Product Data Sheet
OSC Series
Ultra Miniature TCXO s
Features
Low Cost
3.0 or 5.0 Vdc Option
Reflow Solderable
<2.2 mm Height
Voltage Tune Option
Applications
Wireless handsets, PCS, GSM, Cellular
PCMCIA Applications
GPS
Description
Vectron International has introduced a series of low-pro-
file, low cost,
surface mount, Temperature Compensated
Crystal Oscillators (TCXOs)
available in frequencies
from 10 MHz to
50
MHz.
The OSC series low-profile (0.09 inch maximum height),
surface mount TCXOs can be mounted using the stan-
dard convection reflow process. The units feature a
PPM frequency vs. temperature characteristic over a
to
operating range and operate from a
3.0V or 5V supply. Current drain <2.0 mA. Aging
<1ppm/year and phase noise is -125 dBc/Hz at 100 Hz
and -150 dbc/Hz at 100 kHz.
The OSC series of TCXOs and TCVCXOs has been
designed for pick-and-place mounting and reflow sol-
dering. Units are available on tape-and-reel at no addi-
tional charge. The reel size is 2000 pcs. and is compati-
ble with EIAJ-1009B standards. The low-cost, miniature
units are ideal for wireless handsets, PCMCIA applica-
tions, and GPS receivers.
OSC Series Ultra Miniature TCXO s
Performance Characteristics
Parameter
Option A = +5 Vdc
Frequency range:
Stability Options:
(relative to
1
2
3
4
=
=
=
=
Characteristics
Option B= +3 Vdc
10 MHz to
50
MHz
ppm
ppm
ppm
ppm
-20
-30
-30
-40
to
to
to
to
Stability vs. Supply
Aging
(typical):
Input Voltage:
Current:
Output:
Clipped Sinewave
Load:
Mechanical trim:
Trim options:
+5.0 Vdc
ppm vs B+ of
< 1.0 ppm/year at
+3.0 Vdc
<2.0 mA (16.8 to 20.0 MHz)
<4.0 mA (35.1 to 50.0 MHz)
+3.0 Vdc = 0.7 VP-P minimum
<1.5 mA (10.0 to 16.8 MHz)
<3.0 mA (20.1 to 35.0 MHz)
+5.0 Vdc = 1.0 VP-P minimum
10 K /10pf
PPM min.
*Need a trim tool
0 = Mechanical trim, no VCO
1=
ppm VC & mechanical
2 = Voltage trim only
ppm min.
100K
+5.0 Vdc
+0.5Vdc to +4.5Vdc
ppm at +2.5 Vdc
<10 mS (typical) to within
> 3 dBc down
> 6 dBc down
> 10 dBc down
-80 dBc/Hz max. at 10 Hz offset
-125 dBc/Hz max. at 100 Hz offset
-145 dBc/Hz max. at 1 KHz offset
-148 dBc/Hz max. at 10 KHz offset
-150 dBc/Hz max. at 100 KHz offset
minimum
+3.0 Vdc
+0.5Vdc to +2.5Vdc
ppm at +1.5 Vdc
PPM
Voltage Control
Input Impedence:
Supply Voltage:
Control Voltage Range:
Frequency Tolerance at
Start-up time:
Harmonics:
2nd harmonic
3rd harmonic
Other
Phase Noise (typical):
at 10 MHz
Vectron International
267 Lowell Road, Hudson, NH 03051
2
Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON
OSC Series Ultra Miniature TCXO s
0.39
(9.9)
max
3
2
0.47
(11.8)
max
4
1
The OSC series of TCXO s and VCTCXO s has
been designed for pick and place and reflow sol-
dering. Units are available on
Tape and Reel
at
no additional charge when ordering a complete
reel. The reel size is 2000 pcs and is compatible
with EIAJ-1009B standards. The suggested
reflow profile is shown below. The TCXO may be
reflowed two times. Frequency shift as a result of
reflow will be <1.0PPM. Units should not be
adjusted to center frequencies until at least 2
hours after reflow to allow the crystals to stabilize.
The OSC footprint is compatible with many of the
previous generation 6 pin leaded TCXO s. Our
OSE
model is the same size as the OSC except it
provides the two additional pads to match pad con-
nections of 6 pin leaded TCXO s and VCTCXO s.
0.050 (1.3)
4 places
Frequency
adjust
access
Terminal #1
identifier
0.09
(2.2)
max
0.020
(0.5)
0.055 (1.4)
2 places
4
1
0.025 (0.7)
4 places
TCXO s are precision subsystems with tolerances
measured to
Non-hermeti-
cally sealed TCXO s should not be subjected to a
wash process that will immerse the TCXO in sol-
vents.
No clean
is the recommended procedure.
PIN 1 = VC or N/C
PIN 2 = GROUND
PIN 3 = OUTPUT
PIN 4 =
Supply
0.300
(7.62)
0.040 (1.2)
4 places
3
2
Model OSC
Land Pattern
8.4mm
1.4mm
Convection Reflow Profile
7.62mm
1.4mm
1.9mm
1.9mm
warm-up
>30 sec.
pre-heating
50 to 90 sec at
reflow
20 to 40 soc
Vectron International
267 Lowell Road, Hudson, NH 03051
Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON
3
OSC Series Ultra Miniature TCXO s
Order Information
Standard Frequencies* (MHz)
10.0
16.0
12.8
19.2
13.0
19.98
14.4
20.0
15.56
25.0
How To Order
OSC-
Stability Code
(from page 2)
at
Frequency
Trim Option
0 = Mechanical trim, no VCO
1=
ppm VC & mechanical
2 = Voltage trim only
ppm min.
Input Voltage
A = +5.0 Vdc
<2.0 mA MAX.
B = +3.0 Vdc
<1.5 mA (10.0 to 16.8 MHz)
<2.0 mA (16.8 to 20.0 MHz)
Example of typical P/N
OSC-3B2 19.2 MHz
3=
ppm
B = +3.0 Vdc
2 = Voltage Tune
no mechanical trimmer
Visit Our Website at
www.vectron.com
For additional information please contact:
USA: 267 Lowell Road, Hudson, NH 03051 . . . . . . . . . . . . . . . . . . . . . .Tel: 1-88-VECTRON-1, FAX: 1-888-FAX-VECTRON
EUROPE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .Tel: 49 (0) 3328 4784 17 Fax: 49 (0) 3328 4784
30ASIA: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Tel: +86 21 28909740 / 41 /42 Fax: +86 21 28909240 / 2890999
www.vectron.com
Vectron International reserves the right to make changes to the product(s) and/or information contained herein without notice.
No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information.
4
Printed in USA 2/99,
Rev. 8/19/02
