MJE18204 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> MJE18204

MJE18204: Description5A, 600V, NPN, Si, POWER TRANSISTOR, TO-220AB, CASE 221A-09, 3 PIN; CategoryDiscrete semiconductor The transistor; File Size891KB，13 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

MJE18204 Overview

5A, 600V, NPN, Si, POWER TRANSISTOR, TO-220AB, CASE 221A-09, 3 PIN

MJE18204 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Maker	Rochester Electronics
Parts packaging code	TO-220AB
package instruction	CASE 221A-09, 3 PIN
Contacts	3
Manufacturer packaging code	CASE 221A-09
Reach Compliance Code	unknown
Shell connection	COLLECTOR
Maximum collector current (IC)	5 A
Collector-emitter maximum voltage	600 V
Configuration	SINGLE
Minimum DC current gain (hFE)	5
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
JESD-609 code	e0
Humidity sensitivity level	NOT SPECIFIED
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	NPN
Certification status	COMMERCIAL
surface mount	NO
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	13 MHz
