Multifuse
®
Products
Bourns
®
Multifuse
®
family of Polymer Positive
Temperature Coefficient (PPTC) “resettable
fuses” are used in a wide variety of circuit
protection applications.
Under fault conditions the device resistance
will rise exponentially and remain in a
“tripped” state, providing continuous circuit
protection until the fault is removed. Once the
fault is removed and the power cycled the device
will return to its normal low resistance state.
Applications
• Computer
• Battery
• Automotive
• Telecommunications
• Industrial
• Consumer
What’s New in this Edition
• Telecom Rated Products
• MF-R/90
• MF-R/250
• MF-R/600
Features/Benefits
• Resettable circuit protection
• Agency approval - UL, CSA, TÜV
• Popular footprints and packaging options
• Low resistance
• Lead free options
• Custom designs available
What’s Next
• Full line of SMD lead-free products
• MF-MSMF - Available 3rd Quarter 2003
Multifuse
®
Products - How They Work
Crystalline
Polymer
Amorphous
Polymer
Conducting
Carbon Chains
Non-conducting
Carbon Chains
COLD
HOT
Multifuse
®
Products - How They’re Used
I=V/RMF
Log Resistance
I
+t°
I=V/RL
Temperature
PTC Response Characteristic
Typical Circuit Application
RMF
VS
RL
Definitions
Agency Approvals
Bourns
®
PTCs are certified under UL, CSA, IEC and
TÜV registration programs.
Current, Hold (Ihold)
The maximum current a PTC device can pass without
interruption.
Current, Maximum (Imax)
The maximum fault current a PTC device can withstand
without damage at the rated voltage.
Current, Trip (Itrip)
The minimum current that will switch a PTC from the
low resistance to the high resistance state.
Fault Current
The peak current that flows through a PTC or wire
during a short circuit or arc back.
Positive Temperature Coefficient (PTC)
A characteristic of the PTC device that describes the large
increase in resistance as the device reaches its switching
(trip) temperature.
Resistance, Post Trip (R1max)
The maximum resistance one hour after a PTC device
has been tripped and power has been removed.
Resistance, Post Reflow (R1max)
The maximum resistance one hour after a PTC surface
mount device has been reflow soldered.
Voltage, Maximum (Vmax)
The maximum voltage a PTC device can withstand
without damage at the rated current.
Product Selection Worksheet
1. What is the normal circuit operating current (Ihold)_________
2. What is the maximum circuit voltage (Vmax)______________
3. What is the maximum fault current (Imax)________________
4. What is the preferred form factor________________________
Note: Other factors including thermal derating and time to
trip characteristics may be important application considera-
tions. Please refer to the full Bourns
®
data sheet of each
product at www.bourns.com.
How To Order
MF - R 012/250 U - A 05 - 2
Multifuse
®
Product Designator
Series
R
RX
SM
MSMD
ESMD
USMD
S
LR
LS
SVS
VSN
VS
= Radial Leaded
= Radial Leaded
= Surface Mount
= Surface Mount
= Surface Mount
= Surface Mount
= Axial Leaded Strap
= Axial Leaded Strap
= Axial Leaded Strap
= Axial Leaded Strap
= Axial Leaded Strap
= Axial Leaded Strap
Hold Current, Ihold
Voltage Options:
Max. Interrupt Voltage, V
Construction Options:
N = Narrow Device Option (3.6 mm)*
S = Slotted Lead Option (one side)*
SS = Slotted Lead Option (two sides)*
L = Longer Lead Option*
U = Uncoated
T = Pretripped **
Resistance Sorted**
(see individual data sheets)
Agency File Numbers
®
Resistance Bins of 0.5
Ω**
05 = 0.5
Ω
Packaging Options
- 0 = Bulk Packaging
- 2 = Tape and Reel
- AP = Ammo-Pak
*Axial Leaded Strap products only.
**Telecom Radial Leaded products only.
