ESAC25-02C datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> ESAC25-02C

ESAC25-02C: DescriptionRectifier Diode, 1 Phase, 2 Element, 10A, 200V V(RRM), Silicon, TO-220AB, SC-46, 3 PIN; CategoryDiscrete semiconductor diode; File Size122KB，3 Pages; ManufacturerFuji Electric Co., Ltd.

Download Datasheet Parametric View All

ESAC25-02C Overview

Rectifier Diode, 1 Phase, 2 Element, 10A, 200V V(RRM), Silicon, TO-220AB, SC-46, 3 PIN

ESAC25-02C Parametric

Parameter Name	Attribute value
Maker	Fuji Electric Co., Ltd.
Parts packaging code	TO-220AB
package instruction	R-PSFM-T3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	HIGH RELIABILITY
application	HIGH VOLTAGE FAST RECOVERY
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
Maximum non-repetitive peak forward current	70 A
Number of components	2
Phase	1
Number of terminals	3
Maximum output current	10 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	200 V
Maximum reverse recovery time	0.4 µs
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE

Preview

Download Datasheet

View All

ESAC25(C,N,D)

(10A)

FAST RECOVERY DIODE

(200V to 400V / 10A)

Outline drawings, mm

+0.5

2.7

±0.1

Ø3.6

±0.2

4.5

±0.2

1.32

6.4

±0.2

3.7

±0.2

-0.5

1.2

±0.2

0.4

0.8

2.54

5.08

2.7

Features

High voltage by mesa design

High reliability

JEDEC

EIAJ

TO-220AB

SC-46

Connection diagram

ESAC25-

Applications

High speed switching

Maximum ratings and characteristics

Absolute maximum ratings

Item

Repetitive peak reverse voltage

Non-repetitive peak reverse voltage

Average output current

Surge current

Operating junction temperature

Storage temperature

Symbol

RRM

RSM

FSM

stg

Conditions

ESAC25-

Rating

-02

200

250

-04

400

450

10*

-40 to +150

Unit

°C

Square wave, duty=1/2, Tc=106°C

Sine wave 10ms

Average forward current of centertap full wave connection

Electrical characteristics (Ta=25°C Unless otherwise specified )

Item

Forward voltage drop

Reverse current

Reverse recovery time

Thermal resistance

Symbol

RRM

th(j-c)

Conditions

=2.5A

RRM

=0.1A, I

=0.1A

Junction to case

Max.

1.3

0.4

3.0*

Unit

µA

µs

°C/W
