PLASTIC ENCASED SMD CRYSTAL
FPX
CRYSTALS
The FPX is a surface mount version of the FX-3. It has a special
high temperature seal which is able to withstand SMD soldering
techniques. Small size and availability in tape and reel make this
product exceptional for SMD applications.
FEATURES
Industry Standard
Cost Effective
High Temperature Seal
Space Saving Designs
Tape and Reel (1,000 pcs. STD)
FPX STANDARD SPECIFICATIONS *
PARAMETERS
Frequency Range
Frequency Tolerance
Frequency Stability, ref @ 25ºC
Temperature Range
Operating (T
OPR
)
Storage
(T
STG
)
Shunt Capacitance
(Co)
Load Capacitance
(C
L
)
Aging
Drive Level
CONDITIONS
Ta = 25ºC
Ta = -10ºC ~ +70ºC
MIN
3.579545
-50
-100
-10
-55
Customer Specified
Ta = 25ºC; per year
10.0
-5.0
MAX
66.6667
+50
+100
+70
+125
7.0
Series
+5.0
0.1
UNITS
MHz
PPM
PPM
ºC
pF
pF
PPM
mW
Frequency Range
(MHz)
Operating Mode Max ESR
W
Frequency Range
(MHz)
Operating Mode Max ESR
W
Fundamental
3.579 ~ 4.000
200
9.000+ ~ 13.000
60
Fundamental
Fundamental
4.000+ ~ 5.000
150
13.000+ ~ 20.000
40
Fundamental
Fundamental
5.000+ ~ 6.000
120
20.000+ ~ 30.000
30
Fundamental
Fundamental
6.000+ ~ 7.000
100
30.000 ~ 90.000
100
3rd OT
Fundamental
7.000+ ~ 9.000
80
* Other tolerances, stabilities & operating temperature ranges available. Consult Fox Customer Service for specific requirements, or use crystal order form on page 6.
All specifications subject to change without notice. Rev. 03/02/00
Revision "A"
Revision "C"
All dimensions are in millimeters.
See page 31 for tape and reel specifications.
FOXElectronics
5570 Enterprise Parkway
Fort Myers, Florida 33905
941-693-0099
FAX 941-693-1554
http://www.foxonline.com
© 2000 FOX ELECTRONICS
