IRFR420ATRRPBF: DescriptionPower Field-Effect Transistor, 3.3A I(D), 500V, 3ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-252AA, DPAK-3; CategoryDiscrete semiconductor The transistor; File Size115KB，10 Pages; ManufacturerInternational Rectifier （ Infineon ）; Websitehttp://www.irf.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

IRFR420ATRRPBF Overview

Power Field-Effect Transistor, 3.3A I(D), 500V, 3ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-252AA, DPAK-3

IRFR420ATRRPBF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	International Rectifier （ Infineon ）
Parts packaging code	TO-252AA
package instruction	DPAK-3
Contacts	3
Reach Compliance Code	unknown
Avalanche Energy Efficiency Rating (Eas)	140 mJ
Shell connection	DRAIN
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	500 V
Maximum drain current (Abs) (ID)	3.3 A
Maximum drain current (ID)	3.3 A
Maximum drain-source on-resistance	3 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-252AA
JESD-30 code	R-PSSO-G2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	83 W
Maximum pulsed drain current (IDM)	10 A
Certification status	Not Qualified
surface mount	YES
Terminal surface	MATTE TIN OVER NICKEL
Terminal form	GULL WING
Terminal location	SINGLE
Maximum time at peak reflow temperature	30
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

PD - 94355

SMPS MOSFET

IRFR420A

IRFU420A

HEXFET

Power MOSFET

Applications

Switch Mode Power Supply (SMPS)

Uninterruptible Power Supply

High speed power switching

Benefits

Low Gate Charge Qg results in Simple

Drive Requirement

Improved Gate, Avalanche and dynamic

dv/dt Ruggedness

Fully Characterized Capacitance and

Avalanche Voltage and Current

Effective C

OSS

specified (See AN 1001)

Absolute Maximum Ratings

Parameter

@ T

= 25°C

@ T

= 100°C

= 25°C

dv/dt

STG

Continuous Drain Current, V

@ 10V

Continuous Drain Current, V

@ 10V

Pulsed Drain Current

Power Dissipation

Linear Derating Factor

Gate-to-Source Voltage

Peak Diode Recovery dv/dt

Operating Junction and

Storage Temperature Range

Soldering Temperature, for 10 seconds

DSS

500V

(on) max

3.0Ω

3.3A

D-Pak

IRFR420A

I-Pak

IRFU420A

Max.

3.3

2.1

0.67

± 30

3.4

-55 to + 150

300 (1.6mm from case )

Units

W/°C

V/ns

Avalanche Characteristics

Parameter

Single Pulse Avalanche Energy

Avalanche Current

Repetitive Avalanche Energy

Typ.

–––

Max.

140

2.5

5.0

Units

Thermal Resistance

Parameter

θJC

θCS

θJA

Junction-to-Case

Case-to-Sink, Flat, Greased Surface

Junction-to-Ambient

Typ.

–––

0.50

–––

Max.

1.5

–––

Units

°C/W

www.irf.com

12/10/01
