BAS40WT/-04/-05/-06
Features
•
•
Pow Dissipation PD=200mW Tamb=25
Forward
Current I
F
=200mA
Breakdown
Voltage VBR=40V
Lead Free Finish/Rohs Compliant ("P"Suffix designates
RoHS Compliant. See ordering information)
Halogen
free available upon request by adding suffix "-HF"
200mW 40Volt
Plastic-Encapsulate
Diode
SOT-323
A
D
Maximum Ratings
•
•
Operating Temperature: -55 to +150
Storage Temperature: -55 to +150
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Electrical Characteristics @ 25 C Unless Otherwise Specified
Reverse Breakdown
Voltage
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
V
(BR)R
40V
I
R
=10µA
F
E
B
C
V
F
380mV
1000mV
I
FM
= 1mA;
I
FM
= 40mA;
G
H
J
K
DIMENSIONS
I
R
1uA
V
R
=30Volts
C
D
5pF
Measured at
1.0MHz, V
R
=0V
I
F
=10mA through
I
R
=10mA to
I
R
=1mA
Reverse Recovery
Time
DIM
A
B
C
D
E
F
G
H
J
K
INCHES
MIN
MAX
.071
.087
.045
.053
.083
.096
.026 Nominal
.047
.055
.012
.016
.000
.004
.035
.039
.004
.010
.006
.016
MM
MIN
MAX
1.80
2.20
1.15
1.35
2.10
2.45
0.65Nominal
1.20
1.40
.30
.40
.000
.100
.90
1.00
.100
.250
.15
.40
NOTE
T
rr
5nS
Suggested Solder
Pad Layout
0.70
0.90
1.90
0.65
0.65
www.mccsemi.com
Revision:
D
1 of 3
2013/09/24
BAS40WT
I
R
, INSTANTANEOUS REVERSE CURRENT (nA)
MCC
Micro Commercial Components
10000
T
A
= 125ºC
TM
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
1
1000
T
A
= 75ºC
0.1
100
0.01
T
A
= -40ºC
T
A
= 0ºC
T
A
= 25ºC
T
A
= 25ºC
10
T
A
= 0ºC
0.001
1
T
A
= -40ºC
T
A
= 75ºC
T
A
= 125ºC
0.0001
0
0.2
0.4
0.6
0.8
1.0
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Voltage
0.1
0
10
20
30
40
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
3
C
T
, TOTAL CAPACITANCE (pF)
f = 1MHz
2
1
0
0
10
20
30
40
V
R
, REVERSE VOLTAGE (V)
Fig. 3 Typical Capacitance
BAS40WT Marking:43/K43/S40
BAS40WT-04 Marking:44/K44/S42
BAS40WT-05 Marking:45/K45/S43
BAS40WT-06 Marking:46/K46/S44
www.mccsemi.com
Revision:
B
2 of 3
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
