the 7 inch/3,000 unit reel.
Replace the “T1” with “T3” in the Device Number to order the
13 inch/10,000 unit reel.
©
Semiconductor Components Industries, LLC, 2004
1
August, 2004 − Rev. 7
Publication Order Number:
MMBZ5V6ALT1/D
M
MMBZ5V6ALT1 Series
MAXIMUM RATINGS
Rating
Peak Power Dissipation @ 1.0 ms (Note 1)
@ T
L
≤
25°C
MMBZ5V6ALT1 thru MMBZ10VALT1
MMBZ12VALT1 thru MMBZ33VALT1
Symbol
P
pk
°P
D
°
R
qJA
°P
D
°
R
qJA
T
J
, T
stg
T
L
Value
24
40
225
1.8
556
300
2.4
417
− 55 to +150
260
Unit
Watts
°mW°
mW/°C
°C/W
°mW
mW/°C
°C/W
°C
°C
Total Power Dissipation on FR−5 Board (Note 2) @ T
A
= 25°C
Derate above 25°C
Thermal Resistance Junction−to−Ambient
Total Power Dissipation on Alumina Substrate (Note 3) @ T
A
= 25°C
Derate above 25°C
Thermal Resistance Junction−to−Ambient
Junction and Storage Temperature Range
Lead Solder Temperature − Maximum (10 Second Duration)
Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit
values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied,
damage may occur and reliability may be affected.
1. Non−repetitive current pulse per Figure 5 and derate above T
A
= 25°C per Figure 6.
2. FR−5 = 1.0 x 0.75 x 0.62 in.
3. Alumina = 0.4 x 0.3 x 0.024 in, 99.5% alumina.
*Other voltages may be available upon request.
ORDERING INFORMATION
Device
MMBZ5V6ALT1
MMBZ5V6ALT1G
MMBZ5V6ALT3
MMBZ5V6ALT3G
MMBZ6VxALT1
MMBZ6VxALT1G
MMBZ6VxALT3
MMBZ6VxALT3G
MMBZ9V1ALT1
MMBZ9V1ALT1G
MMBZ9V1ALT3
MMBZ9V1ALT13G
MMBZxxVALT1
MMBZxxVALT1G
MMBZxxVALT3
MMBZxxVALT3G
Package
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
SOT−23
SOT−23
(Pb−Free)
Shipping
†
3000 Tape & Reel
3000 Tape & Reel
10,000 Tape & Reel
10,000 Tape & Reel
3000 Tape & Reel
3000 Tape & Reel
10,000 Tape & Reel
10,000 Tape & Reel
3000 Tape & Reel
3000 Tape & Reel
10,000 Tape & Reel
10,000 Tape & Reel
3000 Tape & Reel
3000 Tape & Reel
10,000 Tape & Reel
10,000 Tape & Reel
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specifications Brochure, BRD8011/D.
http://onsemi.com
2
MMBZ5V6ALT1 Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted)
UNIDIRECTIONAL
(Circuit tied to Pins 1 and 3 or 2 and 3)
Symbol
I
PP
V
C
V
RWM
I
R
V
BR
I
T
QV
BR
I
F
V
F
Z
ZT
I
ZK
Z
ZK
Parameter
Maximum Reverse Peak Pulse Current
Clamping Voltage @ I
PP
Working Peak Reverse Voltage
Maximum Reverse Leakage Current @ V
RWM
Breakdown Voltage @ I
T
Test Current
Maximum Temperature Coefficient of V
BR
Forward Current
Forward Voltage @ I
F
Maximum Zener Impedance @ I
ZT
Reverse Current
Maximum Zener Impedance @ I
ZK
I
PP
V
C
V
BR
V
RWM
I
R
V
F
I
T
V
I
F
I
Uni−Directional TVS
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted)
UNIDIRECTIONAL
(Circuit tied to Pins 1 and 3 or Pins 2 and 3)
(V
F
= 0.9 V Max @ I
F
= 10 mA)
24 WATTS
Breakdown Voltage
V
RWM
Volts
3.0
3.0
4.5
6.0
6.5
I
R
@
V
RWM
mA
5.0
0.5
0.5
0.3
0.3
V
BR
(Note 4)
(V)
Min
5.32
5.89
6.46
8.65
9.50
Nom
5.6
6.2
6.8
9.1
10
Max
5.88
6.51
7.14
9.56
10.5
@ I
T
mA
20
1.0
1.0
1.0
1.0
Max Zener
Impedance
(Note 5)
Z
ZT
@ I
ZT
W
11
−
−
−
−
Z
ZK
@ I
ZK
W
1600
−
−
−
−
mA
0.25
−
−
−
−
V
C
@ I
PP
(Note 6)
V
C
V
8.0
8.7
9.6
14
14.2
I
PP
A
3.0
2.76
2.5
1.7
1.7
QV
BR
mV/5C
1.26
2.80
3.4
7.5
7.5
Device
MMBZ5V6AL
MMBZ6V2AL
MMBZ6V8AL
MMBZ9V1AL
MMBZ10VAL
Device
Marking
5A6
6A2
6A8
9A1
10A
(V
F
= 0.9 V Max @ I
F
= 10 mA)
V
RWM
Volts
8.5
12
14.5
17
22
26
I
R
@
V
RWM
nA
200
50
50
50
50
50
40 WATTS
Breakdown Voltage
V
BR
(Note 4)
(V)
Min
11.40
14.25
17.10
19.00
25.65
31.35
Nom
12
15
18
20
27
33
Max
12.60
15.75
18.90
21.00
28.35
34.65
@ I
T
mA
1.0
1.0
1.0
1.0
1.0
1.0
V
C
@ I
PP
(Note 6)
V
C
V
17
21
25
28
40
46
I
PP
A
2.35
1.9
1.6
1.4
1.0
0.87
QV
BR
mV/5C
7.5
12.3
15.3
17.2
24.3
30.4
Device
MMBZ12VAL
MMBZ15VAL
MMBZ18VAL
MMBZ20VAL
MMBZ27VAL
MMBZ33VAL
Device
Marking
12A
15A
18A
20A
27A
33A
4. V
BR
measured at pulse test current I
T
at an ambient temperature of 25°C.
5. Z
ZT
and Z
ZK
are measured by dividing the AC voltage drop across the device by the AC current applied. The specified limits are for I
Z(AC)
= 0.1 I
Z(DC)
, with the AC frequency = 1.0 kHz.
6. Surge current waveform per Figure 5 and derate per Figure 6
http://onsemi.com
3
MMBZ5V6ALT1 Series
TYPICAL CHARACTERISTICS
18
BREAKDOWN VOLTAGE (VOLTS)
(V
BR
@ I
T
)
15
12
9
6
3
0
−40
0.1
0.01
−40
I
R
(nA)
10
1000
100
1
0
+ 100
+ 50
TEMPERATURE (°C)
+ 150
+ 85
+ 25
TEMPERATURE (°C)
+ 125
Figure 1. Typical Breakdown Voltage
versus Temperature
(Upper curve for each voltage is bidirectional mode,
lower curve is unidirectional mode)
Figure 2. Typical Leakage Current
versus Temperature
320
280
C, CAPACITANCE (pF)
240
200
160
120
15 V
80
40
0
0
1
BIAS (V)
2
3
5.6 V
P
D
, POWER DISSIPATION (mW)
300
250
ALUMINA SUBSTRATE
200
150
100
FR−5 BOARD
50
0
0
25
50
75
100
125
TEMPERATURE (°C)
150
175
Figure 3. Typical Capacitance versus Bias Voltage
(Upper curve for each voltage is unidirectional mode,
lower curve is bidirectional mode)
Figure 4. Steady State Power Derating Curve
http://onsemi.com
4
MMBZ5V6ALT1 Series
TYPICAL CHARACTERISTICS
PEAK PULSE DERATING IN % OF PEAK
POWER OR CURRENT @ T
A
= 25°C
100
90
80
70
60
50
40
30
20
10
0
0
25
50
75
100
125
150 175
T
A
, AMBIENT TEMPERATURE (°C)
200
t
r
≤
10
ms
100
VALUE (%)
PULSE WIDTH (t
P
) IS DEFINED
AS THAT POINT WHERE THE
PEAK CURRENT DECAYS TO
50% OF I
PP
.
PEAK VALUE − I
PP
HALF VALUE −
50
t
P
0
I
PP
2
0
1
2
3
t, TIME (ms)
4
Figure 5. Pulse Waveform
MMBZ5V6ALT1
100
P
pk
, PEAK SURGE POWER (W)
RECTANGULAR
WAVEFORM, T
A
= 25°C
BIDIRECTIONAL
100
P
pk
, PEAK SURGE POWER (W)
Figure 6. Pulse Derating Curve
MMBZ5V6ALT1
RECTANGULAR
WAVEFORM, T
A
= 25°C
BIDIRECTIONAL
10
UNIDIRECTIONAL
10
UNIDIRECTIONAL
1
1
0.1
1
10
100
1000
0.1
1
10
100
1000
PW, PULSE WIDTH (ms)
PW, PULSE WIDTH (ms)
Figure 7. Maximum Non−repetitive Surge
Power, P
pk
versus PW
Power is defined as V
RSM
x I
Z
(pk) where V
RSM
is
the clamping voltage at I
Z
(pk).
Figure 8. Maximum Non−repetitive Surge
Power, P
pk
(NOM) versus PW
Power is defined as V
Z
(NOM) x I
Z
(pk) where
V
Z
(NOM) is the nominal Zener voltage measured at
the low test current used for voltage classification.
http://onsemi.com
5
