Part Number

Search

8-696414-2

Description
CONNECTOR ACCESSORY
CategoryThe connector    Connector bracket
File Size136KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

8-696414-2 Overview

CONNECTOR ACCESSORY

8-696414-2 Parametric

Parameter NameAttribute value
MakerTE Connectivity
Reach Compliance Codeunknown
Connector bracket typeCONNECTOR ACCESSORY
Manufacturer's serial number696414
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Terminals & Splices > Product Feature Selector > Product Details
8­696414­2 Product Details
Miscellaneous Terminals

Always EU RoHS/ELV Compliant
 (
Statement of Compliance
)
Product Highlights:
Terminal Style = Shur­Plug
Insulation Support
Wire Range = 0.30­1.42² [22­16] mm [AWG]
Not For Use With Double Wire
Length = 23.13 mm
View all Features
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
8­696414­2

TE Internal Number: 8­696414­2
 Preliminary
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Insulation Support = Insulation Support
Color = Red
Finish = Tin
Product Series = .156
Wire/Cable Type = Regular Wire
Dimensions:
Length (mm [in]) = 23.13 [0.911]
Insulation Diameter (mm [in]) = 2.10 ­ 3.10 [.083 ­ .122]
Body Features:
Wire Range (mm [AWG]) = 0.30­1.42² [22­16]
Double Wire = No
Material = Brass
Insulation Material = Nylon
Sleeve Finish = Tin
Sleeve Material = Copper
Contact Features:
Terminal Style = Shur­Plug
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Features:
Packaging Method = Loose Piece
Packaging Quantity = 50/Box
Other:
Brand = TE Connectivity
Proprietary Name = PIDG
