2mm FLAT TOP LED LAMP
L-1394ID
HIGH EFFICIENCY RED
Features
!
LOW
Description
The High Efficiency Red source color devices are
made with Gallium Arsenide Phosphide on Gallium
Phosphide Orange Light Emitting Diode.
FOR AUDIO PANEL INDICATOR.
POWER CONSUMPTION.
!
SUITABLE
!
FIT
2mm HOLE IN PANELS.
LIFE-SOLID STATE RELIABILITY.
!
LONG
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAB3162
APPROVED : J. Lu
REV NO: V.4
CHECKED : Allen Liu
DATE:MAR/01/2003
DRAWN:Y.H.LI
PAGE: 1 OF 3
Selection Guide
P ar t N o .
Dic e
L en s Ty p e
Iv (m c d )
@ 10 m A
Min .
L-1394ID
HIGH EFFICIENCY RED (GaAsP/GaP)
RED DIFFUSED
5
Ty p .
8
V i ew i n g
An g l e
2
θ
1/2
120°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
Dominate Wavelength
D ev i c e
High Efficiency Red
High Efficiency Red
Ty p .
627
625
45
15
2.0
2.5
10
Max .
Un its
nm
nm
nm
pF
V
uA
Tes t Co n d it io n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Spectral Line Half-width High Efficiency Red
Capacitance
Forward Voltage
Reverse Current
High Efficiency Red
High Efficiency Red
High Efficiency Red
°
Absolute Maximum Ratings at T
A
=25°C
P ar am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
H i g h E f f i c i en c y R ed
105
30
160
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un its
mW
mA
mA
V
SPEC NO: DSAB3162
APPROVED : J. Lu
REV NO: V.4
CHECKED : Allen Liu
DATE:MAR/01/2003
DRAWN:Y.H.LI
PAGE: 2 OF 3
