Type TDC
Solid Tantalum Capacitors
Dipped, Radial Leaded, Solid Tantalum Capacitors
As a low cost alternative to molded solid tantalum capaci-
tors, the Type TDC, constructed in a tough, radial dipped
flame retardant plastic case, assures the user that it is a
top performer with such attributes as low DCL, low ESR,
low impedance and a great value with low in-place cost.
The Type TDC is high shock and vibration resistant and
is available in bulk or on radial tape and reel.
Highlights
♦
♦
♦
♦
♦
♦
♦
Tough plastic case
Low DCL
Low ESR and impedance
Low cost
Temperature stable
UL94VO flammability rating
Resistant to shock and vibration
Specifications
Capacitance Range:
Voltage Range:
Tolerance:
Operating Temperature Range:
DC Leakage:
0.10 µF to 330 µF
6 WVdc to 50 WVdc at 85 ºC
±10%, ±20%
–55 ºC to +125 ºC (with proper derating)
+25 ºC - See ratings limit
+85 ºC - 10 x ratings limit
+125 ºC - 12.5 x ratings limit
–10% @ –55 ºC
+10% @ +85 ºC
+12% @ +125 ºC
15% of rated voltage @ 25 ºC
5% of rated voltage @ 85 ºC
1% of rated voltage @ 125 ºC
Case
Code
E
F
G
Quantity
per Reel
1,000
1,000
1,000
Capacitance Change Maximum:
Reverse Voltage (Non-continuous):
Reel Packaging:
Complies with the EU Directive 2002/95/EC
requirement restricting the use of Lead (Pb), Mercury
(Hg), Cadmium (Cd), Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB) and PolyBrominated
Diphenyl Ethers (PBDE).
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 •
www.cde.com
Type TDC
Solid Tantalum Capacitors
Capacitor Outline Drawing
.250 ±.025
(6.35 ±.64
D
Max
D
Max
H
Max
Dimensions - Inches (Millimeters)
Case
Code
E
F
.
187 ±.032
Leads
D (Max.)
H (Max.)
S
.250 (6.35) (Special)
.250 (6.35) .500 (12.7) .125 (3.17) (Standard)
.250 (6.35) (Special)
.350 (8.89) .650 (16.51) .250 (6.35) (Special)
Code
N
W
N
W
W
.175 (4.45) .350 (8.89) .125 (3.17) (Standard)
M
+
H
Max
.
187 ±.032
106
10
107
10
M
.020
(.51)
S
+
.020
(.51)
(4.75 ±.81)
S
(4.75 ±.81)
G
Ratings
Cap
(µF)
E and F Case Codes:
Lead Spacing =
.125 ±.025
(3.17 ±.64)
G Case Code:
Lead Spacing =
.250 ±.025
(6.34 ±.64)
Max.
Max. DF
@ +25 ºC
120 Hz
(%)
Cap
(µF)
Catalog
Part Number
Case
Lead
(S)
Max.
DCL
(µA)
Code Spacing @ +25 ºC
Max. DF
@ +25 ºC
120 Hz
(%)
Catalog
Part Number
Case
Lead
(S)
DCL
(µA)
Code Spacing @ +25 ºC
6 WVdc; 8 Vdc Surge @ 85 ºC
4 WVdc; 5 Vdc Surge @ 125 ºC
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
TDC335*006NSE-F
TDC395*006NSE-F
TDC475*006NSE-F
TDC565*006NSE-F
TDC685*006NSE-F
TDC825*006NSE-F
TDC106*006NSE-F
TDC126*006NSE-F
TDC156*006NSF-F
TDC186*006NSF-F
TDC226*006NSF-F
TDC276*006NSF-F
TDC336*006NSF-F
TDC396*006NSF-F
TDC476*006NSF-F
TDC566*006NSF-F
TDC686*006NSF-F
TDC826*006NSF-F
TDC107*006NSF-F
TDC127*006WSG-F
TDC157*006WSG-F
TDC187*006WSG-F
TDC227*006WSG-F
TDC277*006WSG-F
TDC337*006WSG-F
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
F
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.25
0.25
0.25
0.25
0.25
0.25
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.7
0.9
1.1
1.3
1.6
1.9
2.3
2.7
3.3
3.9
4.8
5.8
7.2
8.6
10
10
10
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
8
8
8
8
8
8
8
8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
10 WVdc; 13 Vdc Surge @ 85 ºC
7 WVdc; 9 Vdc Surge @ 125 ºC
TDC225*010NSE-F
TDC275*010NSE-F
TDC335*010NSE-F
TDC395*010NSE-F
TDC475*010NSE-F
TDC565*010NSE-F
TDC685*010NSE-F
TDC825*010NSE-F
TDC106*010NSF-F
TDC126*010NSF-F
TDC156*010NSF-F
TDC186*010NSF-F
TDC226*010NSF-F
TDC276*010NSF-F
TDC336*010NSF-F
TDC396*010NSF-F
TDC476*010NSF-F
TDC566*010NSF-F
TDC686*010NSF-F
TDC826*010WSG-F
TDC107*010WSG-F
TDC127*010WSG-F
TDC157*010WSG-F
TDC187*010WSG-F
TDC227*010WSG-F
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
F
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.25
0.25
0.25
0.25
0.25
0.25
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.7
0.8
1.0
1.2
1.4
1.8
2.2
2.6
3.1
3.8
4.5
5.4
6.6
8.0
9.6
10.0
10.0
10.0
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
8
8
8
8
8
8
* Indicates capacitance tolerance: K = ±10%, M = ±20%, (J = ±5%, Special Order)
CDE reserves the right to substitute a tighter tolerance, higher voltage capacitor within the same case size.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 •
www.cde.com
Type TDC
Solid Tantalum Capacitors
Ratings
Max.
Catalog
Cap
(µF)
Part Number
Case
Lead
(S)
DCL
(µA)
Code Spacing @ +25 ºC
Max. DF
@ +25 ºC
120 Hz
(%)
Cap
(µF)
Catalog
Part Number
Case
Lead
(S)
Max.
DCL
(µA)
Code Spacing @ +25 ºC
Max. DF
@ +25 ºC
120 Hz
(%)
16 WVdc; 20 Vdc Surge @ 85 ºC
10 WVdc; 12 Vdc Surge @ 125 ºC
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
TDC155*016NSE-F
TDC185*016NSE-F
TDC225*016NSE-F
TDC275*016NSE-F
TDC335*016NSE-F
TDC395*016NSE-F
TDC475*016NSE-F
TDC565*016NSE-F
TDC685*016NSE-F
TDC825*016NSE-F
TDC106*016NSF-F
TDC126*016NSF-F
TDC156*016NSF-F
TDC186*016NSF-F
TDC226*016NSF-F
TDC276*016NSF-F
TDC336*016NSF-F
TDC396*016WSG-F
TDC476*016WSG-F
TDC566*016WSG-F
TDC686*016WSG-F
TDC826*016WSG-F
TDC107*016WSG-F
TDC127*016WSG-F
TDC157*016WSG-F
E
E
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F
G
G
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.7
0.9
1.0
1.3
1.5
1.8
2.2
2.6
3.2
4.0
4.7
5.6
6.8
8.2
9.8
10.0
10.0
10.0
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
8
8
8
8
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
3
5
5
5
5
5
5
5
5
5
5
10
12
15
18
22
27
33
39
47
56
68
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.8
0.9
1.1
8.2
10
12
15
18
22
33
39
47
56
68
82
100
20 WVdc; 26 Vdc Surge @ 85 ºC
13 WVdc; 16 Vdc Surge @ 125 ºC
TDC825*020NSF-F
TDC106*020NSF-F
TDC126*020NSF-F
TDC156*020NSF-F
TDC186*020NSF-F
TDC226*020NSF-F
TDC336*020WSG-F
TDC396*020WSG-F
TDC476*020WSG-F
TDC566*020WSG-F
TDC686*020WSG-F
TDC826*020WSG-F
TDC107*020WSG-F
F
F
F
F
F
F
G
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.25
0.25
0.25
0.25
0.25
0.25
0.25
1.3
1.6
1.9
2.4
2.9
3.5
5.3
6.2
7.5
9.0
10.0
10.0
10.0
6
6
6
6
6
6
6
6
6
6
6
8
8
25 WVdc; 32 Vdc Surge @ 85 ºC
17 WVdc; 22 Vdc Surge @ 125 ºC
TDC105*025NSE-F
TDC125*025NSE-F
TDC155*025NSE-F
TDC185*025NSE-F
TDC225*025NSE-F
TDC275*025NSE-F
TDC335*025NSE-F
TDC395*025NSE-F
TDC475*025NSF-F
TDC565*025NSF-F
TDC685*025NSF-F
TDC825*025NSF-F
TDC106*025NSF--F
TDC126*025NSF-F
TDC156*025NSF-F
TDC186*025NSF-F
TDC226*025NSF-F
TDC276*025WSG-F
TDC336*025WSG-F
TDC396*025WSG-F
TDC476*025WSG-F
TDC566*025WSG-F
TDC686*025WSG-F
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F
F
F
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.250
0.250
0.250
0.250
0.250
0.250
0.50
0.50
0.50
0.50
0.50
0.50
0.70
0.80
0.90
1.10
1.40
1.60
2.0
2.4
3.0
3.6
4.4
5.4
6.6
7.8
9.4
10.0
10.0
3
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
6
6
20 WVdc; 26 Vdc Surge @ 85 ºC
13 WVdc; 16 Vdc Surge @ 125 ºC
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
TDC105*020NSE-F
TDC125*020NSE-F
TDC155*020NSE-F
TDC185*020NSE-F
TDC225*020NSE-F
TDC275*020NSE-F
TDC335*020NSE-F
TDC395*020NSE-F
TDC475*020NSE-F
TDC565*020NSF-F
TDC685*020NSF-F
E
E
E
E
E
E
E
E
E
F
F
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
* Indicates capacitance tolerance: K = ±10%, M = ±20%, (J = ±5%, Special Order)
CDE reserves the right to substitute a tighter tolerance, higher voltage capacitor within the same case size.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 •
www.cde.com
Type TDC
Solid Tantalum Capacitors
Ratings
Max.
Catalog
Cap
(µF)
Part Number
Case
Code
Lead
(S)
35 WVdc; 46 Vdc Surge @ 85 ºC
23 WVdc; 28 Vdc Surge @ 125 ºC
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
TDC104*035NSE-F
TDC124*035NSE-F
TDC154*035NSE-F
TDC184*035NSE-F
TDC224*035NSE-F
TDC274*035NSE-F
TDC334*035NSE-F
TDC394*035NSE-F
TDC474*035NSE-F
TDC564*035NSE-F
TDC684*035NSE-F
TDC824*035NSE-F
TDC105*035NSE-F
TDC125*035NSE-F
TDC155*035NSE-F
TDC185*035NSE--F
TDC225*035NSE-F
TDC275*035NSF-F
TDC335*035NSF-F
TDC339*035NSF-F
TDC475*035NSF-F
TDC565*035NSF-F
TDC685*035NSF-F
TDC825*035NSF-F
TDC106*035NSF-F
TDC126*035WSG-F
TDC156*035WSG-F
TDC186*035WSG-F
TDC226*035WSG-F
TDC276*035WSG-F
TDC336*035WSG-F
TDC396*035WSG-F
TDC476*035WSG-F
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F
F
G
G
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.7
0.9
1.0
1.3
1.6
1.9
2.3
2.8
3.4
4.2
5.0
6.2
7.6
9.2
10
10
3
3
3
3
3
3
3
3
3
3
3
3
3
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
DCL
(µA)
Spacing @ +25 ºC
Max. DF
@ +25 ºC
120 Hz
(%)
Cap
(µF)
Catalog
Part Number
Case
Lead
(S)
Max.
DCL
(µA)
Code Spacing @ +25 ºC
Max. DF
@ +25 ºC
120 Hz
(%)
50 WVdc; 65 Vdc Surge @ 85 ºC
33 WVdc; 40 Vdc Surge @ 125 ºC
TDC104*050NSE-F
TDC124*050NSE-F
TDC154*050NSE-F
TDC184*050NSE-F
TDC224*050NSE-F
TDC274*050NSE-F
TDC334*050NSE-F
TDC394*050NSE-F
TDC474*050NSE-F
TDC564*050NSE-F
TDC684*050NSE-F
TDC824*050NSE-F
TDC105*050NSE-F
TDC125*050NSE-F
TDC155*050NSE-F
TDC185*050NSF-F
TDC225*050NSF-F
TDC275*050NSF-F
TDC335*050NSF-F
TDC395*050NSF-F
TDC475*050NSF-F
TDC565*050NSF-F
TDC685*050WSG-F
TDC825*050WSG-F
TDC106*050WSG-F
TDC126*050WSG-F
TDC156*050WSG-F
TDC186*050WSG-F
TDC226*050WSG-F
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
F
F
F
F
F
F
F
G
G
G
G
G
G
G
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.125
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.7
0.9
1.1
1.3
1.6
1.9
2.2
2.7
3.3
4.0
4.8
6.0
7.2
8.8
3
3
3
3
3
3
3
3
3
3
3
3
3
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
* Indicates capacitance tolerance: K = ±10%, M = ±20%, (J = ±5%, Special Order)
CDE reserves the right to substitute a tighter tolerance, higher voltage capacitor within the same case size.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 •
www.cde.com
Type TDC
Solid Tantalum Capacitors
Part Numbering System
TDC
107
K
Tolerance
J
= ±5%
K
= ±10%
M
= ±20%
016
Voltage
006
= 6 Vdc
010
= 10 Vdc
016
= 16 Vdc
020
= 20 Vdc
025
= 25 Vdc
035
= 35 Vdc
050
= 50 Vdc
W
S
G
–F
Series Capacitance
TDC 394
= 0.39 µF
105
= 1.0 µF
225
= 2.2 µF
186
= 18 µF
107
= 100 µF
Lead
Lead Case
RoHS
Spacing Length Code
Compliant
N
= .125
S
= .187
E –F
= Compliant
W
= .250
T
= Tape
F Blank
= Not
& Reel
G
Compliant
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 •
www.cde.com
MCU
京公网安备 11010802033920号
EEWORLD
