LN1052-G-AG
LN1052-RE-AG
LN1052-RS-AGL
LN1052-G-CG
LN1052-RE-CG
LN1052-RS-CGL
SEVEN SEGMENT DISPLAY – 13.2 mm (0.52 INCH)
DATA SHEET 3559 REV.1.2
(a) Common Anode
(b) Common Cathode
Notes: All dimensions are in mm, tolerance is
±
0.25 mm (0.01”) unless otherwise specified
Absolute Maximum Ratings T
a
=25 C
Parameter
Power dissipation per segment
Peak forward current per segment*
Continuous forward current per segment
Reverse voltage per segment
Operating temperature range
Storage temperature range
o
Solder temperature 1/16 inch below seating plane for 3 seconds at 260 C
* 1/10 duty cycle 10 ms pulse width
Electro-optical Characteristic: (T
a
=25
°
C)
Part No.
Chip
Material
Common Anode Common Cathode
LN1052-G-AG
LN1005-G-CG
GaP
LN1052-RE-AG
LN1052-RE-CG
GaAsP
LN1052-RS-AGL
LN1052-RS-CGL
GaAlAs
Wavelength
(nm)
572
635
660
o
Green/Red
60
80
15
5
-35~85
-35~85
Unit
mw
mA
mA
V
o
C
o
C
Color
Green
Red
Red
Iv (mcd)
Typ. 20mA
7
7
15
Note
Features
•
•
•
•
0.52 inch digit height, Gray surface
Uniformly illuminated segments
Wide viewing angle
Easy mounting on PCB or socket
Description
LN1052 series display is fully compatible with industry standard 0.52” package with options of low
current (-xxL), common anode ( -Axx ) and common cathode (-Cxx).
•
221 West Industry Court
•
Deer Park, NY 11729-4681
•
Phone: (631) 586-7600
•
Fax: (631) 242-9798
•
http://www.sensitron.com
•
E-Mail: sales@sensitron.com
