BAQ333...BAQ335
Vishay Telefunken
Switching Diode
Features
D
D
D
D
D
Silicon Planar Diodes
Saving space
Hermetic sealed parts
Fits onto SOD 323 / SOT 23 footprints
Electrical data identical with the devices
BAQ33...BAQ35 / BAQ133...BAQ135
96 12315
D
Very low reverse current
Applications
Protection circuits, time delay circuits,
peak follower circuits, logarithmic amplifiers
Order Instruction
Type
BAQ333
BAQ334
BAQ335
Type Differentiation
V
RRM
= 40 V
V
RRM
= 70 V
V
RRM
= 140 V
Ordering Code
BAQ333–TR
BAQ334–TR
BAQ335–TR
Remarks
Tape and Reel
Tape and Reel
Tape and Reel
Absolute Maximum Ratings
T
j
= 25
_
C
Parameter
Reverse voltage
g
Peak forward surge current
Forward current
Junction temperature
Storage temperature range
t
p
=1
m
s
Test Conditions
Type
BAQ333
BAQ334
BAQ335
Symbol
V
R
V
R
V
R
I
FSM
I
F
T
j
T
stg
Value
30
60
125
2
200
200
–65...+200
Unit
V
V
V
A
mA
°
C
°
C
Maximum Thermal Resistance
T
j
= 25
_
C
Parameter
Test Conditions
Junction ambient mounted on epoxy–glass hard tissue, Fig. 1
35
m
m copper clad, 0.9 mm
2
copper area per electrode
Symbol
R
thJA
R
thJA
Value
500
500
Unit
K/W
K/W
Document Number 85538
Rev. 5, 25-Jun-01
www.vishay.com
1 (4)
BAQ333...BAQ335
Vishay Telefunken
Ozone Depleting Substances Policy Statement
It is the policy of
Vishay Semiconductor GmbH
to
1. Meet all present and future national and international statutory requirements.
2. Regularly and continuously improve the performance of our products, processes, distribution and operating
systems with respect to their impact on the health and safety of our employees and the public, as well as their
impact on the environment.
It is particular concern to control or eliminate releases of those substances into the atmosphere which are known as
ozone depleting substances ( ODSs ).
The Montreal Protocol ( 1987 ) and its London Amendments ( 1990 ) intend to severely restrict the use of ODSs and
forbid their use within the next ten years. Various national and international initiatives are pressing for an earlier ban
on these substances.
Vishay Semiconductor GmbH
has been able to use its policy of continuous improvements to eliminate the use of
ODSs listed in the following documents.
1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments respectively
2 . Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental
Protection Agency ( EPA ) in the USA
3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C ( transitional substances ) respectively.
Vishay Semiconductor GmbH
can certify that our semiconductors are not manufactured with ozone depleting
substances and do not contain such substances.
We reserve the right to make changes to improve technical design and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each customer application
by the customer. Should the buyer use Vishay-Telefunken products for any unintended or unauthorized application, the
buyer shall indemnify Vishay-Telefunken against all claims, costs, damages, and expenses, arising out of, directly or
indirectly, any claim of personal damage, injury or death associated with such unintended or unauthorized use.
Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany
Telephone: 49 ( 0 ) 7131 67 2831, Fax number: 49 ( 0 ) 7131 67 2423
www.vishay.com
4 (4)
Document Number 85538
Rev. 5, 25-Jun-01
