HM2R95PE810EE9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> HM2R95PE810EE9

HM2R95PE810EE9: DescriptionBoard Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal; CategoryThe connector The connector; File Size145KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric Compare View All

HM2R95PE810EE9 Overview

Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal

HM2R95PE810EE9 Parametric

Parameter Name	Attribute value
Maker	Amphenol
Reach Compliance Code	compliant
Other features	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE
Connector type	BOARD CONNECTOR
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	HM2R95PE810E
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	9
Options	GENERAL PURPOSE
Terminal pitch	2 mm
Termination type	PRESS FIT
Total number of contacts	225

Preview

Download Datasheet

View All

PDM: Rev:B

STATUS:

Released

Printed: Mar 15, 2011

HM2R95PE810EE9 Related Products

	HM2R95PE810EE9	HM2R95PE810EN9	HM2R95PE810EZ1LF	HM2R95PE810EZ1	HM2R95PE810EE9LF	HM2R95PE810EN9LF
Description	Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal	Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal	Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal, LEAD FREE	Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal	Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal, LEAD FREE	Board Connector, 225 Contact(s), 9 Row(s), Female, Right Angle, Press Fit Terminal, LEAD FREE
Maker	Amphenol	Amphenol	Amphenol	Amphenol	Amphenol	Amphenol
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
Other features	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE	25 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
DIN compliance	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	HM2R95PE810E	HM2R95PE810E	HM2R95PE810E	HM2R95PE810E	HM2R95PE810E	HM2R95PE810E
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	9	9	9	9	9	9
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Terminal pitch	2 mm	2 mm	2 mm	2 mm	2 mm	2 mm
Termination type	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT
Total number of contacts	225	225	225	225	225	225
