BAW56W

Description
Rectifier Diode,
CategoryDiscrete semiconductor    diode
File Size160KB,3 Pages
ManufacturerGalaxy Semi-Conductor Co., Ltd.
Download Datasheet Parametric View All

BAW56W Online Shopping

Suppliers Part Number Price MOQ In stock
BAW56W - - View Buy Now

BAW56W Overview

Rectifier Diode,

BAW56W Parametric

Parameter NameAttribute value
MakerGalaxy Semi-Conductor Co., Ltd.
package instructionR-PDSO-G3
Reach Compliance Codeunknown
applicationGENERAL PURPOSE
Minimum breakdown voltage70 V
ConfigurationCOMMON ANODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.25 V
JESD-30 codeR-PDSO-G3
Maximum non-repetitive peak forward current4.5 A
Number of components2
Phase1
Number of terminals3
Maximum operating temperature150 °C
Maximum output current0.2 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Maximum power dissipation0.2 W
Maximum repetitive peak reverse voltage70 V
Maximum reverse current2.5 µA
Maximum reverse recovery time0.006 µs
Reverse test voltage70 V
surface mountYES
Terminal formGULL WING
Terminal locationDUAL
BL
Galaxy Electrical
Surface mount switching diode
FEATURES
For high-speed switching
Applications.
Common anode
Production specification
BAW56W
Pb
Lead-free
APPLICATIONS
High speed switching application.
SOT-323
ORDERING INFORMATION
Type No.
BAW56W
Marking
KJC
Package Code
SOT-323
MAXIMUM RATING
@ Ta=25℃ unless otherwise specified
Characteristic
Peak Repetitive Reverse Voltage
Working peak reverse voltage
DC Reverse Voltage
Forward Continuous Current
Surge forward Current
Power Dissipation
Operating Junction Temperature Range
Storage Temperature Range
Symbol
V
RRM
V
RWM
V
R
I
F
I
FS
P
d
T
j
T
STG
200
4.5
250
150
-55 to +150
mA
A
mW
70
V
Limits
Unit
ELECTRICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified
Characteristic
Reverse Breakdown Voltage
Symbol
V
(BR)R
Min
70
MAX
-
715
855
1000
1250
2.5
2
6
UNIT
V
Test Condition
I
R
= 100μA
I
F
=1mA
I
F
=10mA
I
F
=50mA
I
F
=150mA
V
R
=70V
V
R
=0V,f=1MHz
I
F
=I
R
=10mA f=1MHz
Forward Voltage
V
F
-
V
Reverse Leakage Current
Diode Capacitance
Reverse Recovery Time
I
R
C
D
t
rr
-
-
-
μA
pF
ns
Document number: BL/SSSDF009
Rev.A
www.galaxycn.com
1
