SMBJ SERIES
Elektronische Bauelemente
VOLTAGE 5.0V ~ 170V
600W Peak Power Surface Mount TVS
RoHS Compliant Product
FEATURES
* For surface mount application
* Built-in strain relief
* Excellent clamping capability
* Low profile package
* Fast response time: Typically less than
1.0ps from 0 volt to BV min.
* Typical I
R
less than 1m above 10V
A
* High temperature soldering guaranteed:
260 C / 10 seconds at terminals
DO-214AA(SMB)
.083(2.11)
.075(1.91)
.155(3.94)
.130(3.30)
.185(4.70)
.160(4.06)
.012(0.31)
.006(0.15)
.096(2.44)
.083(2.13)
.050(1.27)
.030(0.76)
.008
MAX.
(.203)
.220(5.59)
.200(5.08)
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Lead: Solderable per MIL-STD-202,
method 208 guaranteed
* Polarity: Color band denotes cathode end except Bidirectional
* Mounting position: Any
* Weight: 0.093 grams
Dimensions in inches
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25 C ambient temperature unless otherwise specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
RATINGS
Peak Power Dissipation at T
A
=25 C, T
P
=1ms(NOTE 1)
Peak Forward Surge Current at 8.3ms Single Half Sine-Wave
superimposed on rated load (JEDEC method) (NOTE 3)
Maximum Instantenous Forward Voltage at 35.0A for
Unidirectional only
SYMBOL
P
PK
I
FSM
V
F
T
J
, T
STG
Minimum 600
100
3.5
-55 to +150
VALUE
UNITS
Watts
Amps
V olts
C
Operating and Storage Temperature Range
NOTES:
1. Non-repetitive current pulse per Fig. 3 and derated above T
A
=25 C per Fig. 2.
2
2. Mounted on Copper Pad area of 5.0mm (.013mm Thick) to each terminal.
3. 8.3ms single half sine-wave, duty cycle = 4 pulses per minute maximum.
DEVICES FOR BIPOLAR APPLICATIONS
1. For Bidirectional use C or CA Suffix for types SMBJ5.0 thru SMBJ170.
2. Electrical characteristics apply in both directions.
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page 1 of
4
SMBJ SERIES
Elektronische Bauelemente
VOLTAGE 5.0V ~ 170V
600W Peak Power Surface Mount TVS
RATING AND CHARACTERISTIC CURVES (SMBJ SERIES)
FIG.1-PEAK PULSE POWER DERATING CURVE
Non-Repetitive
Pulse Waveform
Shown in Fig. 3
T
A
=25 C
10
PEAK PULSE POWER(P
PP
) OR CURRENT(I
PP
)
DERATING IN PERCENTAGE
100
100
FIG.2-PULSE DERATING CURVE
P
PPM
, PEAK PULSE POWER, KW
75
50
1.0
5.0mm COPPER PAD AREAS
2
25
0.1
0.1ms
0
1.0ms
10ms
100ms
1.0ms
10ms
0
25
50
75
100
125
150
175
td, PULSE WIDTH, sec.
T
A
, AMBIENT TEMPERATURE ( C)
FIG.3-PULSE WAVE FORM
150
I
PPM
, PEAK PULSE CURRENT, %
tf=10us
Peak Value
I
PPM
T
A
=25 C
Pulse Width (td) is defined
as the point where the Peak
Current Deacys to 50% of Ipp
10,000
FIG.4-TYPICAL JUNCTION CAPACITANCE
T
J
=25 C
f=1.0MHz
Vsig=50mVp-p
5,000
100
2,000
Half Value-I
PPM
2
Measued at
Zero Bias
1,000
50
10/1000msec Waveform
as Defined by R.E.A.
C
J
, CAPACITANCE, pF
500
td
e-kt
0
0
1.0
2.0
3.0
4.0
200
Measured at
Stand-Off
Voltage(V
MW
)
t, TIME, ms
100
FIG.5-MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT
100
80
T
J
=T
J
max
8.3ms Single Half Sine-wave
JEDEC Method
50
20
I
FSM
, PEAK FORWARD SURGE
CURRENT, AMPERES
60
10
1.0
2.0
5.0
10
20
50
100
200
V(BR), BREAKDOWN VOLTAGE, VOL
TS
40
20
10
1
5
10
20
50
100
NUMBER OF CYCLES AT 60Hz
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page
2
of
4
SMBJ SERIES
Elektronische Bauelemente
VOLTAGE 5.0V ~ 170V
600W Peak Power Surface Mount TVS
PART NUMBER REVERSE BREAKDOWN
VOLTAGE
ADD C FOR BI- STAND-OFF
V
BR
(V)
VOLTAGE
DIRECTIONAL
MIN. @ I
T
V
RWM
(V)
See Note 1
BREAKDOWN
VOLTAGE
V
BR
(V)
MAX. @ I
T
TEST
CURRENT
I
T
( mA )
MAXIMUM
CLAMPING
VOLTAGE
@I
PP
V
C
(V)
PEAK
REVERSE
PULSE
LEAKAGE
CURRENT
@V
RWM
I
PP
(A)
I
R
( A)
MARKING
CODE
SMBJ60(C)
SMBJ60(C)A
SMBJ64(C)
SMBJ64(C)A
SMBJ70(C)
SMBJ70(C)A
SMBJ75(C)
SMBJ75(C)A
SMBJ78(C)
SMBJ78(C)A
SMBJ85(C)
SMBJ85(C)A
SMBJ90(C)
SMBJ90(C)A
SMBJ100(C)
SMBJ100(C)A
SMBJ110(C)
SMBJ110(C)A
SMBJ120(C)
SMBJ120(C)A
SMBJ130(C)
SMBJ130(C)A
SMBJ150(C)
SMBJ150(C)A
SMBJ160(C)
SMBJ160(C)A
SMBJ170(C)
SMBJ170(C)A
60
60
64
64
70
70
75
75
78
78
85
85
90
90
100
100
110
110
120
120
130
130
150
150
160
160
160
170
66.7
66.7
71.1
71.1
77.8
77.8
83.3
83.3
86.7
86.7
94.4
94.4
100
100
111
111
122
122
133
133
144
144
167
167
178
178
189
189
84.5
76.7
90.1
81.8
98.6
89.5
105.7
95.8
109.8
99.7
119.2
108.2
126.5
115.5
141.0
128.0
154.5
140.5
169.0
153.0
182.5
165.5
211.5
192.5
226.0
205.0
239.5
217.5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
107
96.8
114
103
125
113
134
121
139
126
151
137
160
146
179
162
196
177
214
193
231
209
268
243
287
259
304
275
5.6
6.2
5.3
5.8
4.8
5.3
4.5
4.9
4.3
4.7
3.9
4.4
3.8
4.1
3.4
3.7
3.0
3.4
2.8
3.1
2.6
2.9
2.2
2.5
2.1
2.3
2.0
2.2
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
BJ60
BJ60A
BJ64
BJ64A
BJ70
BJ70A
BJ75
BJ75A
BJ78
BJ78A
BJ85
BJ85A
BJ90
BJ90A
BJ100
BJ100A
BJ110
BJ110A
BJ120
BJ120A
BJ130
BJ130A
BJ150
BJ150A
BJ160
BJ160A
BJ170
BJ170A
For Bi-direction type suffix"C"
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page
4
of
4
