T-17004: Description10/100 BASE-T SINGLE PORT TRANSFORMER MODULE; File Size39KB，2 Pages; ManufacturerRhombus Industries, Inc.; Websitehttp://www.rhombus-ind.com/

Download Datasheet Compare View All

T-17004 Overview

10/100 BASE-T SINGLE PORT TRANSFORMER MODULE

Preview

Download Datasheet

View All

10/100 BASE-T SINGLE PORT TRANSFORMER MODULE

1 : 1 Transmit Turns Ratio CompatibleWith Intel, National Semiconductor,

Level One, ICS, Kendin, TDK, Broadcom, SEEQ and Lucent Transceivers

Electrical Specifications at 25

Insertion

Part

Insertion Loss

Return Loss

Number

(dB MAX)

(dB MIN @ 100Ω)

0.1-100MHz

1-30MHz 40MHz 50MHz

60-80MHz 30MHz

Crosstalk

(dB MIN)

60MHz 100MHz

Differential to

Common Mode

Rejection (dB MIN)

30MHz

60MHz

100MHz

Hipot

(Vrms MIN)

T-17000

T-17001

T-17002

T-17003

T-17004

T-17006

-1.0

-22

-20

-18

-20

-18

-16

-12

-14

-12

-50

-45

-50

-55

-40

-50

-40

-35

-40

-50

-42

-45

-42

-50

-38

-40

-36

-45

-32

-35

-33

-40

1500

Mil. Grade Epoxy encapsulated package

withstands 235

C IR reflow

Tape and Reel available.

Meets all IEE 802.3 and ANSI X3.263 stan-

dards including 350

µH

OCL with 8 mA bias

1.000

(25.40)

MAX.

.410

(10.41)

MAX.

.260

(6.60)

.300

MAX. (7.62)

MAX.

.010

(0.25)

TYP.

.040

(1.02)

TYP.

.510 (12.95)

.480 (12.19)

.020

(0.51)

TYP.

.100

(2.54)

TYP.

Dimensions in inches (mm)

Specifications subject to change without notice.

For other values & Custom Designs, contact factory.

100-sp100

Rhombus

Industries Inc.

www.rhombus-ind.com

15801 Chemical Lane, Huntington Beach, CA 92649-1595

Tel: (714) 898-0960

•

Fax: (714) 896-0971

T-17004 Related Products

	T-17004	T-17002	T-17003	T-17000	T-17001	T-17006
Description	10/100 BASE-T SINGLE PORT TRANSFORMER MODULE	10/100 BASE-T SINGLE PORT TRANSFORMER MODULE	10/100 BASE-T SINGLE PORT TRANSFORMER MODULE	10/100 BASE-T SINGLE PORT TRANSFORMER MODULE	10/100 BASE-T SINGLE PORT TRANSFORMER MODULE	10/100 BASE-T SINGLE PORT TRANSFORMER MODULE
Maker	-	Rhombus Industries, Inc.	Rhombus Industries, Inc.	Rhombus Industries, Inc.	Rhombus Industries, Inc.	Rhombus Industries, Inc.
Reach Compliance Code	-	unknow	unknow	unknow	unknow	unknow
ECCN code	-	EAR99	EAR99	EAR99	EAR99	EAR99
application	-	10/100 BASE-T	10/100 BASE-T	10/100 BASE-T	10/100 BASE-T	10/100 BASE-T
high	-	6.6 mm	6.6 mm	7.24 mm	6.6 mm	6.6 mm
Insulation voltage	-	1500 V	1500 V	1500 V	1500 V	1500 V
length	-	25.4 mm	25.4 mm	25.9 mm	25.4 mm	25.4 mm
Installation features	-	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of functions	-	1	1	1	1	1
method of packing	-	TAPE & REEL	TAPE & REEL	TAPE & REEL	TAPE & REEL	TAPE & REEL
physical size	-	L25.4XB10.41XH6.6 (mm)	L25.4XB10.41XH6.6 (mm)	L25.9XB10.16XH7.24 (mm)	L25.4XB10.41XH6.6 (mm)	L25.4XB10.41XH6.6 (mm)
Primary inductance	-	350 µH	350 µH	350 µH	350 µH	350 µH
surface mount	-	YES	YES	YES	YES	YES
Transformer type	-	DATACOM TRANSFORMER	DATACOM TRANSFORMER	DATACOM TRANSFORMER	DATACOM TRANSFORMER	DATACOM TRANSFORMER
Turns ratio (Np:Ns)	-	1CT:1CT; 1CT:1CT	1CT:1; 1CT:1CT	1CT:1CT; 1CT:1CT	1CT:1; 1CT:1CT	1CT:1CT; 1CT:1CT
width	-	10.41 mm	10.41 mm	10.16 mm	10.41 mm	10.41 mm
