AGILE OPTICAL SWITCHES
Intelligent Optical Add/Drop Circuit Pack
Key Features
• C or L band wavelength operation
• 50 or 100 GHz operation
• Number of add/drop channels customizable up to 8
• Controllable attenuation to 20 dB
• Wavelength blocking to 40 dB
• Optional add/drop path amplification
• 100Base-T interface
• RS-232 craft interface
• SNMP managed
• CLI interface for craft access
• 1RU 19-inch rack mountable
• 48 V operating voltages with dual redundant inputs
• Full featured alarms
• Field upgradeable software
Applications
• Enables add/drop and pass through
of DWDM channels
• Enables add/drop and pass through
channel equalization, blocking, power
monitoring, and amplification
JDSU’s Agile Optical Switch family provides the broadest portfolio of ROADM
solutions designed to match the requirements of major market segments. They
are building blocks of Agile Optical Networks and provide the flexibility to
remotely reconfigure any or all wavelengths, thereby reducing time-to-service,
simplifying the network, and streamlining planning and management. This
results in significant Opex and Capex reductions and faster time to revenue. In
addition, they enable the cost-effective creation and deployment of more complex
network architectures.
The JDSU Intelligent Optical Add/Drop (IOAD) Circuit Pack provides, in a
deployment-ready 1RU configuration, the cost-effective add/drop and pass
through capabilities that are needed in today’s Agile Optical Networks and
features power management control and amplification of both add and drop
optical paths. The optional blocking capability of attenuators allows for the easy
addition/deletion of new wavelengths to the network. Optical taps and photo
diodes provide the power monitoring and add channel verification features. In
addition, the IOAD Circuit Pack incorporates a pass through capability, enabling
for the cascading of multiple circuit packs.
The IOAD Circuit Pack is controlled through an industry-standard network
interface based on TCP/IP, dynamic host configuration protocol (DHCP), and
simple network management protocol (SNMP). SNMP traps are fully supported
as the system alarm mechanism. The IOAD Circuit Pack is ready for integration
into a system provider's IP-based control plane sub-net.
The IOAD Circuit Pack is passively cooled and meets all relevant regulatory
requirements for emission, immunity, and safety compliance.
Compliance
• NEBS Level 3
• IEC 60950-1
• IEC 60825-1
• EN 300 386
• ETSI 300-019
NORTH AMERICA
:
800 498-JDSU (5378)
WORLDWIDE
:
+800 5378-JDSU
WEBSITE
:
www.jdsu.com
INTELLIGENT OPTICAL ADD/DROP CIRCUIT PACK
2
Functional Diagram
(This diagram shows the optical functionality of the IOAD Circuit Pack only. The
diagram does not resemble the actual device. )
Specifications
Parameter
Frequency range
Frequency spacing
Number of add/drop channels
Amplification
Tunable attenuation range
Block attenuation (maximum channel attenuation)
Attenuation resolution
Supply voltage
Interface
Communication
Operating temperature
Connector type
Dimensions (W x H x D)
19-inch configuration, 1U high
Specification
C or L band
50 or 100 GHz
2 to 8 channels (customizable)
10 dBm maximum output power
0 to 20 dB
40 dB
0.1 dB
-48 V
RS-232, 100Base-T
SNMP
-5 to 55 °C
LC/UPC or MTP
18.2 x 1.70 x 11.25 inches (46.2 x 4.3 x 28.6 cm) including handles
17.2 x 1.70 x 8.8 inches (43.7 x 4.3 x 22.35 cm) not including handles
Minimum
INTELLIGENT OPTICAL ADD/DROP CIRCUIT PACK
Ordering Information
For more information on this or other products and their availability, please contact your local JDSU account manager or
JDSU directly at 1-800-498-JDSU (5378) in North America and +800-5378-JDSU worldwide or via e-mail at
customer.service@jdsu.com.
Sample: CPOWCA2N-06101
CPOW
Code
C
L
Operating Band
C band
L band
Code
2
4
6
8
Number of Add/Drop Channels
2
4
6
8
-
Code
Custom
Determined by JDSU at time of order
Code
A
B
Operating Frequency
50 GHz
100 GHz
Code
N
A
D
B
Amplification
No amplification
On add path only
On drop path only
On both add and drop paths
All statements, technical information and recommendations related to the products herein are based upon information believed to be
reliable or accurate. However, the accuracy or completeness thereof is not guaranteed, and no responsibility is assumed for any
inaccuracies. The user assumes all risks and liability whatsoever in connection with the use of a product or its application. JDSU reserves
the right to change at any time without notice the design, specifications, function, fit or form of its products described herein, includ-
ing withdrawal at any time of a product offered for sale herein. JDSU makes no representations that the products
herein are free from any intellectual property claims of others. Please contact JDSU for more information. JDSU and the JDSU logo are
trademarks of JDS Uniphase Corporation. Other trademarks are the property of their respective holders. ©2006 JDS Uniphase
Corporation. All rights reserved. 30137459 Rev. 001 03/06 OADMCP.DS.CMS.AE
