Models with integrated transmit and receive channels
in low profile SMT package
Designed to withstand IR-Reflow with peak
temperature per IPC/JEDEC J-STD-020C
Operating temperature 0°C to +70°C
RoHS compliant versions are available
E
LECTRICAL
S
PECIFICATION @
25°C
Part
Number
RoHS
Part
Number
Turns Ratio
Tx
824-M0004
824-M0073
824-M0075
824-M0080
824-M0090
824-M0144
824-M0220
824-M0004R 1.41CT:1CT
824-M0073R 1.41CT:1CT
824-M0075R 1.25CT:1CT
824-M0080R
1CT:1.41
Rx
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
Insertion
Loss
(dB Max)
.1-100MHz 1-30MHz
1.1
1.1
1.1
2.0
2.0
1.1
1.1
18.0
18.0
18.0
18.0
18.0
18.0
18.0
Return Loss
(dB Min)
40MHz
15.5
15.5
15.5
15.5
15.5
15.5
15.5
50MHz
13.5
13.5
13.5
13.5
13.5
13.5
13.5
CMRR Crosstalk
Hipot
(dB Min) (dB Min)
(Vrms)
60-80MHz .1-100MHz .1-100MHz
12.0
12.0
12.0
12.0
12.0
12.0
12.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
34.0
34.0
34.0
34.0
34.0
34.0
34.0
1500
1500
1500
1500
1500
1500
1500
824-M0090R 1CT:1.41CT
824-M0144R 1.41CT:1CT
824-M0220R 1.41CT:1CT
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
1
Tel: (852) 2765 3888
Fax: (852) 2954 3304
EH020(06)
Revised in 06/07
E & E Magnetic Products Limited
10/100 Base-T Single Port
Magnetic Module
For Transceiver Requiring Various Turns Ratios
S
CHEMATICS
M
ECHANICAL
D
IMENSIONS
Package: SM016A
.700
17.78
3
1.000
25.40 MAX
.100
2.54
.100
2.54
.540
13.72
.040
1.02
.500±.010
12.70±0.25
ELEC & ELTEK
824-M0xxx
(COUNTRY)
(DATE)
Recommended
Pad Layout
.018±.003
0.46±0.08
.395
10.03 MAX
M
ECHANICAL
D
IMENSIONS
.004-.020
0.10-0.51
REFERENCE OR
GAUGE PLANE
.100±.010
2.54±0.25
.700±.010
17.78±0.25
.235 MAX
5.97
0-8°
.035±.010
0.89±0.25
Notes:
Weight (in gram)
1. All dimensions are specified in inches with higher precedence in inches.
mm
Tape & Reel
2. Unless otherwise specified, all tolerances are ± .010 .
0.25
3. For available RoHS part number, the part will be marked with “824-M0xxxR”, instead of “824-M0xxx”.
:
:
2.7 typ.
350 / reel
S
CHEMATICS
824-M0004
CHIP SIDE
(Primary)
RD+
RD-
RDCT
1
2
3
4
16
15
14
13
12
11
10
9
TD+
TD-
TDCT
RXCT
RX-
5
6
7
8
TXCT
TX-
TX+
LINE SIDE
(Secondary)
RX+
Rx Side
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
2
Tx Side
Tel: (852) 2765 3888
Fax: (852) 2954 3304
EH020(06)
Revised in 06/07
E & E Magnetic Products Limited
S
CHEMATICS
824-M0080
10/100 Base-T Single Port
Magnetic Module
For Transceiver Requiring Various Turns Ratios
CHIP SIDE
(Primary)
RD+
RD-
RDCT
1
2
3
4
16
15
14
13
12
11
10
9
TD+
TD-
TDCT
RXCT
RX-
5
6
7
8
TXCT
TX-
TX+
LINE SIDE
(Secondary)
RX+
Rx Side
824-M0073/ 824-M0090
Tx Side
S
CHEMATICS
CHIP SIDE
(Primary)
RD+
RD-
RDCT
1
2
3
4
16
15
14
13
12
11
10
9
TD+
TD-
TDCT
RXCT
RX-
5
6
7
8
TXCT
TX-
TX+
LINE SIDE
(Secondary)
RX+
Rx Side
824-M0075/ 824-M0144
TD+
TDCT
TD-
1
2
3
4
5
Tx Side
S
CHEMATICS
16
15
14
TX+
TXCT
TX-
CHIP SIDE
(Primary)
RD+
RDCT
RD-
Tx Side
13
12
11
10
9
LINE SIDE
(Secondary)
RX+
RXCT
RX-
6
7
8
Rx Side
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
3
Tel: (852) 2765 3888
Fax: (852) 2954 3304
EH020(06)
Revised in 06/07
E & E Magnetic Products Limited
S
CHEMATICS
824-M0220
10/100 Base-T Single Port
Magnetic Module
For Transceiver Requiring Various Turns Ratios
CHIP SIDE
(Primary)
TD+
TD-
1
2
16
15
RD+
RD-
TDCT
3
4
14
RDCT
13
12
RXCT
11
10
9
TXCT
5
TX-
6
7
8
RX-
RX+
LINE SIDE
(Secondary)
TX+
Tx Side
Rx Side
FOR MORE INFORMATION, PLEASE CONTACT
HEADQUARTER
2/F Block A, Merit Industrial Centre,
94 Tokwawan Road, Kowloon,
Hong Kong
Tel: (852) 2765 3888
Fax: (852) 2954 3304
Email: eempl@eleceltek.com
Website: http://www.eleceltek.com
Information herein is for reference only and subject to change without notice. It does not constitute any representation, warranty or commitment of the company in respect
of the products in any aspect. All logos, brands and product names mentioned herein are trademarks or registered trademarks of their respective owners. The company
does not assume any liability arising out of the application or use of any product or circuit described herein. Copyrights 2006, E & E Magnetic Products Limited.
