VCXO Voltage Controlled Oscillator
ECV20 Series
§
§
§
§
60kHz to 120.0MHz
Low Cost
Fast Delivery
Custom Options Available
Parameter
Frequency
Range
Supply Voltage
Supply Current
(max)
Stability
Operating Temp
Storage Temp
Symmetry
Control Voltage
Pulling Range
ECV20A
12.0MHz
to
120.0MHz
50mA
ECV20F
ECV20H
12.0MHz
60.0kHz
to
to
75.00MHz 50.00MHz
+5Vdc +/- 5%
40mA
20mA
+/-50ppm
0
0
-10 C to +70 C
0
0
-25 C to +100 C
60/40
55/45
0.5Vdc to 5.0Vdc
+/- 200ppm (A)
+/- 250ppm (B)
+/- 300ppm (C)
FTTL
HCMOS
6nS
10nS
ECV20T
60.0kHz
to
50.0MHz
30mA
Environmental & Mechanical
Shock
MIL-STD-202 30G 11ms
Vibration
MIL-STD-202 5G to
2000Hz
0
Soldering
Lead Temperature 260 C
Condition
10s max
55/45
60/40
Output
Rise & Fall
Times (max)
ACMOS
5nS
LSTTL
10nS
Part Numbering: ECV20 A 20.00 A
Type
Output
A = ACMOS F= FTTL
H= HCMOS T= LSTTL
Frequency
Pulling Range
A=200ppm B=250ppm C=300ppm
Supply Voltage
X = 5V
X
Pin
Function
1
V
C
7
0V
8
Output
14
V
DD
A
25.00
B
15.00
C
10.00
D
15.24
E
7.62
F
0.50
Dimensions in mm
ECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UK
Tel: +44(0)1903 892810: Fax: +44(0)1903 892738. Email: ecm@ecmelectronics.co.uk
Although we have attempted to accurately reflect the products we market. ECM reserve the right without prior notice to
discontinue any product or make design changes we believe necessary.
Issue 1
