3-1761210-6 Product Details
Live Product Chat
SDL (Shielded Data Link)
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-1761210-6
T E I nternal N umber: 3 - 1 7 6 1 2 1 0 - 6
Product Highlights:
l
C onnector
l
Receptacle
l
Receptacle C onfiguration = Standard
l
Number of C onductors = 16
l
Keying = C
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
C onnector, SDL
(PDF, English)
Application Specifications:
l
SDL Top-Entry and Side-Entry Printed C ircuit (PC ) Bo...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version A)
l
3D Model
(IGES, Version A)
l
3D Model
(STEP, Version A)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Receptacle
l
Receptacle C onfiguration
= Standard
l
Number of C onductors
= 16
l
Grounding Options
= PC B and Panel Ground
l
PC B Retention Feature
= Yes
l
Shield Material = Brass
l
C omment = Prefix no. designates key configuration. Suffix no. is a
code for the number of conductors. Prefix & suffix nos. of plug
assemblies must match those of the intended mating receptacle.
Keys are molded in as an integral part of the plug & receptacle.
Mechanical Attachment:
l
Keying
= C
Body Related Features:
l
PC B Retention Method
= Mounting Holes
l
Shield Plating = Tin over C opper
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
l
C ontact Plating, Mating Area, Material = Gold (50)
Housing Related Features:
l
Housing Entry Style
= Top
l
Housing Material
= Polyester
l
Housing C olor = Black
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
