TAK CHEONG
®
SEM IC O N DU C TO R
500 mW LL-34 Hermetically
Sealed Glass Zener Voltage
Regulators
SURFACE MOUNT
LL34
Absolute Maximum Ratings
Parameter
Power Dissipation
Storage Temperature Range
Operating Junction Temperature
T
A
= 25°C unless otherwise noted
Value
500
-65 to +175
+175
Units
mW
°C
°C
Cathode Band Color : Blue
DEVICE MARKING DIAGRAM
These ratings are limiting values above which the serviceability of the diode may be impaired.
Specification Features:
Zener Voltage Range 2.4 to 75 Volts
TCZMxxxB
TCZMxxxC
- VZ tolerance
±
2%
- VZ tolerance
±
5%
Cathode
Anode
LL-34 (Mini-MELF) Package
Surface Device Type Mounting
Hermetically Sealed Glass
Compression Bonded Construction
All External Surfaces Are Corrosion Resistant And Terminals Are Readily Solderable
RoHS Compliant
Matte Tin (Sn) Terminal Finish
Color band Indicates Negative Polarity
ELECTRICAL SYMBOL
Electrical Characteristics
Device Type
TCZM2V4B
TCZM2V7B
TCZM3V0B
TCZM3V3B
TCZM3V6B
TCZM3V9B
TCZM4V3B
TCZM4V7B
TCZM5V1B
TCZM5V6B
TCZM6V2B
TCZM6V8B
TCZM7V5B
TCZM8V2B
TCZM9V1B
TCZM10B
TCZM11B
TCZM12B
TCZM13B
Min
2.35
2.65
2.94
3.23
3.53
3.82
4.21
4.61
5.00
5.49
6.08
6.66
7.33
8.04
8.92
9.80
10.78
11.76
12.74
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
Z
ZT
@ I
ZT
I
ZT
(Volts)
(Ω)
(mA)
Max
Nom
Max
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
2.45
2.75
3.06
3.37
3.67
3.98
4.39
4.79
5.20
5.71
6.32
6.94
7.63
8.36
9.28
10.20
11.22
12.24
13.26
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
94
94
89
89
84
84
84
75
56
37
9
14
14
14
14
18
18
23
28
I
ZK
(mA)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Z
ZK
@ I
ZK
(Ω)
Max
564
564
564
564
564
564
564
470
451
376
141
75
75
75
94
141
141
141
160
I
R
@ V
R
(μA)
Max
45
18
9
4.5
4.5
2.7
2.7
2.7
1.8
0.9
2.7
1.8
0.9
0.63
0.45
0.18
0.09
0.09
0.09
V
R
(Volts)
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
Number: DB-064
June 2008 / C
Page 1
TCZM2V4B through TCZM75B/
TCZM2V4C through TCZM75C
TAK CHEONG
Electrical Characteristics
Device Type
Min
®
SEM IC O N DU C TO R
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
Z
ZT
@ I
ZT
I
ZT
(Volts)
(Ω)
(mA)
Max
Nom
Max
28
37
42
51
51
65
75
75
75
84
122
141
160
169
188
202
226
240
I
ZK
(mA)
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Z
ZK
@ I
ZK
(Ω)
Max
188
188
212
212
235
235
282
282
306
329
329
353
353
376
400
423
447
470
I
R
@ V
R
(μA)
Max
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
V
R
(Volts)
10.5
11.2
12.6
14.0
15.4
16.8
18.9
21.0
23.0
25.2
27.3
30.1
33.0
35.7
39.2
43.4
47.6
52.5
TCZM15B
14.70
15
15.30
5
TCZM16B
15.68
16
16.32
5
TCZM18B
17.64
18
18.36
5
TCZM20B
19.60
20
20.40
5
TCZM22B
21.56
22
22.44
5
TCZM24B
23.52
24
24.48
5
TCZM27B
26.46
27
27.54
2
TCZM30B
29.40
30
30.60
2
TCZM33B
32.34
33
33.66
2
TCZM36B
35.28
36
36.72
2
TCZM39B
38.22
39
39.78
2
TCZM43B
42.14
43
43.86
2
TCZM47B
46.06
47
47.94
2
TCZM51B
49.98
51
52.02
2
TCZM56B
54.88
56
57.12
2
TCZM62B
60.76
62
63.24
2
TCZM68B
66.64
68
69.36
2
TCZM75B
73.50
75
76.50
2
V
F
Forward Voltage = 1 V Maximum @
I
F
= 100 mA for all types
Electrical Characteristics
Device Type
TCZM2V4C
TCZM2V7C
TCZM3V0C
TCZM3V3C
TCZM3V6C
TCZM3V9C
TCZM4V3C
TCZM4V7C
TCZM5V1C
TCZM5V6C
TCZM6V2C
TCZM6V8C
TCZM7V5C
TCZM8V2C
TCZM9V1C
TCZM10C
TCZM11C
TCZM12C
TCZM13C
TCZM15C
TCZM16C
TCZM18C
TCZM20C
TCZM22C
TCZM24C
TCZM27C
TCZM30C
TCZM33C
TCZM36C
TCZM39C
TCZM43C
Number: DB-064
June 2008 / C
Min
2.28
2.57
2.85
3.14
3.42
3.71
4.09
4.47
4.85
5.32
5.89
6.46
7.11
7.79
8.65
9.50
10.45
11.40
12.35
14.25
15.20
17.10
19.00
20.90
22.80
25.65
28.50
31.35
34.20
37.05
40.85
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
Z
ZT
@ I
ZT
I
ZT
(Volts)
(Ω)
(mA)
Max
Nom
Max
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
2.52
2.84
3.15
3.47
3.78
4.10
4.52
4.94
5.36
5.88
6.51
7.14
7.86
8.61
9.56
10.50
11.55
12.60
13.65
15.75
16.80
18.90
21.00
23.10
25.20
28.35
31.50
34.65
37.80
40.95
45.15
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
2
94
94
89
89
84
84
84
75
56
37
9
14
14
14
14
18
18
23
28
28
37
42
51
51
65
75
75
75
84
122
141
I
ZK
(mA)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
Z
ZK
@ I
ZK
(Ω)
Max
564
564
564
564
564
564
564
470
451
376
141
75
75
75
94
141
141
141
160
188
188
212
212
235
235
282
282
306
329
329
353
I
R
@ V
R
(μA)
Max
45
18
9
4.5
4.5
2.7
2.7
2.7
1.8
0.9
2.7
1.8
0.9
0.63
0.45
0.18
0.09
0.09
0.09
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
V
R
(Volts)
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10.5
11.2
12.6
14.0
15.4
16.8
18.9
21.0
23.0
25.2
27.3
30.1
Page 2
TAK CHEONG
Electrical Characteristics
Device Type
Min
®
SEM IC O N DU C TO R
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
Z
ZT
@ I
ZT
(Volts)
I
ZT
(Ω)
(mA)
Max
Nom
Max
160
169
188
202
226
240
I
ZK
(mA)
0.5
0.5
0.5
0.5
0.5
0.5
Z
ZK
@ I
ZK
(Ω)
Max
353
376
400
423
447
470
I
R
@ V
R
(μA)
Max
0.045
0.045
0.045
0.045
0.045
0.045
V
R
(Volts)
33.0
35.7
39.2
43.4
47.6
52.5
TCZM47C
44.65
47
49.35
2
TCZM51C
48.45
51
53.55
2
TCZM56C
53.20
56
58.80
2
TCZM62C
58.90
62
65.10
2
TCZM68C
64.60
68
71.40
2
TCZM75C
71.25
75
78.75
2
V
F
Forward Voltage = 1 V Maximum @
I
F
= 100 mA for all types
Notes:
1.
2.
For detailed information on price, availability and delivery of nominal zener voltages between the voltages shown and tighter
voltage tolerances, contact your nearest Tak Cheong Electronics representative.
The zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an rms value equal to
10% of the dc zener current (I
ZT
or
I
ZK
) is superimposed to
I
ZT
or
I
ZK.
Number: DB-064
June 2008 / C
Page 3
TAK CHEONG
Typical Characteristics
600
®
SEM IC O N DU C TO R
1000
Total Capacitance [pF]
f = 1MHz
Ta = 25
℃
100
VR = 0V
VR = 2V
VR = 5V
PD-Power Passipation [mW]
500
400
300
200
100
VR = 20V
10
VR = 30V
0
0
40
1
Temperature [
℃
]
80
120
160
200
0
20
40
VZ - Reverse Voltage [V]
60
80
Figure 1. Power Dissipation vs Ambient Temperature
Valid provided leads at a distance of 0.8mm from case are kept at
ambient temperature
Figure 2. Total Capacitance
Differential Zener Impedance [Ω]
1000
1000
Iz=1mA
Iz=2mA
Ta = 25
℃
Forward Current [mA]
100
Ta = 25
℃
100
Iz=5mA
Iz=10mA
10
10
1
1
0.1
1
10
VZ - Reverse Voltage [V]
100
0.1
0
0.2
0.4
0.6
0.8
VF - Forw ard Voltage [m V]
1
1.2
Figure 3. Differential Impedance vs. Zener Voltage
Figure 4. Forward Current vs. Forward Voltage
300
250
Reverse Current [mA]
200
150
100
50
0
0
2
4
6
VZ - Reverse Voltage [V]
8
10
PD = 500mW
Ta = 25
℃
100
PD = 500mW
Ta = 25
℃
Reverse Current [mA]
10
1
0.1
0.01
15
25
35
45
55
65
VZ - Reverse Voltage [V]
75
Figure 5. Reverse Current vs. Reverse Voltage
Figure 6. Reverse Current vs. Reverse Voltage
Number: DB-064
June 2008 / C
Page 4
TAK CHEONG
Package Outline
Package
®
SEM IC O N DU C TO R
Case Outline
B
LL-34
DIM
LL34
A
A
B
C
C
Min
3.302
1.397
0.350
Millimeters
Max
3.505
1.499
0.500
Min
0.130
0.055
0.014
Inches
Max
0.138
0.059
0.020
Notes:
1.
2.
3.
All dimensions are within DO213AC JEDEC standard.
LL-34 polarity denoted by cathode band.
Number: DB-064
June 2008 / C
Page 5
