Type T
High Voltage Paper-Film/Foil Capacitors
Paper-Film/Foil Capacitors for High Voltage Filter Applications
Type T capacitors are for high voltage filter applications
as well as being used for filtering, bypass and blocking
in radar amplifiers and power supplies. The Type T is
constructed with a rugged inserted tab to foil connection
to 10-32 screw terminals surrounded by thermoset plastic
bushings for high voltage performance in an oval, her-
metically seald metal case that will give long operating
life under harsh conditions.
Complies with the EU Directive
2002/95/EC requirement
restricting the use of Lead (Pb),
Mercury (Hg), Cadmium (Cd),
Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB)
and PolyBrominated Diphenyl
Ethers (PBDE).
Highlights
• Hermetically sealed
• High Voltage to 5 kVdc
• High Temperature, 105 ºC operation with derating
•
Specifications
Ratings
Cap
(µF)
0.5
1.0
2.0
3.0
4.0
6.0
8.0
10.0
15.0
0.10
0.25
0.50
1.0
2.0
4.0
6.0
8.0
10.0
15.0
0.5
1.0
2.0
4.0
6.0
8.0
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Temperature Range:
Catalog
Case
Code
A
A
A
A
A
A
C
C
D
A
A
A
A
A
A
C
D
D
D
A
A
A
C
D
D
H
(Inches)
2.13
2.13
2.13
2.38
2.63
3.88
2.88
3.13
3.50
2.13
2.13
2.13
2.13
2.63
4.25
3.50
3.50
3.88
5.25
2.13
2.13
3.13
3.13
3.88
4.25
0.1 µF to 15.0 µF
600 Vdc to 5000 Vdc
±10%
–55 ºC to 105 ºC — Full rated voltage to 85 ºC.
Derate linearly to 50% rated voltage at max temp.
Cap
(µF)
10.0
12.0
15.0
0.10
0.25
0.50
1.0
2.0
4.0
5.0
8.0
10.0
15.0
1.0
2.0
4.0
.10
.50
1.0
6.0
.50
1.0
2.0
Catalog
Part Number
1500 Vdc
T15W10NR-F
T15W12NR-F
T15W15NR-F
2000 Vdc
T20P1NR-F
T20P25NR-F
T20P5NR-F
T20W1NR-F
T20W2NR-F
T20W4NR-F
T20W5NR-F
T20W8NR-F
T20W10NR-F
T20W15NR-F
2500 Vdc
T25W1NR-F
T25W2NR-F
T25W4NR-F
3000 Vdc
T30P1NR-F
T30P5NR-F
T30W1NR-F
T30W6NR-F
5000 Vdc
T50P5NR-F
T50W1NR-F
T50W2NR-F
C
D
D
3.50
4.25
7.25
A
A
C
D
2.13
3.13
3.13
8.00
C
C
D
2.88
3.13
4.25
A
A
A
A
C
D
D
D
D
D
2.13
2.13
2.13
2.63
2.88
3.50
4.25
5.75
6.75
9.88
D
D
D
4.75
5.25
6.25
Case
Code
H
(Inches)
Part Number
600 Vdc
T6P5NR-F
T6W1NR-F
T6W2NR-F
T6W3NR-F
T6W4NR-F
T6W6NR-F
T6W8NR-F
T6W10NR-F
T6W15NR-F
1000 Vdc
T10P1NR-F
T10P25NR-F
T10P5NR-F
T10W1NR-F
T10W2NR-F
T10W4NR-F
T10W6NR-F
T10W8NR-F
T10W10NR-F
T10W15NR-F
1500 Vdc
T15P5NR-F
T15W1NR-F
T15W2NR-F
T15W4NR-F
T15W6NR-F
T15W8NR-F
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.
cde.com
Type T
High Voltage Paper-Film/Foil Capacitors
Outline Drawing
D
C
Case
Code
A
C
D
A
1.31
1.91
1.97
Dimensions (Inches)
B
2.16
2.91
3.66
C
0.56
0.50
0.50
D
1.06
1.00
1.00
F
0.81
1.38
1.38
Mounting Hardware
See page 5.000 for mounting hardware.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.
cde.com
