2mm FLAT TOP LED LAMPS
Feature
LOW POWER CONSUMPTION.
SUITALBE FOR AUDIO PANEL INDICATOR.
FIT 2mm HOLE IN PANELS.
LONG LIFE-SOLID STATE RELIABILITY.
L1394HD BRIGHT RED
L1394ID HIGH EFFICIENCY RED
L1394GD GREEN
L1394YD YELLOW
Package Dimensions
Description
The Bright Red source color devices are made with Gallium
Phosphide Red Light Emitting Diode.
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
Selection Guide
Iv (mc d )
@ 10 mA
Min .
L1394HD
L1394ID
L1394GD
L1394YD
BRIGHT RED (GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
RED DIFFUSED
RED DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
0.5
5
3
3
Ty p .
2
8
5
5
View in g
An g l e
2θ1/2
70°
70°
70°
70°
Par t No .
Di c e
L en s Ty p e
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
SPEC NO: DSAA0202
REV NO: V.1
DATE: MAR/13/2001
PAGE: 1 OF 5
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
Par ameter
Dev ic e
Bright Red
High Efficiency Red
Green
Yellow
Ty p .
700
625
565
590
45
45
30
35
40
12
45
10
2.0
2.0
2.2
2.1
2.5
2.5
2.5
2.5
10
Max .
Un i t s
Tes t Co n d itio n s
λ
peak
Peak Wavelength
nm
IF=20mA
∆λ
1/2
Bright Red
High Efficiency Red
Spectral Line Halfwidth
Green
Yellow
Bright Red
High Efficiency Red
Green
Yellow
Bright Red
High Efficiency Red
Green
Yellow
All
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
VR = 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par ameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Soldering Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
B r ig h t Red
120
25
150
5
Hig h Effic ien c y
Red
105
30
150
5
Gr een
105
25
150
5
-40
°
C To + 85
°C
Yello w
105
30
150
5
Un i t s
mW
mA
mA
V
260
°
C For 5 Seconds
SPEC NO: DSAA0202
REV NO: V.1
DATE: MAR/13/2001
PAGE: 2 OF 5
