824-M0234R datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power management> transformer> 824-M0234R

824-M0234R: DescriptionDatacom Transformer, 10/1000 BASE-T Application(s), 1CT:1; 1CT:1CT, SM016A, ROHS COMPLIANT; CategoryPower management transformer; File Size501KB，7 Pages; ManufacturerElec & Eltek; Websitehttp://www.eleceltek.com; Environmental Compliance

Download Datasheet Parametric View All

824-M0234R Overview

Datacom Transformer, 10/1000 BASE-T Application(s), 1CT:1; 1CT:1CT, SM016A, ROHS COMPLIANT

824-M0234R Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Elec & Eltek
package instruction	SM016A, ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	BREADTH & HEIGHT DIM INCLUDES TERMINALS ALSO
application	10/1000 BASE-T
high	5.97 mm
Insulation voltage	1500 V
length	25.4 mm
Installation features	SURFACE MOUNT
Number of functions	1
Maximum operating temperature	70 °C
Minimum operating temperature
method of packing	TAPE & REEL
physical size	L25.4XB12.7XH5.97 (mm)
Primary inductance	350 µH
surface mount	YES
Transformer type	DATACOM TRANSFORMER
Turns ratio (Np:Ns)	1CT:1; 1CT:1CT
width	12.7 mm

Preview

Download Datasheet

View All

E & E Magnetic Products Limited

10/100 Base-T Single Port

Magnetic Module

For Transceiver Requiring 1:1 Transmit Turns Ratios

CHEMATICS

Compliant with IEEE802.3 standard including

350uH

OCL with 8mA DC bias

Models with integrated transmit and receiver channels

in low profile SMT package

Designed to withstand IR-Reflow with peak

temperature per IPC/JEDEC J-STD-020C

Operating temperature 0°C to +70°C

RoHS compliant versions are available

LECTRICAL

PECIFICATION @

25°C

Part

Number

RoHS

Part

Number

824-M0014R

824-M0023R

824-M0024R

824-M0070R

1,2

Turns Ratio

1CT:1CT

Insertion

Loss

(dB Max)

.1-100MHz 1-30MHz

1.0

1.1

1.5

1.0

1.5

1.0

1.15

1.0

16.0

18.0

16.0

18.0

16.0

18.0

16.0

18.0

16.0

Return Loss

(dB Min)

40MHz

14.0

15.5

13.5

14.0

15.5

13.5

15.5

17.0

15.5

14.0

15.5

12.0

50MHz

13.0

13.5

11.5

13.0

13.5

11.5

13.5

14.5

13.5

12.0

CMRR Crosstalk

Hipot

(dB Min) (dB Min)

(Vrms)

60-80MHz .1-100MHz .1-100MHz

12.0

10.0

12.0

10.0

12.0

10.5

33.0

35.0

33.0

35.0

33.0

35.0

50.0

38.0

40.0

38.0

40.0

38.0

35.0

40.0

38.0

30.0

38.0

35.0

38.0

33.0

38.0

1500

824-M0014

824-M0023

824-M0024

824-M0070

824-M0113

824-M0125

824-M0142

824-M0157

824-M0158

824-M0190

824-M0192

824-M0194

824-M0218

824-M0219

824-M0223

824-M0234

824-M0235

824-M0237

824-M0241

824-00274

1CT:1

1CT:1CT

1CT:1

1CT:1CT

1CT:1

1CT:1CT

1CT:1

1CT:1CT

1CT:1

1CT:1CT

824-M0113R

824-M0125R

824-M0142R

824-M0157R

824-M0158R

824-M0190R

824-M0192R

1,4

824-M0194R

824-M0218R

824-M0219R

824-M0223R

824-M0234R

824-M0235R

824-M0237R

824-M0241R

824-M0274R

Notes:

1. Operating temperature -40°C to +85°C.

2. Suitable for Auto MDI/MDIX applications.

3. For 824-M0157 and 824-M0237, Pin 4 & 13 are removed.

4. For 824-M0158, 824-M0194 and 824-M0234, Pin 5 & 12 are removed.

2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong

Tel: (852) 2765 3888

Fax: (852) 2954 3304

EH021(07)

Revised in 06/07
