Description
DG411/883, DG412/883
DG413/883
CMOS Analog Switches
The DG411/883 series monolithic CMOS analog switches
are drop-in replacements for the popular DG211 and DG212
series devices. They include four independent single pole
throw (SPST) analog switches, and TTL and CMOS compat-
ible digital inputs.
These switches feature lower analog ON resistance (<35Ω)
and faster switch time (t
ON
<175ns) compared to the DG211
or DG212. Charge injection has been reduced, simplifying
sample and hold applications.
The improvements in the DG411/883 series are made possi-
ble by using a high voltage silicon-gate process. An epitaxial
layer prevents the latch-up associated with older CMOS
technologies. The 44V maximum voltage range permits con-
trolling 40V
P-P
signals. Power supplies may be single-ended
from +5V to +34V, or split from
±5V
to
±20V.
The four switches are bilateral, equally matched for AC or
bidirectional signals. The ON resistance variation with analog
signals is quite low over a
±15V
analog input range. The
switches in the DG411/883 and DG412/883 are identical, dif-
fering only in the polarity of the selection logic. Two of the
switches in the DG413/883 (#1 and #4) use the logic of the
DG211 and DG411/883 (i.e. a logic “0” turns the switch ON)
and the other two switches use DG212 and DG412/883 posi-
tive logic. This permits independent control of turn-on and
turn-off times for SPDT configurations, permitting “break-
before-make” or “make-before-break” operation with a mini-
mum of external logic.
• This Circuit is Processed in Accordance to MIL-STD-
883 and is Fully Conformant Under the Provisions of
Paragraph 1.2.1.
• ON-Resistance <35Ω Max
• Low Power Consumption (P
D
<35µW)
• Fast Switching Action
- t
ON
<175ns
- t
OFF
<145ns
• Low Charge Injection
• Upgrade from DG211/DG212
• TTL, CMOS Compatible
• Single or Split Supply Operation
Applications
• Audio Switching
• Battery Operated Systems
• Data Acquisition
• Hi-Rel Systems
• Sample and Hold Circuits
• Communication Systems
• Automatic Test Equipment
Part Number Information
PART NUMBER
DG411AK/883
DG412AK/883
DG413AK/883
TEMP. RANGE
-55
o
C
-55
o
C
to
to
+125
o
C
+125
o
C
PACKAGE
16 Lead CerDIP
16 Lead CerDIP
16 Lead CerDIP
-55
o
C to +125
o
C
Pinout
DG411/883, DG412/883,
DG413/883 (CERDIP)
TOP VIEW
IN
1
D
1
S
1
1
2
3
16 IN
2
15 D
2
14 S
2
13 V+
12 V
L
11 S
3
10 D
3
9 IN
3
Functional Diagrams
DG411/883
S
1
IN
1
D
1
S
2
IN
2
D
2
S
3
IN
3
D
3
S
4
IN
4
D
4
Four SPST Switches per Package Switches Shown for Logic “1” Inpu
t
DG412/883
S
1
IN
1
D
1
S
2
IN
2
D
2
S
3
IN
3
D
3
S
4
IN
4
D
4
IN
4
D
4
IN
3
D
3
S
4
IN
2
D
2
S
3
IN
1
D
1
S
2
DG413/883
S
1
V- 4
GND 5
S
4
D
4
IN
4
6
7
8
(NC) NO CONNECTION
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright © Intersil Americas Inc. 2003. All Rights Reserved
1
All other trademarks mentioned are the property of their respective owners.
Spec Number
File Number
512043
3681.1
DG411/883, DG412/883, DG413/883
Pin Description
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
SYMBOL
IN
1
D
1
S
1
V-
GND
S
4
D
4
IN
4
IN
3
D
3
S
3
V
L
V+
S
2
D
2
IN
2
DESCRIPTION
Logic Control for Switch 1
Drain (Output) Terminal for Switch 1
Source (Input) Terminal for Switch 1
Negative Power Supply Terminal
Ground Terminal (Logic Common)
Source (Input) Terminal for Switch 4
Drain (Output) Terminal for Switch 4
Logic Control for Switch 4
Logic Control for Switch 3
Drain (Output) Terminal for Switch 3
Source (Input) Terminal for Switch 3
Logic Reference Voltage
Positive Power Supply Terminal (Substrate)
Source (Input) Terminal for Switch 2
Drain (Output) Terminal for Switch 2
Logic Control for Switch 2
LOGIC
0
1
SWITCH
ON
OFF
SWITCH
OFF
ON
SWITCH
1, 4
OFF
ON
SWITCH
2, 3
ON
OFF
DG411/
883
TRUTH TABLE
DG412/
883
DG413/883
NOTE: Logic “0”
≤0.8V.
Logic “1”
≥2.4V.
Spec Number
2
512043
Specifications DG411/883, DG412/883, DG413/883
