Hi-Rel DC/DC CONVERTER

MGDM-25 : 25W POWER

Hi-Rel

Grade

Single, Bi & Triple Outputs

Metallic Case - 1.500 VDC Isolation

• 28Vdc input compliant with MIL-STD-704 D/E

• Nominal power up to 25 W without derating

• Wide temperature range : -40°C/+105°C case

• High efficiency up to 87%

• Soft start

• Galvanic isolation 1.500 VDC

• Integrated LC EMI filter

• Permanent short circuit protection

• No optocoupler for high reliability

• RoHS or Leaded process option

1-General

The MGDM-25 series is a full family of high per-

formance DC/DC power modules designed for

aerospace, military and high-end industrial ap-

plications. These modules use a frequency fixed

swiching technic at 250KHz providing excellent

reliability, low noise characteristics and high

power density. Standard models are available

with nominal input voltage of 28 volts in a vol-

tage range of 9-36, 16-40 volts. The series

include single, bi and triple output voltage

choices of 3,3, 5, 12, 15 volts.

No external heatsink is required for the MGDM-

25 series to supply 25W output power over the

case temperature range of -40°C up to 105°C.

All the modules are designed with LC network

filters to minimize reflected input current ripple

and output voltage ripple.

The modules include a soft-start, a permanent

short circuit protection and an output overvoltage

protection to ensure efficient module protec-

tions.

The soft-start allows current limitation and

eliminates inrush current during start-up. The

short circuit protection completely protects the

modules against short-circuits of any duration

by a shut-down and restores to normal when

the overload is removed.

The design has been carried out with surface

mount components and is manufactured in a

fully automated process to guarantee high

quality. Each module is tested and burned in

with a GAIA converter automated test equipment.

The modules are potted with a bi-component

thermal conductive compound and packaged in

a metallic case to ensure the module’s integrity

under high environmental conditions.

2-Product Selection

Single output model

Bi output model

Triple output model

: MGDS - 25 -

: MGDB - 25 -

: MGDT - 25 -

input

output

option

suffix

Input Voltage Range

Permanent

Transient

Output

B : 3,3 VDC

C : 5 VDC or +/-5VDC

E : 12 VDC or +/-12VDC

F : 15 VDC or +/-15VDC

BE : 3,3 VDC and +/-12 VDC

BF : 3,3 VDC and +/-15 VDC

CE : 5 VDC and +/-12 VDC

CF : 5 VDC and +/-15 VDC

Suffix :

nothing : RoHS process

-L : leaded process

(available in N. America)

H : 9-36 VDC

J : 16-40 VDC

* Consult factory

40 VDC/100 ms *

50 VDC/100 ms *

Options :

/T : option for -55°C start up operating temperature

/S : option for screening and serialization

REDEFINING THE SOURCE OF POWER

Gaia Converter FC98-024.01/11 Revision K
