SBR1060F
Elektronische Bauelemente
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
VOLTAGE
60V
10
.0AMP Schottky Barrier Rectifiers
ITO-220
10
0.5
3.2
0.2
0.1
4.5
0.2
0.3
FEATURES
* Low forward voltage drop
* High current capability
* High reliability
* High surge current capability
* Epitaxial construction
0.2
2.8
2.7
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Lead: Lead solderable per MIL-STD-202,
method 208 guaranteed
* Polarity: As Marked
* Mounting position: Any
* Weight: 2.24 grams(Approximately)
3.7
2.54
0.2
0.7
2.54
PIN 1
PIN 3
0.2
0.2
13Min
MECHANICAL DATA
0.2
1.3
0.2
15
0.3
0.5
2.6
0.2
0.2
CASE
PIN 2
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25 C ambient temperature unless otherwise specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TYP
E NUMBER
Maximum Recurrent Peak Reverse Voltage
Working Peak Reverse Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(Per Leg)
(Per Device)
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Instantaneous Forward Voltage (I
F
=
5
Amps,T
A
= 25 C, per leg)
Maximum Instantaneous Forward Voltage (I
F
=
5
Amps,T
A
= 125 C, per leg)
Maximum DC Reverse Current
Ta=25
o
C
at Rated DC Blocking Voltage
Typical Junction Capacitance (Note1)
Typical Thermal Resistance (Note 2)
Voltage Rate Of Chance (Rated V
R
)
Operating Temperature Range
Storage Temperature Range
NOTES:
SYMBOL
V
RRM
V
RSM
V
DC
I
F
I
FSM
V
F
I
R
C
J
Rθ
JA
dv/dt
T
J
T
STG
SBR1060F
60
60
60
5
10
130
0.65
0.55
0.20
10
350
4.5
10000
-50
~
+150
-65
~
+175
UNITS
V
V
V
A
A
V
mA
o
Ta=125 C
o
pF
C/W
C
C
V/us
1. Measured at 1MHz and applied reverse voltage of 5.0V D.C.
2. Thermal Resistance Junction to Case.
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2006 Rev. A
Page 1 of 2
SBR1060F
Elektronische Bauelemente
VOLTAGE 60V
10.0AMP Schottky Barrier Rectifiers
RATING AND CHARACTERISTIC CURVES
Typical Forward Current Derating Curve
100
7
Typical Forward Characteristic
5
Instantaneous Forward Current (A)
Average Forward Current (A)
10
125℃
25℃
1
0
20
50
100
150
190
Tc, Case Temperature (℃)
75℃
Typical Junction Capacitance
800
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
Forward Voltage (V)
Junction Capacitance (pF)
600
400
Typical Reverse Characteristic
200
100
0
0.1
1
10
100
Revise Voltage (%)
100℃
10
200
Reverse Curren
t(mA)
Maximum Non- Repetitive Forward
Surge Current
Peak Forwad surge Current (A)
75℃
1
160
Tj=25℃
8.3mS Single half
Sine Wave
JEDEC Method
120
50℃
80
0.1
25℃
40
0
0
10
100
0.01
20
30
40
50
60
70
Number of Cycles at 60Hz
Reverse Voltage(V)
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individua
l
01-Jun-2002 Rev. A
Page 2 of 2
