E & E Magnetic Products Limited
POWER TRANSFORMER
Flyback Transformer for PoE Plus
Providing Power to PoE devices with up to 30 Watts
S
CHEMATICS
Flyback transformers designed for PoE Plus (IEEE802.3at)
powered devices with up to 30 Watts
Designed for 250kHz switching frequency with input of
36 - 72V and auxilliary output of 12V
Low Leakage Inductance
Hipot voltage: 1500Vrms
Operating temperature -40°C to +125°C.
RoHS compliant version is available
Custom design is also available
E
LECTRICAL
S
PECIFICATION @
25°C
Part
Number
835-00865
835-00866
835-00867
835-00868
835-00869
RoHS
Part
Number
835-00865F
835-00866F
835-00867F
835-00868F
835-00869F
Turns Ratio
Pri : Sec
1 : 0.09
1 : 0.14
1 : 0.33
1 : 0.56
1 : 0.67
Pri : Aux
1 : 0.33
1 : 0.33
1 : 0.33
1 : 0.33
1 : 0.33
Inductance
at 0A
(uH ± 10%)
42.0
42.0
42.0
42.0
42.0
Inductance
@ Ipk
(uH Min)
37.8
37.8
37.8
37.8
37.8
DCR
(Ohm Max)
Pri
Sec
Aux
Leakage
Inductance
(nH Max)
3.00
1.60
0.545
0.430
0.310
Ipk
(A)
2.6
2.6
2.6
2.6
2.6
Secondary
Output
3.3V, 9A
5V, 6A
12V, 2.5A
19.5V, 1.5A
24V, 1.25A
0.070 0.0023 0.220
0.069 0.0050 0.225
0.061
0.060
0.060
0.015
0.037
0.055
0.195
0.195
0.195
Notes:
1. Inductance is measured at 250kHz, 0.7Vrms, 0Adc.
2. Peak primary current is drawn at minimum input voltage.
3. DCR is measured with the windings connected in parallel.
4. Leakage Inductance is for the primary winding with the secondary windings shorted.
5. Turns ratio is with the primary and the secondary windings connected in parallel.
6.Operating temperature range: -40°
C
to +125°C. The part temperature (ambient temperature + temperature rise)
should not exceed the upper limit of the operating temperature under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow and other cooling provisions all affect the part
temperature. Part temperature should be verified in the end application.
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
1
Tel: (852) 2765 3888
Fax: (852) 2954 3304
PX207(01)
Revised in 06/12
E & E Magnetic Products Limited
POWER TRANSFORMER
Flyback Transformer for PoE Plus
Providing Power to PoE devices with up to 30 Watts
M
ECHANICAL
D
IMENSIONS
.590
14.99
.860
MAX
21.84
12
7
.130
3.30
.118
3.00
EE
1.150
MAX
29.21
835-008xx
(DATE)
1
.028
TYP
0.71
6
1.190
30.23
.060
1.52
Recommended
Pad Layout
.012 ±.008
0.30 ±0.20
.450
MAX
11.43
REFERENCE OR
GAUGE PLANE
.118±.010
3.00 ±0.25
.590 ±.010
14.99±0.25
.080 TYP
2.03
Notes:
7. All dimensions are specified in
inches
with higher precedence in inches.
mm
8. Unless otherwise specified, all tolerances are ±
.010
.
0.25
Weight (in gram)
Tape & Reel
:
:
13.2 typ.
140 / reel
9. Coplanarity:
.004
max.
0.10
S
CHEMATICS
1
2
12
11
10
Pri
4
3
Sec
9
8
5
7
Aux
6
SCHEMATIC
